12. Observe the following precautions to avoid damage to theparts:
(a) Do not open the cover or case of the ECU unless
absolutely necessary (If the IC terminals are touched, the
IC may be destroyed by static electricity.).
(b) To pull apart electrical connectors, pull on the connectoritself, not the wires (See page BE±2).
(c) Be careful not to drop electrical components, such as sensors or relays. It they are dropped on a hard floor,
they should be replaced and not reused.
(d) When checking continuity at the wire connector, insert the tester probe carefully to prevent terminals from
bending.
(e) To disconnect vacuum hoses, pull on the end, not the middle of the hose.
(f) When steam cleaning an engine, protect the distributor,
coil and air filter from water.
(g) Ne ve r use an imp a ct wre n ch to re mo ve or in sta ll temperature switches or temperature sensors.
(h) When using a vacuum gauge, never force the hose onto
a connector that is too large. Use a step±down adapter
instead. Once the hose has been stretched, it may leak.
13. Tag hoses before disconnecting them: (a) When disconnecting vacuum hoses, use tags to identify
how they should be reconnected.
(b) After completing a job, double check that the vacuum hoses are properly connected. A label under the hood
shows the proper layout.
14. Installation of wheels The wheel assemblies are of the uni±directional type and
must be rotated only between the front and rear as illustrated.
Wheels are marked with turning direction indicators.
When installing the wheels, check the marks carefully and
install the wheel correctly.
15. Bleeding of traction control system When repairing the brake master cylinder or TRAC system,
bleed the air out of the TRAC system (See page BR±7).
CAUTION: Since the fluid is under high pressure, it could
spray out with great force, so be careful.
IN±6
±
INTRODUCTION General Repair Instructions
WhereEverybodyKnowsYourName
Page 10 of 4087

TOTAL DIAGNOSTIC
COMMUNICATION LINK (TDCL)
The TDCL is provided inside the cabin (located under the left side
instrument panel) as a connector exclusively for diagnosis of data
from the engine, ECT, ABS, A/C, Airbag and Cruise Control Sys-
tem to improve serviceability. The check connector inside the en-
gine compartment is used for engine adjustment.
Connecting the following terminals of the TDCL to terminal E1 se-
lects the diagnosis mode shown.
NOTICE: Never make a mistake with the terminal connection
position as this will cause a malfunction.
TerminalSystem
TE1Engine and ECT (Normal mode)
TE2 and TE1Engine and ECT (Test mode)
TcABS, A/C, Airbag, Traction Control and Cruise
Control System
TTECT
Refer to the respective system for the inspection method.
HINT: By connecting the TDCL up to a monitor specifically de-
signed for use with the TDCL, the diagnosis result for each system
can be read easily.
±
INTRODUCTION Total Diagnostic Communication Link (TDCL)IN±7
WhereEverybodyKnowsYourName
Page 11 of 4087

PRECAUTIONS FOR VEHICLES
EQUIPPED WITH SRS AIRBAG
The LEXUS SC400 is equipped with an SRS (Supplemental Re-
straint System) airbag.
Failure to carry out service operations in the correct sequence
could cause the airbag system to unexpectedly deploy during serv-
icing, possibly leading to a serious accident.
Further, if a mistake is made in servicing the airbag system, it is pos-
sible the airbag may fail to operate when required.
Before performing servicing (including removal or installation of
parts, inspection or replacement), be sure to read the following
items carefully, then follow the correct procedure described in this
manual.
Locations of Airbag Components
1. Malfunction symptoms of the airbag system are difficult to confirm,
so the diagnostic codes become the most important source of
information when troubleshooting.
When troubleshooting the airbag system, always inspect the diag-
nostic codes before disconnecting the battery. (See page
AB±25)
2. Work must be started after approx. 20 seconds or longer from the time the ignition switch is turned to the LOCK position and
the negative (±) terminal cable is disconnected from the
battery.
(The airbag system is equipped with a back±up power source
so that if work is started within 20 seconds of disconnecting
the negative (±) terminal cable of the battery, the airbag may be
deployed.)
IN±8±
INTRODUCTION Precautions for Vehicles Equipped with SRS Airbag
WhereEverybodyKnowsYourName
Page 12 of 4087

When the negative (±) terminal cable is disconnected from
the battery, memory of the clock and audio systems will be
cancelled. So before starting work, make a record of the con-
tents memorized by each memory system. Then when work
is finished, reset the clock and audio systems as before.
When the vehicle has power tilt and power telescopic steer-
ing, power seat, power outside rear view mirror and power
shoulder belt anchorage, which are all equipped with
memory function, it is not possible to make a record of the
memory contents. So when the operation is finished, it will be
necessary to explain this fact to the customer, and ask the
customer to adjust the features and reset the memory.
To avoid erasing the memory of each memory system, never
use a back±up power supply from outside the vehicle.
3. Even in cases of a minor collision where the airbag does not deploy, the front airbag sensors and the steering wheel pad
should be inspected. (See page AB±9)
4. Never use airbag parts from another vehicle. When replacing parts, replace them with new parts.
5. Before repairs, remove the airbag sensors if shocks are likely
to be applied to the sensors during repairs.
6. The center airbag sensor assembly contains mercury. After
performing replacement, do not destroy the old part. When
scrapping the vehicle or replacing the center airbag sensor
assembly itself, remove the center airbag sensor assembly
and dispose of it as toxic waste.
7. Never disassemble and repair the front airbag sensors, center airbag sensor assembly or steering wheel pad in order
to reuse it.
8. If the front airbag sensors, center airbag sensor assembly or steering wheel pad have been dropped, or if there are cracks,
dents or other defects in the case, bracket or connector,
replace them with new ones.
9. Do not expose the front airbag sensors, center airbag sensor assembly or steering wheel pad directly to hot air or flames.
10. U s e a v o l t / o h m m e t e r w i t h h i g h i m pedance (10 kW/V
minimum) for troubleshooting of the electrical circuit.
11. Information labels are attached to the periphery of the airbag components. Follow the notices.
12. After work on the airbag system is completed, perform the
airbag warning light check (See page AB±30).
±
INTRODUCTION Precautions for Vehicles Equipped with SRS AirbagIN±9
WhereEverybodyKnowsYourName
Page 13 of 4087

