LEXUS SC400 1991 Service Repair Manual 35. DISCONNECT TRANSMISSION CONTROL RODRemove the nut, and disconnect the control rod from the shift lever. 36. REMOVE ENGINE AND TRANSMISSION A SSEMBLY FROM VEHICLE (a) Attach the engine hoist cha

Page 1594 of 4087

LEXUS SC400 1991 Service Repair Manual COMPONENTS FOR SEPARATION AND ASSEMBLY OF ENGINE AND TRANSMISSION SEPARATION OF ENGINE AND TRANSMISSION 1. REMOVE OIL DIPSTICK GUIDE FOR TRANSMISSION(a) Remove the mounting bolt. (b) P u ll ou t t

Page 1595 of 4087

LEXUS SC400 1991 Service Repair Manual 3. DISCONNECT ENGINE WIRE FROM TRANSMISSION(a) Disconnect the following connectors:(1) O/D direct clutch speed sensor connector (2) No.1 speed sensor connector (3) No.2 speed sensor connector (4

Page 1596 of 4087

LEXUS SC400 1991 Service Repair Manual COMPONENTS FOR DISASSEMBLY AND ASSEMBLY OF CYLINDER BLOCK ± ENGINE MECHANICAL Cylinder BlockEM±131 WhereEverybodyKnowsYourName

Page 1597 of 4087

LEXUS SC400 1991 Service Repair Manual PREPARATION FOR DISASSEMBLY (See Components on page EM±131) 1. REMOVE DRIVE PLATE Remove the eight bolts, two spacers and drive plate. 2. INSTALL ENGINE TO ENGINE STAND FOR DISASSEMBLY 3. REMOVE

Page 1598 of 4087

LEXUS SC400 1991 Service Repair Manual (b) Disconnect the wire clamp from the bracket on thestarter. (c) Remove the nut, and disconnect the wire. (d) Disconnect the connector, and remove the starter. 8. REMOVE KNOCK SENSORS (a) Disc

Page 1599 of 4087

LEXUS SC400 1991 Service Repair Manual 11. REMOVE WATER PUMP(a) Remove the five mounting bolt, two mounting stud boltsand mounting nut. (b) Remove the water pump by prying the portions between the water pump and cylinder block with a s

Page 1600 of 4087

LEXUS SC400 1991 Service Repair Manual DISASSEMBLY OF CYLINDER BLOCK (See Components on page EM±131) 1. REMOVE REAR OIL SEAL RETAINER (a) Remove the seven bolts. (b) Remove the oil seal retainer by prying the portions between the oil
