Page 1249 of 4087

Fuel Pump ECUAuto Antenna Motor and Relay
Power Seat ECU
(For Passenger's Seat)
Power Seat ECU
(For Driver's Seat) CD Automatic Changer
Wireless Door Lock ECU
Moon Roof Control Relay
Locations of ECUs (Cont'd)
Many ECUs are mounted in this vehicle.
Take the following precautions during body repair to prevent damage to th\
e ECUs.
Before starting electric welding operations, disconnect the negative (-\
) terminal cable from the battery.
When the negative (-) terminal cable is disconnected from the battery, memory of the clock and audio
systems will be cancelled. So before starting work, make a record of the\
contents memorized by each
memory system. Then when work is finished, reset the clock and audio sys\
tems as before.
When the vehicle has tilt and telescopic steering, power seat and outsid\
e rear view mirror, which are all
equipped with memory function, it is not possible to make a record of th\
e memory contents.
So when the operation is finished, it will be necessary to explain this \
fact to the customer, and request
the customer to adjust the features and reset the memory.
Do not expose the ECUs to ambient temperatures above 80 °C (176 °F).
NOTICE: If it is possible the ambient temperature may reach 80°C (176°F) or, more, remove the ECUs
from the vehicle before starting work.
Be careful not to drop the ECUs and not to apply physical shocks to them\
.
5. COMPONENTS ADJACENT TO THE BODY PANELS
Various types of component parts are mounted directly on or adjacently to\
the body panels.
Strictly observe the following precautions to prevent damaging these com\
ponents and the body panels
during handling.
Before repairing the body panels, remove their adjacent components or ap\
ply protective covers over
the components.
Before prying components off using a screwdriver or a scraper, etc., attach protective tape to the tool
tip or blade to prevent damaging the components and the body paint.
Before removing components from the outer surface of the body, attach protective tape to the body to
ensure no damage to painted areas.
HINT: Apply touch-up paint to any damaged paint surfaces.
Before drilling or cutting sections, make sure that there are no wires, \
hoses, etc., on the reverse side.
INTRODUCTIONIN-9
WhereEverybodyKnowsYourName
Page 1250 of 4087

GENERAL REPAIR INSTRUCTIONS
Work Precautions
SAFETY
1. Before performing repair work, checkfor fuel leaks. If a leak is found, be sure
to close the opening totally.
2. If it is necessary to use a frame in the area of the fuel tank, first remove the
tank and plug the fuel line.
VEHICLE PROTECTION
When welding, protect the
painted surfaces, windows,
seats and carpet with heat
resistant, fire-proof covers.
SAFETY
Never stand in direct
line with the chain when
using a puller on the
body or frame, and be
sure to attach a safety
cable.
WRONG
Glass Cover
Safety Cable Seat Cover
WRONG
SAFETY WORK CLOTHES
HAND TOOLS
Keeping your hand tools in
neat order improve your
work efficiency.
In addition to the usual mechanic's wear, cap and safety shoes,
the appropriate gloves, head protector, glasses, ear plugs, face
protector, dust-prevention mask, etc. should be worn as, the
situation demands.
Dust-
Prevention
Mask Welder's
Glasses
Ear
Plugs Body
Mechanic
Stand
Face
Protector
Head
Protector
Eye
Protector
Welder's
Gloves
Safety
Shoes
INTRODUCTIONIN-10
WhereEverybodyKnowsYourName
Page 1251 of 4087

Proper and Efficient Work ProceduresREMOVAL
NUMBER OF SPOT WELDS AND PANEL POSITIONS
The number of spot welds and the panel positions to be
removed are shown for your reference.
HINT: See ºSymbols º on page IN-4,5 .
PRE-REMOV AL MEASURING
Before removal or cutting
operations, take measurements
in accordance with the dimen-
sion diagram. Always use a
puller to straighten a damaged
body or frame.
REMOVAL of ADJACENT COMPONENTS
When removing adjacent components, ap-
ply protective tape to the surrounding body
and your tools to prevent damage.
HINT: See ºHandling Precautions on Related Components º on page IN-9.
PRECAUTIONS FOR DRILLING OR
CUTTING
Check behind any area to be drilled or
cut to insure that there are no hoses,
wires, etc., that may be damaged.
HINT: See ºHandling Precautions on
Related Components º on page IN-9.
CUTTING AREA
Always cut in a straight
line and avoid reinforced
areas.
Cutting Okay
Corners
Reinforcement
WRONG
INTRODUCTIONIN-11
WhereEverybodyKnowsYourName
Page 1252 of 4087
Thickness of
welded portionSize of plug hole
1.0 (0.04) under 5 (0.20)
f over
1.0 (0.04) - 1.5 (0.06) 6.5 (0.26)
f over
1.5 (0.06) over 8 (0.31)
f over
REFERENCE:
mm (in.)
PREPARATION FOR INSTALLATION
SPOT WELD POINTS
APPLICATION OF WELD-THROUGH PRIMER
(SPOT SEALER)
Less than
3 mm
Remove the paint from
the portion of the new
parts and body to be
welded, and apply
weld-through primer.
HINT: See ºANTI-
RUST TREATMENT ºon page AR-9.
When welding panels with a
combined thickness of over
3 mm (0.12 in.), use a MIG
(Metal Inert Gas) welder for
plug welding.
HINT: Spot welding will not
provide sufficient durabilityfor panels over 3 mm (0.12
in.) thick.
Air Saw
WRONG
Puncher
20 - 30 mm
Overlap
ROUGH CUTTING OF JOINT
For joint areas, rough
cut the new parts, leaving
20 - 30 mm (0.79 - 1.18 in.)
overlap. MAKING HOLES FOR PLUG WELDING
For areas where a spot welder cannot
be used, use a puncher or drill to make
holes for plug welding.
INTRODUCTIONIN-12
WhereEverybodyKnowsYourName
Page 1253 of 4087

