2. INSPECT BRAKE WARNING LIGHT(a) Disconnect the connector from the brake fluid warningswitch.
(b) Release the parking brake pedal.
(c) Connect terminals on the wire harness side of the level warning switch connector.
(d) Start the engine, check that the warning light lights up.
If the warning light does not light up, test the bulb or wire har-
ness.
(Parking Brake Switch)
REMOVAL AND INSTALLATION OF PARKING
BRAKE SWITCH
1. REMOVE PARKING BRAKE SWITCH
(a) Remove the driver's seat.
(See page BO±58)
(b) Disconnect the connector and remove switch.
2. INSTALL PARKING BRAKE SWITCH For installation follow the removal procedure in reverse.
INSPECTION OF PARKING BRAKE SWITCH
1. INSPECT PARKING BRAKE SWITCH
(a) Check that there is continuity between terminal andswitch body with the switch ON (switch pin released).
(b) Check that there is no continuity between terminal and switch body with the switch OFF (switch pin pushed in.)
If continuity is not as specified, replace the switch or inspect
ground point.
2. INSPECT BRAKE WARNING LIGHT (a) Disconnect the connector from the parking brake switchand brake fluid warning switch.
(b) Ground terminal on the wire harness side connector.
(c) Start the engine, check that the warning light lights up.
If the warning light does not light up, test the bulb or inspect
wire harness.
BE±116
±
BODY ELECTRICAL SYSTEM Combination Meter
WhereEverybodyKnowsYourName
Page 538 of 4087

( Coolant Level Warning Switch)
REMOVAL AND INSTALLATION OF COOLANT
LEVEL WARNING SWITCH
1. REMOVE COOLANT LEVEL WARNING SWITCH(a) Disconnect the connector.
(b) Remove the boot.
(c) Using the notches in the head of switch, turn the switchcounterclockwise and remove it.
NOTICE: Do not remove when engine is hot.
2. INSTALL COOLANT LEVEL WARNING SWITCH For installation, follow the removal procedure in reverse.
INSPECTION OF COOLANT LEVEL WARNING
SWITCH
1. INSPECT COOLANT LEVEL WARNING SWITCH(Continuity)
(a) Remove the radiator cap and open the radiator drainclock.
NOTICE: Do not remove when engine is hot.
(b) Drain the coolant about 1 liter. (1.1 US qts, 0.9 lmp. qts)
(c) Check that there is continuity between terminals (float down).
(d) Close radiator drain cock and fill the cooling system with
coolant.
(e) Check that there is no continuity between terminals (float up).
If continuity is not as specified, replace the switch.
2. INSPECT COOLANT LEVEL WARNING LIGHT (a) Disconnect the connector from the coolant level warning
switch and ground terminal 1 on the wire harness side
connector.
(b) Start the engine, check that the warning light lights up.
If the warning light does not light up, inspect the bulb or wire
harness.
±
BODY ELECTRICAL SYSTEM Combination MeterBE±117
WhereEverybodyKnowsYourName
Page 539 of 4087

POWER WINDOW CONTROL
SYSTEM
Description
The Power Window System raises and lowers the window glass in each door usi\
ng electrical power. The compo-
nent parts of this system and their functions are described in the following\
table.
Parts NameFunction
Theft Deterrent and
Door Lock
Control ECUCurrent is sent to the power window main relay only when the ignition sw\
itch
is on or within a specified period after the ignition switch is turned o\
ff.
Power Window
Main RelayCurrent from the theft deterrent and door lock control ECU to the power
window main relay switches large current from the master switch ON and O\
FF.
Master SwitchThis switch turns current to each power window motor ON and OFF and
switches it. It also includes a circuit for ºOne Touch Power Windowº use of
the driver's window and a built±in window lock switch which controls the
operation of all power window switches.
Power Window
SwitchThis switch is installed on each door except on the driver's door. It is supplied
with current from the master siwtch and turns the current to the motor O\
N and
OFF and switches the current. This switch will not operate when the wind\
ow
lock switch inside the master switch is in the LOCK position.
Power Window
MotorThis motor moves the window regulator directly when current is supplied \
to it
from the master switch or power window switch. The motor has a built±\
in
circuit breaker.
Parts Location
±
BODY ELECTRICAL SYSTEM Power Window Control SystemBE±147
WhereEverybodyKnowsYourName
Page 540 of 4087
Wiring and Connector Diagrams
BE±148±
BODY ELECTRICAL SYSTEM Power Window Control System
WhereEverybodyKnowsYourName
Page 541 of 4087
Parts Inspection
(Power Window Master Switch)
REMOVAL AND INSTALLATION OF
POWER WINDOW MASTER SWITCH
(See page BO±33)
INSPECTION OF POWER WINDOW
MASTER SWITCH
INSPECT POWER WINDOW MASTER SWITCH
(Continuity)
Inspect the switch continuity between terminals.
Window operation Driver's Passenger's
Terminal
Switch position
UP
OFF
DOWN
UP
OFF
DOWN
Window Unlock
Window Lock
If continuity is not as specified, replace the master siwtch.
(Illumination)
(a) Set the window lock switch to the unlock position.
(b) Connect the positive (+) lead from the battery to terminal
4 and the negative (±) lead to terminal 8, check that all
the illuminations light up.
±
BODY ELECTRICAL SYSTEM Power Window Control SystemBE±149
WhereEverybodyKnowsYourName
Page 542 of 4087