FRONT AIRBAG SENSOR
1. Never reuse the front airbag sensors involved in a collisionwhen the airbag has deployed. (Replace both the left and
right airbag sensors.)
2. Install the front airbag sensor with the arrow on the sensor facing toward the front of the vehicle.
3. The front airbag sensor set bolts have been anti±rust treated. When the sensor is removed, always replace the set bolts
with new ones.
4. The front airbag sensor is equipped with an electrical connection check mechanism. Be sure to lock this
mechanism securely when connecting the connector. If the
connector is not securely locked, a malfunction code will be
detected by the diagnosis system (See page AB±10).
SPIRAL CABLE (IN COMBINATION
SWITCH)
The steering wheel must be fitted correctly to the steering column
with the spiral cable at the neutral position; otherwise cable dis-
connection and other troubles may result. Refer to page AB±15
of this manual concerning correct steering wheel installation.
STEERING WHEEL PAD (WITH AIRBAG)
1. When removing the steering wheel pad or handling a new steering wheel pad, it should be placed with the pad top
surface facing up.
In this case, the twin±lock type connector lock lever should
be in the locked state and care should be taken to place it so
the connector will not be damaged. And do not store a steer-
ing wheel pad on top of another one. (Storing the pad with its
metallic surface up may lead to a serious accident if the air-
bag inflates for some reason.)
2. Never measure the resistance of the airbag squib. (This
may cause the airbag to deploy, which is very
dangerous.)
IN±10±
INTRODUCTION Precautions for Vehicles Equipped with SRS Airbag
WhereEverybodyKnowsYourName
Page 14 of 4087

3. Grease should not be applied to the steering wheel pad andthe pad should not be cleaned with detergents of any kind.
4. Store the steering wheel pad where the ambient temperature remains below 93 C (200 F), without high humidity and
away from electrical noise.
5. When using electric welding, first disconnect the airbag connector (yellow color and 2 pins) under the steering
column near the combination switch connector before
starting work.
6. When disposing of a vehicle or the steering wheel pad alone, the airbag should be deployed using an SST
before disposal (See page AB±91). Perform the
operation in a place away from electrical noise.
CENTER AIRBAG SENSOR ASSEMBLY
The connector to the center airbag sensor assembly should be
connected or disconnected with the sensor mounted on the floor.
If the connector is connected or disconnected while the center air-
bag sensor assembly is not mounted to the floor, it could cause un-
desired ignition of the airbag system.
WIRE HARNESS AND CONNECTOR
The airbag system's wire harness is integrated with the cowl wire
harness assembly. The wires for the airbag wire harness are en-
cased in a yellow corrugated tube. All the connectors for the sys-
tem are also a standard yellow color. If the airbag system wire har-
ness becomes disconnected or the connector becomes broken
due to an accident, etc., repair or replace it as shown on page
AB±22 .
±
INTRODUCTION Precautions for Vehicles Equipped with SRS AirbagIN±11
WhereEverybodyKnowsYourName
Page 15 of 4087

PRECAUTIONS FOR VEHICLES
EQUIPPED WITH A CATALYTIC
CONVERTER
CAUTION: If large amounts of unburned gasoline flow into the
converter, it may overheat and create a fire hazard. To prevent
this, observe the following precautions and explain them to
your customer.
1. Use only unleaded gasoline.
2. Avoid prolonged idling. Avoid running the engine at idle speed for more than 20 min-
utes.
3. Avoid spark jump test. (a) P e r f o r m s p a r k j u m p t e s t o n l y w h e n a b s o l u t e l ynecessary. Perform this test as rapidly as possible.
(b) While testing, never race the engine.
4. Avoid prolonged engine compression measurement.
Engine compression tests must be done as rapidly as pos-
sible.
5. Do not run engine when fuel tank is nearly empty. This may c ause the engine to misfire and create an extra load
on the converter.
6. Avoid coasting with ignition turned off and prolonged braking.
7. Do not dispose of used catalyst along with parts contaminated with gasoline or oil.
IN±12
±
INTRODUCTION Precautions for Vehicles Equipped with a Catalytic
Converter
WhereEverybodyKnowsYourName
Page 16 of 4087
PRECAUTIONS FOR VEHICLES
EQUIPPED WITH TRACTION
CONTROL (TRAC) SYSTEM
When using a rear wheel two±wheel drum tester such as a
speedometer tester or chassis dynamometer, etc., or jacking up
the rear wheels and driving the wheels, always push in the TRAC
cut (ºTRAC OFFº) switch and turn the TRAC system OFF.
CONFIRM TRAC SYSTEM IS OFF
1. Press the TRAC cut (ºTRAC OFFº) switch.
2. Check that the TRAC OFF indicator light comes on when the
TRAC system is turned off by the TRAC cut switch.
HINT: The TRAC indicator light should always operate right after
the engine is restarted.
3. Begin measurements.
4. Press the TRAC cut switch again to change the TRAC to operative and check that the TRAC OFF indicator light goes
off.
HINT: The TRAC indicator light blinks when the TRAC system is
operative.
±
INTRODUCTION Precautions for V
ehicles Equipped with Traction Cotnrol
(TRAC)SystemIN±13
