Page 2825 of 3924

INFINITI FX35 2008 Service Manual FFD-34 < SERVICE INFORMATION > FRONT FINAL DRIVE ASSEMBLY 10. Install companion flange (1).NOTE: When reusing drive pinion, align the matching mark (B) of drive pinion with the matching mark (A) of c

Page 2826 of 3924

INFINITI FX35 2008 Service Manual FRONT FINAL DRIVE ASSEMBLYFFD-35 < SERVICE INFORMATION > CEF G H I J K L M A B FFD N O P 2. Install side gears and thrust washers into differential case. CAUTION:  Never reuse circular clip.  Make

Page 2827 of 3924

INFINITI FX35 2008 Service Manual FFD-36 < SERVICE INFORMATION > FRONT FINAL DRIVE ASSEMBLY 9. Install drive gear on the mounting bolts, and then tighten to thespecified torque. Refer to "COMPONENTS (VQ35DE MOD- ELS)", "COMPONENTS (V

Page 2828 of 3924

INFINITI FX35 2008 Service Manual FRONT FINAL DRIVE ASSEMBLYFFD-37 < SERVICE INFORMATION > CEF G H I J K L M A B FFD N O P 15. Install selected side bearing adjusting shim (1). 16. Apply multi-purpose grease to O-ring (2), and instal

Page 2829 of 3924

INFINITI FX35 2008 Service Manual FFD-38 < SERVICE INFORMATION > FRONT FINAL DRIVE ASSEMBLY 23. Apply sealant to mating surface of carrier cover.Use Genuine Silicone RTV or equivalent. Refer to GI-44, "Recommended Chemical Product

Page 2830 of 3924

INFINITI FX35 2008 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) FFD-39 < SERVICE INFORMATION > C EF G H I J K L M A B FFD N O P SERVICE DATA AND SPECIFICATIONS (SDS) General SpecificationINFOID:0000000001327488 Inspection and

Page 2831 of 3924

INFINITI FX35 2008 Service Manual FFD-40 < SERVICE INFORMATION > SERVICE DATA AND SPECIFICATIONS (SDS) Unit: mm (in) *: Always check with the Parts Department for the latest parts information. Pinion Height Adjusting Washer Unit: mm

Page 2832 of 3924

INFINITI FX35 2008 Service Manual SERVICE DATA AND SPECIFICATIONS (SDS) FFD-41 < SERVICE INFORMATION > C EF G H I J K L M A B FFD N O P Unit: mm (in) *: Always check with the Parts Department for the latest parts information. Thickne
