Page 577 of 3924

AV-30
< SERVICE INFORMATION >
AUDIO
*: With satellite radio
Terminal and Reference Value for BOSE Speaker AmpINFOID:0000000001328679
53 (G)* GroundCommunication signal
Rx (SAT-AUDIO) Input ONWhen setting to satellite ra-
dio mode
54 (Y)* Ground Communication signal
Tx (AUDIO-SAT)
Output ONWhen setting to satellite ra-
dio mode
Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Reference value
+– Ignition
switch Operation
SKIB7337E
SKIB7336E
Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Reference value
+– Ignition
switch Operation
1 (R) Ground Battery power supply Input OFF — Battery voltage
9 (LG) 10 (B/Y) Audio signal rear door-
speaker LH
Output ACC Receive audio signal
11 (OR) 12 (B/P) Audio signal rear door
speaker RH Output ACC Receive audio signal
13 (L) 14 (B/W) Audio signal front door
speaker LH
Output ACC Receive audio signal
SKIB3609E
SKIB3609E
SKIB3609E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 578 of 3924
AUDIOAV-31
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
AV
N
O P
15 (BR) 16 (B/R) Audio signal front door
speaker RH Output ACC Receive audio signal
17 (B) Ground Ground — ON — Approx. 0 V
18 (R/L) 2 (B) Audio signal instru-
ment speaker center
Output ACC Receive audio signal
19 (W) 3 (B) Audio signal woofer Output ACC Receive audio signal 20 (G) 4 (G/W) Audio signal tweeter Output ACC Receive audio signal22 (P) Ground Amp ON signal (woof-
er) Output ACC Receive audio signal Approx. 12 V
24 (L) 23 (B/W) Audio signal rear RH Input ACC Receive audio signal
26 (B/R) 25 (BR) Audio signal rear LH Input ACC Receive audio signal Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Reference value
+– Ignition
switch Operation
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
SKIB3609E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 579 of 3924

AV-32
< SERVICE INFORMATION >
AUDIO
Terminal and Reference Va lue for A/C and AV Switch
INFOID:0000000001328680
28 (LG) 27 (PU) Audio signal front RH Input ACC Receive audio signal
30 (W) 29 (B) Audio signal front LH Input ACC Receive audio signal31 (P) Ground BOSE speaker amp.
ON signal Input ACC — Approx. 12 V
Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Reference value
+– Ignition
switch Operation
SKIB3609E
SKIB3609E
Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Reference value
+– Ignition
switch Operation
1 (W/L) Ground Battery power supply Input OFF — Battery voltage 2 (LG) Ground ACC power supply Input ACC — Battery voltage 5 (B) Ground Ground — ON — Approx. 0 V
6 (PU) Ground Communication
signal (+) Input/
Output ON —
7—Shield —— — —
8 (LG) Ground Communication
signal (–) Input/
Output ON —
SKIB7378E
SKIB7379E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 580 of 3924

AUDIOAV-33
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
AV
N
O P
*1: With telephone system
*2: Without telephone system
Terminal and Reference Value for WooferINFOID:0000000001328681
12 (R/W) Ground Steering SW A Input ON Press and hold PTT
*1 switch
Approx. 0 V
Press and hold MODE
*2
switch Approx. 0 V
Press and hold SEEK UP
switch Approx. 1.7 V
Press and hold VOL UP
switch Approx. 3.3 V
Except for above Approx. 5 V
13 (G/W) Ground Steering SW B Input ON Press and hold MODE
*1
switch Approx. 0 V
Press and hold POWER
*2
switch Approx. 0 V
Press and hold SEEK
DOWN switch Approx. 1.7 V
Press and hold VOL DOWN
switch Approx. 3.3 V
Except for above Approx. 5 V
14 (B/Y) Ground Steering SW ground — ON — Approx. 0 V Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Reference value
+– Ignition
switch Operation
Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Voltag e
+– Ignition
switch Operation
1 (G/R) Ground Battery power supply Input OFF — Battery voltage 2 (B) Ground Ground — ON — Approx. 0 V
5 (P) Ground Amp ON signal Input ACC — Approx. 12 V
7 (W) 8 (B) Audio signal woofer Input ACC Receive audio signal
SKIB3609E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 581 of 3924

AV-34
< SERVICE INFORMATION >
AUDIO
Terminal and Reference Valu e for Satellite Radio Tuner
INFOID:0000000001328682
A/C and AV Switch Self-Diagnosis FunctionINFOID:0000000001328683
It can check ON/OFF operation of each switch in the A/C and AV sw itch and diagnose the input signals to the
audio steering wheel switch.
Te r m i n a l
(Wire color) ItemSignal
input/
output Condition
Reference value
+– Ignition
switch Operation
2 (B) 1 (R) Satellite radio audio
signal LH
Output ONReceive satellite radio audio
signal
4 (G) 3 (W) Satellite radio audio
signal RH Output ONReceive satellite radio audio
signal
5—Shield —— — —
6—Shield —— — —
8 (L) Ground Communication signal
REQ (SAT-AUDIO)
Output ONWhen setting to satellite ra-
dio mode
9 (L/R) Ground Communication signal
Tx (SAT-AUDIO) Output ONWhen setting to satellite ra-
dio mode
10 (L/W) Ground Communication signal
Rx (AUDIO-SAT) Input ON
When setting to satellite ra-
dio mode
12 (Y) Ground Battery power supply Input OFF — Battery voltage
15 (B) Ground Ground — ON — Approx. 0 V
16 (P) Ground ACC power supply Input ACC — Battery voltage
17 — Satellite radio antenna — — — —
SKIB3609E
SKIB3609E
SKIB7338E
SKIB7337E
SKIB7336E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 582 of 3924

