Page 1569 of 4087

LEXUS SC400 1991 Service Repair Manual 2. CONNECT TRANSMISSION CONTROL ROD FROMSHIFT LEVER Connect the control rod to the shift lever with the nut. 3. INSTALL PROPELLER SHAFT (See page PR±12) 4. INSTALL CENTER FLOOR CROSSMEMBER BRACE

Page 1570 of 4087

LEXUS SC400 1991 Service Repair Manual 7. INSTALL TAILPIPE (a) Install the hook of the tailpipe to the ring on the tailpipebracket. (b) Install a new gasket and tailpipe to the center exhaust pipe with 2 bolts. Install the 2 tailpipes.

Page 1571 of 4087

LEXUS SC400 1991 Service Repair Manual 11. CONNECT ENGINE WIRE TO CABIN (a) Push in the engine wire through the cowl panel.NOTICE: Be careful not to damage the engine wire. Tape the engine wire. (b) Install the engine wire retainer wit

Page 1572 of 4087

LEXUS SC400 1991 Service Repair Manual (d) Install the ECM with the nut. (e) Install the ECM protector with the 2 nuts. (f) Install the floor carpet. (g) Install the scuff plate. (h) Connect the connectors. (i) Install the lower ins

Page 1573 of 4087

LEXUS SC400 1991 Service Repair Manual 12. INSTALL CHARCOAL CANISTER (a) Install the charcoal canister. (b) Connect the vacuum hose and air hose to the charcoalcanister. 13. CONNECT HOSES Connect the following hoses and ground strap:

Page 1574 of 4087

LEXUS SC400 1991 Service Repair Manual 15. INSTALL POWER STEERING (PS) PUMP (a) Install the PS pump with the nut and 3 bolts. Alternatelytighten the bolts and nut. Torque: 39 NVm (400 kgf Vcm, 29 ft Vlbf) for bolt 43 N Vm (440 kgf Vcm,

Page 1575 of 4087

LEXUS SC400 1991 Service Repair Manual 20. INSTALL POWER STEERING (PS) SOLENOID VALVECONNECTOR 21. CONNECT ENGINE WIRE CONNECTORS 22. CONNECT THEFT DETERRENT HORN CONNECTOR 23. INSTALL GROUND CABLE TO BODY 24. CONNECT IGNITER CONNECT

Page 1576 of 4087

LEXUS SC400 1991 Service Repair Manual (d) Install the upper radiator support with the 2 bolts and screw.Install the 2 upper radiator supports. Torque: 12 N Vm (120 kgf Vcm, 9 ft Vlbf) (e) Connect the following hoses: (1) 2 oil cooler
