Page 1529 of 3924
![INFINITI FX35 2008 Service Manual
DTC P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
EC-289
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
: Average voltage for pulse signal (Actual pulse signal can be confirmed by osc INFINITI FX35 2008 Service Manual
DTC P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
EC-289
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
: Average voltage for pulse signal (Actual pulse signal can be confirmed by osc](/manual-img/42/57017/w960_57017-1528.png)
DTC P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
EC-289
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
: Average voltage for pulse signal (Actual pulse signal can be confirmed by oscilloscope.)
Diagnosis ProcedureINFOID:0000000001326108
1.CHECK EXHAUST GAS LEAK
1. Start engine and run it at idle.
2. Listen for an exhaust gas leak before three way catalyst 1.
OK or NG
OK >> GO TO 2.
NG >> Repair or replace.
2.CHECK FOR INTAKE AIR LEAK
TER- MI-
NAL
NO. WIRE
COLOR ITEM CONDITION DATA (DC Voltage)
24 L A/F sensor 1 heater
(bank 2) [Engine is running]
Warm-up condition
Idle speed Approximately 5V
40
41
42 LG
B
P Fuel injector No. 6
Fuel injector No. 4
Fuel injector No. 2 [Engine is running]
Warm-up condition
Idle speed NOTE:
The pulse cycle changes depending on rpm
at idle BATTERY VOLTAGE
(11 - 14V)
[Engine is running]
Warm-up condition
Engine speed: 2,000 rpm BATTERY VOLTAGE
(11 - 14V)
57 G A/F sensor 1 (bank 2) [Engine is running]
Warm-up condition
Idle speed Approximately 2.6V
58 Y Approximately 2.3V
76 P Approximately 3.1V
77 BR Approximately 2.3V
PBIB1584E
SEC984C
SEC985C
PBIB1922E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1530 of 3924
![INFINITI FX35 2008 Service Manual
EC-290
< SERVICE INFORMATION >[VQ35DE]
DTC P0172, P0175 FUEL IN
JECTION SYSTEM FUNCTION
Listen for an intake air leak after the mass air flow sensor.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace. INFINITI FX35 2008 Service Manual
EC-290
< SERVICE INFORMATION >[VQ35DE]
DTC P0172, P0175 FUEL IN
JECTION SYSTEM FUNCTION
Listen for an intake air leak after the mass air flow sensor.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace.](/manual-img/42/57017/w960_57017-1529.png)
EC-290
< SERVICE INFORMATION >[VQ35DE]
DTC P0172, P0175 FUEL IN
JECTION SYSTEM FUNCTION
Listen for an intake air leak after the mass air flow sensor.
OK or NG
OK >> GO TO 3.
NG >> Repair or replace.
3.CHECK AIR FUEL RATIO (A/F) SE NSOR 1 INPUT SIGNAL CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect corresponding A/F sensor 1 harness connector.
3. Disconnect ECM harness connector.
4. Check harness continuity between the following terminals. Refer to Wiring Diagram.
5. Check harness continuity between the following terminals and ground. Refer to Wiring Diagram.
6. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 4.
NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4.CHECK FUEL PRESSURE
1. Release fuel pressure to zero. Refer to EC-87, "
Fuel Pressure Check".
2. Install fuel pressure gauge and check fuel pressure. Refer to EC-87, "
Fuel Pressure Check".
Bank 1A/F sensor 1 terminal ECM terminal
116
275
535
656
Bank 2 176
277
557
658
Continuity should exist.
Bank 1 Bank 2
A/F sensor 1 terminal ECM terminal A/F sensor 1 terminal ECM terminal 116176
275277
535557
656658
Continuity should not exist.
PBIB2190E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1531 of 3924
![INFINITI FX35 2008 Service Manual
DTC P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
EC-291
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the f INFINITI FX35 2008 Service Manual
DTC P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
EC-291
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the f](/manual-img/42/57017/w960_57017-1530.png)
DTC P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
EC-291
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
OK or NG
OK >> GO TO 6.
NG >> GO TO 5.
5.DETECT MALFUNCTIONING PART
Check the following.
Fuel pump and circuit (Refer to EC-558
.)
Fuel pressure regulator (Refer to EC-87, "
Fuel Pressure Check".)
>> Repair or replace.
6.CHECK MASS AIR FLOW SENSOR
With CONSULT-III
1. Install all removed parts.
2. Check “MASS AIR FLOW” in “DATA MONITOR” mode with CONSULT-III.
With GST
1. Install all removed parts.
2. Check mass air flow sensor signal in Service $01 with GST.
OK or NG
OK (With CONSULT-III)>>GO TO 7.
OK (Without CONSULT-III)>>GO TO 8.
