ATC-100
< SERVICE INFORMATION >
IN-VEHICLE SENSOR
IN-VEHICLE SENSOR
Removal and InstallationINFOID:0000000001328203
REMOVAL
1. Remove instrument driver lower panel. Refer to IP-10.
2. Remove mounting screw, and then remove in-vehicle sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2036E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 506 of 3924
SUNLOAD SENSORATC-101
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
SUNLOAD SENSOR
Removal and InstallationINFOID:0000000001328204
REMOVAL
1. Remove front defroster grille (RH). Refer to IP-10.
2. Disconnect sunload sensor connector, and then remove the sunload sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2026E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 507 of 3924

ATC-102
< SERVICE INFORMATION >
INTAKE SENSOR
INTAKE SENSOR
Removal and InstallationINFOID:0000000001328205
REMOVAL
1. Remove low-pressure pipe 2 and high-pressure pipe 3. Refer to ATC-133, "Removal and Installation of
Low-Pressure Pipe 2 and High-pressure Pipe 3".
CAUTION:
Cap or wrap the joint of evaporator, low-pressure pipe 1 and high-pressure pipe 2 with suitable
material such as vinyl tape to avoid the entry of air.
2. Slide evaporator to passenger side, and then remove intake sensor.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Replace O-rings of low-pressure pipe 1, 2 and high-p ressure pipe 2, 3 with new ones, and then apply
compressor oil to it when installing it.
Mark the mounting position of intake sensor bracket prior to removal so that the reinstalled sensor
can be located in the same position.
Female-side piping connection is thin and easy to deform. Slowly insert the male-side piping
straight in axial direction.
Insert piping securely until a click is heard.
After piping connection is comp leted, pull male-side piping by hand to make sure that connection
does not come loose.
When recharging refrigerant, check for leaks.
RJIA0928E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 508 of 3924
BLOWER UNITATC-103
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
BLOWER UNIT
Removal and InstallationINFOID:0000000001328206
REMOVAL
1. Remove instrument passenger lower panel. Refer to IP-10.
2. Remove mounting nut, and then remove ECM with bracket attached.
3. Disconnect intake door motor connector and blower fan motor connector.
4. Remove harness clip from blower unit.
5. Remove mounting bolt and screws from blower unit. CAUTION:
Move blower unit rightward, and remove locating pin (1
part) and joint. Then remove blower unit downward.
6. Remove blower unit.
INSTALLATION
Installation is basically the reverse order of removal.
CAUTION:
Make sure locating pin (1 part) and joint are securely inserted.
RJIA2039E
RJIA0943E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 509 of 3924
ATC-104
< SERVICE INFORMATION >
BLOWER UNIT
Disassembly and Assembly
INFOID:0000000001328207
1. Adapter 2. Intake upper case 3. Filter cover
4. In-cabin microfilter 5. Intake lower case 6. Blower motor assembly
7. Motor cover 8. Intake door lever 2 9. Intake door motor
10. Intake door link 11. Intake door lever 3 12. Intake door 2
13. Intake door lever 1 14. Intake door 1 15. Intake bell mouth
SJIA0420E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 510 of 3924
BLOWER MOTORATC-105
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
BLOWER MOTOR
Removal and InstallationINFOID:0000000001328208
REMOVAL
1. Remove instrument lower cover. Refer to IP-10.
2. Disconnect blower motor connector.
3. Remove mounting screws, and then remove blower motor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2239E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 511 of 3924
ATC-106
< SERVICE INFORMATION >
INTAKE DOOR MOTOR
INTAKE DOOR MOTOR
Removal and InstallationINFOID:0000000001328209
REMOVAL
1. Remove blower unit. Refer to ATC-103.
2. Remove mounting screws, and then remove intake door motor from blower unit.
