LEXUS SC400 1991 Service Repair Manual (c) Using SST and a press, install the axle hub.SST 09608±32010, 09608±35014 (09608±06020,09608±06100) 4. INSTALL OIL SEAL (INSIDE) (a) Using SST and a hammer, install a new oil seal. SST 0922

Page 3322 of 4087

LEXUS SC400 1991 Service Repair Manual (c) Connect the No. 1 lower suspension arm to the axle carrierwith a new nut. Torque: 59 N Vm (600 kgf Vcm, 43 ft Vlbf) (d) Connect the strut rod to the axle carrier and temporarily install the bo

Page 3323 of 4087

LEXUS SC400 1991 Service Repair Manual (i) Install the 2 bolts. Torque: 7.8 NVm (80 kgf Vcm, 69 in. Vlbf) 2. INSTALL PARKING BRAKE SHOE (See page BR±44) 3. INSTALL ABS SPEED SENSOR Install the sensor to the axle carrier with the bolt

Page 3324 of 4087

LEXUS SC400 1991 Service Repair Manual 7. STABILIZE SUSPENSION (a) Install the rear wheel and lower the vehicle. Torque: 103 NVm (1,050 kgf Vcm, 76 ft Vlbf) (b) Bounce the vehicle up and down several times to stabilize the suspension.

Page 3325 of 4087

LEXUS SC400 1991 Service Repair Manual REAR DRIVE SHAFT DESCRIPTION SA0S2±03 The drive shaft has cross±groove type joints on the differential side and on the wheel side. SA±62± SUSPENSION AND AXLE REAR DRIVE SHAFT WhereEverybodyKnows

Page 3326 of 4087

LEXUS SC400 1991 Service Repair Manual PREPARATION SST (SPECIAL SERVICE TOOLS) SA06B±02 RECOMMENDED TOOLS SA06C±02 EQUIPMENT SA06D±01\   \  \ Torque wrench

Page 3327 of 4087

LEXUS SC400 1991 Service Repair Manual LUBRICANT SA06E±02  Item Capacity Classification    Outboard Joint

Page 3328 of 4087

LEXUS SC400 1991 Service Repair Manual REAR DRIVE SHAFT COMPONENTS SA0W5±01 ± SUSPENSION AND AXLE REAR DRIVE SHAFTSA±65 WhereEverybodyKnowsYourName