INSTALLATION
PRE-WELDING MEASUREMENTS
Always take measurements
before installing underbody
or engine components
to insure correct assembly.
After installation, confirm
proper fit.POST-WELDING REFINISH-
ING
1. Always check the welded
spots to insure they are
secure.
2. When smoothing out the weld spots with a disc
grinder, be careful not to
grind off too much as this
would weaken the weld.
WELDING PRECAUTIONS
1. The number of welding spots
should be as follows.
Spot weld: 1.3 x No. of
manufacturer's spots.
Plug weld: More than No. of
manufacturer's plugs.
WRONG
OKAYWRONG
2. Plug welding should be done
with a MIG (Metal Inert Gas)
welder. Do not gas weld or
braze panels at areas other
than specified.
Safety Glass
Body
Measurement
Diagrams
SPOT WELDING PRECAUTIONS
SPOT WELD LOCATIONS
Try to avoid welding over
previous spots. 1. The shape of the welding
tip point has an effect on
the strength of the weld.
2. Always insure that the seams and welding tip are
free of paint.
Old
Spot
Locations New Spot
Locations
Tip Cutter
INTRODUCTIONIN-13
WhereEverybodyKnowsYourName
Page 1254 of 4087
ANTI-RUST TREATMENT
When replacing body panels, always apply body sealer, anti-rust agent or undercoat according to the re-
quirements of your country.
HINT: For further details, see the description given in Section AR of this m\
anual.
ANTI-RUST AGENT (WAX)Apply anti-rust agent to
following sections.
Inside of the hems of the
doors and hood.
Around the hinges of the
doors and hood.
Inside of the welded parts
with boxed cross-section.
BODY SEALER
Apply body sealer to the
required areas.
Cartridge
Type
Tube
Type
UNDERCOAT
Apply undercoat to the underbody and
wheel housings.
Spray Gun
Undercoating
(Water base)
Undercoating
(Oil base)
INTRODUCTIONIN-14
WhereEverybodyKnowsYourName
Page 1255 of 4087
N01093
N01094
SUPPORT POSITION PANTOGRAPH JACK POSITION
Front Center of suspension crossmember. . . . . . . .
Rear Jack up support of differential carrier . . . . . . . . .
JACK POSITION
Jack
or Suspension Crossmember
Front
Safety stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
VEHICLE LIFT AND SUPPORT LOCATIONS
INTRODUCTIONIN-15
WhereEverybodyKnowsYourName
Page 1256 of 4087

SERVICE SPECIFICATIONS
SERVICE DATA
ThermostatValve opening temperature80±845C176±183 5F
Valve liftat 95 5C (203 5F) 10 mm0.39 in.
Radiator capRelief valve opening pressureSTD74±103 kPa
(0.75±1.05 kgf/cm, 10.7±14.9 psi)
Limit 59 kPa 0.6 kgf/cm 8.5 psi
On±vehicle
itifh
Oil pressure1,177±2,452 kPa
inspection for hy-
draulic cooling(12±25 kgf/cm, 171±356 psi)draulic cooling
fan
fan
Hydraulic pumpSpool valve45.8 mm1.803 in.
Rotor side clearanceSTD Drive rotor 0.02 mm0.0008 in.
Driven rotor 0.03 mm0.0012 in.
Limit Drive rotor 0.03 mm0.0012 in.
Driven rotor 0.04 mm0.0016 in.
Rotor body clearanceSTD 0.05±0.09 mm0.0020±0.0035 in.
Limit 0.10 mm0.0039 in.
Rotor tip clearanceSTD 0.02 mm0.0008 in.
Limit 0.03 mm0.0012 in.
Drive shaft bushing inside diameter17.00±17.05 mm0.6693±0.6713 in.
Drive shaft diameter16.97±16.98 mm0.6681±0.6685 in.
Drive shaft oil clearanceSTD 0.02±0.08 mm0.0008±0.0031 in.
Limit 0.08 mm0.0031 in.
Drive shaft preload (rotating torque)0.3 N Vm 3.0 kgf Vcm 2.6 in. Vlbf
Solenoid valve resistanceat cold 7.5±8.5
Hydraulic motorRotor side clearanceSTD0.01±0.04 mm0.0004±0.0016 in.
Limit 0.05 mm0.0020 mm
Drive shaft hole inside diameter14.000±14.011 mm0.5512±0.5516 in.
Drive shaft diameter13.973±13.984 mm0.5501±0.5506 in.
Drive shaft oil clearanceSTD 0.016±0.038 mm0.0006±0.0015 in.
Limit 0.04 mm0.0031 in.
Drive shaft preload (rotating torque)0.3 NVm 3.0 kgf Vcm 2.6 in. Vlbf
Water temp. Resistanceat 80 5C (176 5F)1.48±1.58 k
sensor
CO±64±
COOLIING SYSTEM Service Specifications