AUDIOAV-35
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
AV
N
O P
STARTING THE SELF-DIAGNOSIS MODE
1. Turn ignition switch from OFF to ACC.
2. Within 10 seconds press and hold the switches “1” and “6” simultaneously for 3 seconds.
DIAGNOSIS FUNCTION
The following are checked: All the indicators (LED) in the A/C and AV switch.
Continuity of the switches by sounding the buzze r when the A/C and AV switch and audio steering wheel
switch is pressed.
Continuity of harness between A/C and AV switch and audio steering switch.
NOTE:
Rear window defogger switch operation is not checked. (No beep sound even under normal status)
EXITING THE SELF-DIAGNOSIS MODE
Turn ignition switch OFF.
Trouble DiagnosisINFOID:0000000001328684
The majority of the audio malfunctions are the result of outside causes (bad CD, electromagnetic interfer-
ence, etc.). Check the symptoms below to diagnose the malfunction.
The vehicle itself can be a source of noise if noise prevention parts or electrical equipment is malfunctioning.
Check if noise is caused and/or changed by engine speed, ignition switch turned to each position, and oper-
ation of each piece of electrical equipment, and then determine the cause.
Make sure that other operation except audio system can be performed with A/C and AV switch. If these
operations are inoperative with A/C and AV switch, refer to AV-79, "
Unable to Operate System with A/C and
AV Switch" (Without navigation system), or AV-127, "Unable to Operate System with A/C and AV Switch"
(With navigation system).
Refer to "SERVICE BULLETIN ITB04-055" for the diagnosis of satellite radio.
SKIB8660E
Symptom Possible malfunction location
Audio system does not work properly. Audio unit power supply circuit
Communication signal circuit between audio unit and display control unit
A/C and AV switch
Audio unit
No sound can be heard from all speakers. BOSE speaker amp. power supply and ground circuit
BOSE speaker amp. ON signal circuit
Audio unit
BOSE speaker amp.
No sound can be heard from one or several speakers. Audio signal circuit between audio unit and BOSE speaker amp.
Audio signal circuit between BOSE speaker amp. and speaker
Speaker
Tweeter
Audio unit
BOSE speaker amp.
No sound can be heard from woofer. Audio signal circuit between BOSE speaker amp. and woofer
Woofer
BOSE speaker amp.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 583 of 3924

AV-36
< SERVICE INFORMATION >
AUDIO
NOTE:
Noise resulting from variations in field strength, such as fading noise and multi-path noise, or external noise
from trains and other source s. It is not a malfunction.
Fading noise: This noise occurs because of variations in the field strength in a narrow range due to moun- tains or buildings blocking the signal.
Multi-path noise: This noise results from a time di fference between the broadcast waves directly from the
station arriving at the antenna and the waves reflected by mountains or buildings.
Power Supply Circuit InspectionINFOID:0000000001328685
1.CHECK FUSE
Make sure that the following fuses of the BOSE speaker amp., woofer, and audio unit are not blown.
OK or NG
OK >> GO TO 2.
NG >> If fuse is blown, be sure to eliminate caus e of malfunction before installing new fuse. Refer to PG-
3.
2.CHECK POWER SUPPLY CIRCUIT
1. Check voltage between audio unit harness connector terminals and ground.
No sound can be heard from radio or noise is caught. Antenna amp. ON signal circuit
Antenna feeder
Roof antenna
Antenna amp.
Audio unit
Audio steering switch does not operate properly. Remote control signal circuit between audio steering switch and A/C and
AV switch
Audio steering switch
Spiral cable
TEL adapter unit (With telephone system)
A/C and AV switch
Symptom Possible malfunction location
Unit Terminal Signal name Fuse No.
Audio unit 6 Battery power supply 32
10 ACC power supply 6
BOSE speaker amp. 1 Battery power supply 17
Woofer 1 Battery power supply 32
Te r m i n a l s Ignition
switch Vo l ta g e
(+)
(–)
Connector Terminal
M58 6 Ground OFF Battery voltage
10 Ground ACC Battery voltage
PKIA3814E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 584 of 3924

AUDIOAV-37
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
AV
N
O P
2. Check voltage between BOSE speaker amp. harness connector terminal or woofer harness connector terminal and ground.
OK or NG
OK >> INSPECTION END (Audio unit is OK.) GO TO 3. (BOSE speaker amp. and woofer)
NG >> Repair harness or connector between each unit and fuse.
3.CHECK GROUND CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect BOSE speaker amp. and woofer connectors.
3. Check continuity between BOSE speaker amp. harness connec-
tor B212 terminal 17 and ground.
4. Check continuity between woofer harness connector B223 ter- minal 2 and ground.
OK or NG
OK >> INSPECTION END (System is OK.)
NG >> Repair harness or connector.
Audio Steering Wheel Switch InspectionINFOID:0000000001328686
1.CHECK A/C AND AV SWITCH SELF-DIAGNOSIS FUNCTION
1. Start A/C and AV switch self-diagnosis function. Refer to AV-34, "
A/C and AV Switch Self-Diagnosis Func-
tion".
2. Operate audio steering wheel switch.
Does audio steering wheel switch operate normally?
YES >> INSPECTION END
Te r m i n a l s
Ignition
switch Vo l ta g e
(+)
(–)
Connector Terminal
B212 1 Ground OFF Battery voltage
B223 1 Ground OFF Battery voltage
SKIA8931E
17 – Ground : Continuity should exist.
SKIA4312E
2 – Ground : Continuity should exist.
SKIB8692E
