GENERAL INSPECTION
SA19Y±01
1. INSPECT TIRE
(a) Check the tires for wear and for the proper inflation pressure.Cold tire inflation pressure (SC400):
Tire size
Front
kPa (kg/cm2, psi)
Rear
kPa (kg/cm2, psi)
P225/55R16 93V 220 (2.2, 32) 220 (2.2, 32)
Cold tire inflation pressure (SC300):
Tire size
Front
kPa (kg/cm2, psi)
Rear
kPa (kg/cm2, psi)
P215/60R15 94V
210 (2.1, 30)
210 (2.1, 30)
P215/60R15 93V
(b) Check the tire runout.
Tire runout:
SC400 Less then 1.4 mm (0.055 in.)
SC300 Less then 1.0 mm (0.039 in.)
2. ROTATING TIRESNOTICE: The wheel assemblies must be rotated only be-
tween the front and rear.
3. INSPECT WHEEL BALANCE
(a) Check and adjust the Off±the±car balance.
(b) If necessary, check and adjust the On±the±car balance.
Unbalance after adjustment: 8.0 g (0.018 lb) or less
±
SUSPENSION AND AXLE GENERAL INSPECTIONSA±3
