Page 3921 of 3924

INFINITI FX35 2008 Service Manual WW-46 < SERVICE INFORMATION > POWER SOCKET 1. Remove A/T console finisher. Refer to IP-10, "Component Parts Location". 2. Remove instrument clock finisher. Refer to IP-10, " Component Parts Location

Page 3922 of 3924

INFINITI FX35 2008 Service Manual POWER SOCKETWW-47 < SERVICE INFORMATION > C DE F G H I J L M A B WW N O P 1. Remove inner socket from the ring. While pressing the hook on the ring out from square hole. 2. Remove ring from power soc

Page 3923 of 3924

INFINITI FX35 2008 Service Manual WW-48 < SERVICE INFORMATION > HORN HORN Wiring Diagram - HORN -INFOID:0000000001328605 Removal and InstallationINFOID:0000000001328606 REMOVAL 1. Remove front grille. Refer to EI-22, "Component Parts

Page 3924 of 3924

INFINITI FX35 2008 Service Manual HORN WW-49 < SERVICE INFORMATION > C D E F G H I J L M A B WW N O P 2. Disconnect all horn connectors. 3. Remove horn mounting bolt and remove horn from vehicle. INSTALLATION Installation is the reve
