Page 1185 of 4087

LEXUS SC400 1991 Service Repair Manual mm in.30 100 1.18 3.34 FRONT BODY PILLAR (CUT): w/ Moon Roof REMOVAL (With the cowl top side panel removed.) Cut and Join Location [Cut and Join Location] 100 mm 30 mm 30 mm [Cut and Join Location] C

Page 1186 of 4087

LEXUS SC400 1991 Service Repair Manual INSTALLATION BODY PANEL REPLACEMENTRE-29 WhereEverybodyKnowsYourName

Page 1187 of 4087

LEXUS SC400 1991 Service Repair Manual INSTALLATION Butt Weld Inner Pillar Front Body Pillar Upper ReinforcementOuter Pillar Front Body Pillar Lower Reinforcement 1. Before temporarily installing the new outer pillar, weld the front body

Page 1188 of 4087

LEXUS SC400 1991 Service Repair Manual INSTALLATION Butt WeldButt Weld Roof Drip Channel Butt Weld 1. After installing the new parts, apply foamed material. HINT: For the foamed material application areas, refer to AP-4. BODY PANEL REPLA

Page 1189 of 4087

LEXUS SC400 1991 Service Repair Manual ROCKER OUTER PANEL (CUT) REMOVAL Cut and Join Location (Cut Location for Supply Parts)Cut and Join Location (Cut Location for Supply Parts) [Cut and Join Location] [Cut and Join Location] 1. Cut and

Page 1190 of 4087

LEXUS SC400 1991 Service Repair Manual Butt Weld INSTALLATION Butt Weld 1. Temporarily install the new parts and check thefit of the front door. BODY PANEL REPLACEMENTRE-33 WhereEverybodyKnowsYourName

Page 1191 of 4087

LEXUS SC400 1991 Service Repair Manual ROOF PANEL (ASSY): w/o Moon Roof REMOVAL Braze (both sides) 1. Heat the brazed area of the quarter panel andscrape off the brazing with a wire brush. NOTICE: Be careful not to overheat the quarter pa

Page 1192 of 4087

LEXUS SC400 1991 Service Repair Manual INSTALLATION Body Sealer Body Sealer Braze (both sides) 2. Braze the quarter panel connection. NOTICE: Before performing these operations,place a wet rag on the roof panel to protect it fromdamage. 1
