Page 1113 of 4087

LEXUS SC400 1991 Service Repair Manual WIRING DIAGRAM ABS Warning Light Circuit CIRCUIT DESCRIPTION If the ECU detects trouble, it lights the ABS warning light while at the s\ ame time prohibiting ABS control. At this time, the ECU record

Page 1114 of 4087

LEXUS SC400 1991 Service Repair Manual ± BRAKE SYSTEM ANTI±LOCK BRAKE SYSTEM (ABS)BR±145 WhereEverybodyKnowsYourName

Page 1115 of 4087

LEXUS SC400 1991 Service Repair Manual OKNG OKNG INSPECTION PROCEDURE 1Check ABS warning light. See Combination Meter Troubleshooting on page BE±159. Replace bulb or combination meter assembly. 2Check ABS solenoid relay. C OK P OK C Remo

Page 1116 of 4087

LEXUS SC400 1991 Service Repair Manual NOYES YESNO OKNG INSPECTION PROCEDURE 3Is diagnosis trouble code output? Perform diagnostic trouble code check on page BR±76. Repair circuit indicated by the code output. 4Does ABS warning light go

Page 1117 of 4087

LEXUS SC400 1991 Service Repair Manual IN±33). WIRING DIAGRAM Tc Terminal Circuit CIRCUIT DESCRIPTION Connecting between terminals Tc and E1 of the DLC1 or the DLC2 causes the ECU to display the diagnos- tic trouble code by flashing th

Page 1118 of 4087

LEXUS SC400 1991 Service Repair Manual NGOK OKNG INSPECTION PROCEDURE 1Check voltage between terminals Tc and E1 of DLC2 or DLC1. C OK PTurn ignition switch ON. Measure voltage between terminals Tc and E1 of DLC2 or DLC1. Voltage: 10 ± 1

Page 1119 of 4087

LEXUS SC400 1991 Service Repair Manual IN±33 ). WIRING DIAGRAM Ts Terminal Circuit CIRCUIT DESCRIPTION The sensor check circuit detects abnormalities in the speed sensor signal w\ hich can not be detected with the diagnostic trouble cod

Page 1120 of 4087

LEXUS SC400 1991 Service Repair Manual NGOK OKNG INSPECTION PROCEDURE 1Check voltage between terminal Ts and E1 of data link connector 1. C OK PTurn ignition switch ON. Measure voltage between terminals Ts and E1 of DLC1. Voltage: 10 ± 1