NG >> Check connectors for rusted terminals or loose c onnections in the mass air flow sensor circuit or
ground. Refer to EC-175
.
7.CHECK FUNCTION OF FUEL INJECTOR
With CONSULT-III
1. Start engine.
2. Perform “POWER BALANCE” in “A CTIVE TEST” mode with CONSULT-III.
3. Make sure that each circuit produces a momentary engine speed drop.
OK or NG
OK >> GO TO 10.
NG >> Perform trouble diagnosis for FUEL INJECTOR, refer to EC-552
.
8.CHECK FUNCTION OF FUEL INJECTOR-I
Without CONSULT-III
1. Stop engine.
2. Disconnect harness connector F50, F251
3. Turn ignition switch ON. At idling: Approximately 350 kPa (3.57 kg/cm
2, 51 psi)
2.0 - 6.0 g·m/sec: at idling
7.0 - 20.0 g·m/sec: at 2,500 rpm
2.0 - 6.0 g·m/sec: at idling
7.0 - 20.0 g·m/sec: at 2,500 rpm
PBIB2624E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1532 of 3924
![INFINITI FX35 2008 Service Manual
EC-292
< SERVICE INFORMATION >[VQ35DE]
DTC P0172, P0175 FUEL IN
JECTION SYSTEM FUNCTION
4. Check voltage between harness connector F50 terminal 5 and
ground.
5. Turn ignition switch OFF.
6. Disconnec INFINITI FX35 2008 Service Manual
EC-292
< SERVICE INFORMATION >[VQ35DE]
DTC P0172, P0175 FUEL IN
JECTION SYSTEM FUNCTION
4. Check voltage between harness connector F50 terminal 5 and
ground.
5. Turn ignition switch OFF.
6. Disconnec](/manual-img/42/57017/w960_57017-1531.png)
EC-292
< SERVICE INFORMATION >[VQ35DE]
DTC P0172, P0175 FUEL IN
JECTION SYSTEM FUNCTION
4. Check voltage between harness connector F50 terminal 5 and
ground.
5. Turn ignition switch OFF.
6. Disconnect ECM harness connector.
7. Check harness continuity between harness connector F50 and ECM as follows.
Refer to Wiring Diagram.
8. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 9.
NG >> Perform trouble diagnosis for FUEL INJECTOR, refer to EC-552
.
9.CHECK FUNCTION OF FUEL INJECTOR-II
Provide battery voltage between harness connector F251 as follows
and then interrupt it. Listen to each fuel injector operating sound.
OK or NG
OK >> GO TO 10.
NG >> Perform trouble diagnosis for FUEL INJECTOR, refer to EC-552
.
10.CHECK FUEL INJECTOR
1. Remove fuel injector assembly. Refer to EM-45
.
Keep fuel hose and all fuel injectors connected to fuel injector gallery.
2. Confirm that the engine is cooled down and there are no fire hazards near the vehicle.
3. Reconnect all harness connectors disconnected.
4. Disconnect all fuel injector harness connectors.
5. Disconnect all ignition coil harness connectors.
6. Prepare pans or saucers under each fuel injectors.
7. Crank engine for about 3 seconds.
Make sure fuel does not drip from fuel injector.Voltage: Battery voltage
Cylinder
Harness connector F50
terminal ECM terminal
1623
2442
3222
4341
5121
6740
Continuity should exist.
PBIB2323E
Cylinder Harness connector F251 terminal
(+) (–)
1
56
24
32
43
51
67
Operating sound should exist.
PBIB2497E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1533 of 3924
DTC P0172, P0175 FUEL INJECTION SYSTEM FUNCTION
EC-293
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
OK or NG
OK (Does not drip.)>>GO TO 11.
NG (Drips.)>>Replace the fuel injectors from which
fuel is dripping. Always replace O-ring with new one.
11 .CHECK INTERMITTENT INCIDENT
Refer to EC-139
.
>> INSPECTION END
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1534 of 3924
![INFINITI FX35 2008 Service Manual
EC-294
< SERVICE INFORMATION >[VQ35DE]
DTC P0181 FTT SENSOR
DTC P0181 FTT SENSOR
Component DescriptionINFOID:0000000001326109
The fuel tank temperature (FTT)
sensor is used to detect the fuel
temper INFINITI FX35 2008 Service Manual
EC-294
< SERVICE INFORMATION >[VQ35DE]
DTC P0181 FTT SENSOR
DTC P0181 FTT SENSOR
Component DescriptionINFOID:0000000001326109
The fuel tank temperature (FTT)
sensor is used to detect the fuel
temper](/manual-img/42/57017/w960_57017-1533.png)
EC-294
< SERVICE INFORMATION >[VQ35DE]
DTC P0181 FTT SENSOR
DTC P0181 FTT SENSOR
Component DescriptionINFOID:0000000001326109
The fuel tank temperature (FTT)
sensor is used to detect the fuel
temperature inside the fuel tank. The sensor modifies a voltage sig-
nal from the ECM. The modified signal returns to the ECM as the
fuel temperature input. The sensor uses a thermistor which is sensi-
tive to the change in temperature. The electrical resistance of the
thermistor decreases as temperature increases.