(c) Set the window lock switch to the lock position, checkthat all the passenger's power window switch
illuminations go out.
If operation is not as specified, replace the master switch.
(One Touch Power Window System/Current of Circuit)
Inspection using an ammeter.
(a) Disconnect the connector from the master switch.
(b) C onnect the positive (+) lead from the ammeter to
terminal 9 on the wire harness side connector and the
negative (±) lead to negative terminal of the battery.
(c) Connect the positive (+) lead from the battery to terminal
10 on the wire harness side connector.
(d) As the window goes down, check that the current flow is approximately 7 amperes.
(e) Check that the current increases approximately 14.5 amperes or more when the window stops going down.
HINT: The circuit breaker opens some 4±40 seconds after the
window stops going down, so that check must be made be-
fore the circuit breaker operates.
If the operation is as specified, replace the master switch.
Inspection using an ammeter with a current±measuring
probe.
(a) Remove the master switch with connector connected.
(b) Attach a current±measuring probe to terminal 4 of the
wire harness.
(c) Turn the ignition switch ON and set the power window switch in the down position.
(d) As the window goes down, check that the current flow
is approximately 7 amperes.
(e) Check that the current increases approximately 14.5 amperes or more when the window stops going down.
HINT: The circuit breaker opens some 4±40 seconds after the
window stops going down, so that check must be made be-
fore the circuit breaker operates.
If operation is as specified, replace the master switch.
BE±150
±
BODY ELECTRICAL SYSTEM Power Window Control System
WhereEverybodyKnowsYourName
Page 543 of 4087

(Switch Circuit)
Disconnect the connector from the master switch and inspect
the connector on the wire harness side as shown.
Check forTester connectionConditionSpecified value
Voltage9±GroundIgnition switch turned to ONBattery voltage
Continuity8±GroundConstantContinuity
If the circuit is not as specified, refer to BE±148 wiring dia-
gram and inspect the circuits connected to other parts.
(Power Window Switch)
REMOVAL AND INSTALLATION OF
POWER WINDOW SWITCH
(See page BO±33)
INSPECTION OF POWER WINDOW
SWITCH
INSPECT POWER WINDOW SWITCH
(Switch Continuity)
Inspect switch continuity between terminals.
Terminal
Switch
position
UP
OFF
DOWN
If continuity is not as specified, replace the switch.
(Switch Circuit)
Disconnect the connector from the switch and inspect the
connector on the wire harness side as shown.
Check forTester connectionConditionSpecified value
Voltage2±GroundIgnition switch ON andDOWNBattery positive voltagegg
master switch positionOFFNo voltage
3±GroundIgnition switch ONBattery positive voltage
4±GroundIgnition switch ON and UPBattery positive voltageg
master switch positionOFFNo voltage
If the circuit is not as specified, refer to BE±148 wiring dia-
gram and inspect the circuits connected to other parts.
±
BODY ELECTRICAL SYSTEM Power WindowBE±151
WhereEverybodyKnowsYourName
Page 544 of 4087

(Power Window Main Relay)
REMOVAL AND INSTALLATION OF
POWER WINDOW MAIN RELAY
(See page BE±16)
INSPECTION OF POWER WINDOW MAIN
RELAY
INSPECT POWER WINDOW MAIN RELAY
(Continuity)
Inspect relay continuity between terminals.
Terminal
Condition Constant
Apply battery voltage to terminals 1 and 2.
If continuity is not as specified, replace the relay.
(Relay Circuit)
(See page BE±20)
(Power Window Motor)
REMOVAL AND INSTALLATION OF
POWER WINDOW MOTOR
1. REMOVE POWER WINDOW MOTOR
(a) Remove window regulator.(See page BO±35)
2. INSTALL POWER WINDOW MOTOR For installation follow the removal procedure in reverse.
INSPECTION OF POWER WINDOW
MOTOR
INSPECT POWER WINDOW MOTOR(Left Side Door Motor/Motor Operation)
(a) Connect the positive (+) lead from the battery to terminal
1 and the negative (±) lead to terminal 2, check that the
motor turns counterclockwise.
(b) Re ve rse th e po la rity, ch e ck th a t th e mo to r tu rn s clockwise.
If operation is not as specified, replace the motor.