*: This data is reference values and is measured between ECM terminal 107 (fuel
tank temperature sensor) and ground.
CAUTION:
Do not use ECM ground terminals when measuring input/output
voltage. Doing so may result in damage to the ECM's transistor.
Use a ground other than ECM terminals, such as the ground.
On Board Diagnosis LogicINFOID:0000000001326110
DTC Confirmation ProcedureINFOID:0000000001326111
NOTE:
If DTC Confirmation Procedure has been previously conduc ted, always turn ignition switch OFF and wait at
least 10 seconds before conducting the next test.
WITH CONSULT-III
1. Turn ignition switch ON and wait at least 10 seconds.
2. Wait at least 10 seconds. If 1st trip DTC is detected, go to EC-296, "
Diagnosis Procedure".
If 1st trip DTC is not det ected, go to following step.
3. Select “DATA MONITOR” mode with CONSULT-III.
4. Check “COOLAN TEMP/S” value. If “COOLAN TEMP/S” is less than 60 °C (140 °F), the result will be OK.
If “COOLAN TEMP/S” is above 60 °C (140 °F), go to the following step.
5. Cool engine down until “COOLAN TEMP/S” is less than 60 °C (140 °F).
6. Wait at least 10 seconds.
7. Check 1st trip DTC.
PBIB1572E
Fluid temperature °C ( °F) Voltage*
V Resistance
kΩ
20 (68) 3.5 2.3 - 2.7
50 (122) 2.2 0.79 - 0.90
SEF012P
DTC No. Trouble diagnosis name DTC detecting condition Possible cause
P0181
0181 Fuel tank temperature
sensor circuit range/per-
formance Rationally incorrect voltage from the sensor is
sent to ECM, compared with the voltage signals
from engine coolant temperature sensor and in-
take air temperature sensor. Harness or connectors
(Fuel tank temperature sensor circuit is
open or shorted)
Fuel tank temperature sensor
Unified meter and A/C amp.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1535 of 3924
DTC P0181 FTT SENSOREC-295
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
8. If 1st trip DTC is detected, go to
EC-296, "Diagnosis Procedure".
WITH GST
Follow the procedure “WITH CONSULT-III” above.
Wiring DiagramINFOID:0000000001326112
TBWM1386E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 1536 of 3924
![INFINITI FX35 2008 Service Manual
EC-296
< SERVICE INFORMATION >[VQ35DE]
DTC P0181 FTT SENSOR
Diagnosis Procedure
INFOID:0000000001326113
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Loosen and retighten ground screw on INFINITI FX35 2008 Service Manual
EC-296
< SERVICE INFORMATION >[VQ35DE]
DTC P0181 FTT SENSOR
Diagnosis Procedure
INFOID:0000000001326113
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Loosen and retighten ground screw on](/manual-img/42/57017/w960_57017-1535.png)
EC-296
< SERVICE INFORMATION >[VQ35DE]
DTC P0181 FTT SENSOR
Diagnosis Procedure
INFOID:0000000001326113
1.CHECK GROUND CONNECTIONS
1. Turn ignition switch OFF.
2. Loosen and retighten ground screw on the body. Refer to EC-144, "
Ground Inspection".
OK or NG
OK >> GO TO 2.
NG >> Repair or replace ground connections.
2.CHECK DTC WITH “UNIFIED METER AND A/C AMP.”
Refer to DI-27, "
CONSULT-III Function (METER/M&A)".
OK or NG
OK >> GO TO 3.
NG >> Go to DI-19, "
Fuel Level Sensor Signal Inspection".
3.CHECK FUEL TANK TEMPERATURE SENSOR POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect “fuel level sensor unit and fuel pump” harness con- nector.
3. Turn ignition switch ON.
4. Check voltage between “fuel level sensor unit and fuel pump” terminal 4 and ground with CONSULT-III or tester.
OK or NG
OK >> GO TO 5.
NG >> GO TO 4.
4.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors B1, M11
Harness for open or short between ECM and “fuel level sensor unit and fuel pump”
>> Repair open circuit or short to ground or short to power in harness or connector.
PBIB2625E
PBIB1572E
Voltage: Approximately 5V
PBIB0932E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
