Page 497 of 3924

ATC-92
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
SYMPTOM: Sunload sensor circuit is open or shorted. (25 or −25 is
indicated on unified meter and A/C amp. as a result of performing
self-diagnosis STEP-2.)
1.CHECK VOLTAGE BETWEEN S UNLOAD SENSOR AND GROUND
1. Disconnect sunload sensor connector.
2. Turn ignition switch ON.
3. Check voltage between sunload sensor harness connector M87 terminal 1 and ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 4.
2.CHECK CIRCUIT CONTINUITY BETWEEN SUNLOAD SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between sunload sensor harness connector M87 terminal 2 and unified meter and A/C amp. harness con-
nector M57 terminal 49.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3.CHECK SUNLOAD SENSOR
1. Reconnect sunload sensor connector and unified meter and A/C amp. connector.
2. Refer to "Sunload Sensor".
OK or NG
OK >> 1. Replace unified meter and A/C amp. 2. Go to self-diagnosis ATC-43, "
Self-Diagnosis Function" and perform self-diagnosis STEP-2.
Confirm that code No. 20 is displayed.
NG >> 1. Replace sunload sensor. 2. Go to self-diagnosis ATC-43, "
Self-Diagnosis Function" and perform self-diagnosis STEP-2.
Confirm that code No. 20 is displayed.
4.CHECK CIRCUIT CONTINUITY BETWEEN SUNLOAD SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
RJIA1455E
1 – Ground : Approx. 5 V
RJIA2027E
2 – 49 : Continuity should exist.
RJIA2028E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 498 of 3924
TROUBLE DIAGNOSISATC-93
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
3. Check continuity between sunload sensor harness connector M87 terminal 1 and unified meter and A/C amp. harness con-
nector M57 terminal 50.
4. Check continuity between sunload sensor harness connector M87 terminal 1 and ground.
OK or NG
OK >> 1. Replace unified meter and A/C amp. 2. Go to self-diagnosis ATC-43, "
Self-Diagnosis Function" and perform self-diagnosis STEP-2.
Confirm that code No. 20 is displayed.
NG >> Repair harness or connector.
COMPONENT INSPECTION
Sunload Sensor
Measure voltage between unified meter and A/C amp. harness con-
nector M57 terminal 50 and ground. 1 – 50 : Continuity should exist.
1 – Ground : Continuity should not exist.
RJIA2029E
RJIA2030E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 499 of 3924
ATC-94
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
When checking sunload sensor, select a place where sunshine directly on it.
If NG, replace sunload sensor.
Intake Sensor CircuitINFOID:0000000001328199
COMPONENT DESCRIPTION
Intake Sensor
The intake sensor is located on t he heater & cooling unit assembly. It
converts temperature of air after it passes through the evaporator
into a resistance value which is then input to the unified meter and A/
C amp.
DIAGNOSIS PROCEDURE FOR INTAKE SENSOR
SYMPTOM: Intake sensor circuit is open or shorted. (24 or −24 is
indicated on unified meter and A/C amp. as a result of performing
self-diagnosis STEP-2.)
1.CHECK VOLTAGE BETWEEN IN TAKE SENSOR AND GROUND
1. Disconnect intake sensor connector.
2. Turn ignition switch ON.
SHA930E
RJIA0928E
RJIA1458E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 500 of 3924

TROUBLE DIAGNOSISATC-95
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
3. Check voltage between intake sensor harness connector M254 terminal 2 and ground.
OK or NG
OK >> GO TO 2.
NG >> GO TO 4.
2.CHECK CIRCUIT CONTINUITY BETWEEN INTAKE SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between intake sensor harness connector M254 terminal 1 and unified meter and A/C amp. harness con-
nector M57 terminal 49.
OK or NG
OK >> GO TO 3.
NG >> Repair harness or connector.
3.CHECK INTAKE SENSOR
Refer to "Intake Sensor".
OK or NG
OK >> 1. Replace unified meter and A/C amp. 2. Go to self-diagnosis ATC-43, "
Self-Diagnosis Function" and perform self-diagnosis STEP-2.
Confirm that code No. 20 is displayed.
NG >> 1. Replace intake sensor. 2. Go to self-diagnosis ATC-43, "
Self-Diagnosis Function" and perform self-diagnosis STEP-2.
Confirm that code No. 20 is displayed.
4.CHECK CIRCUIT CONTINUITY BETWEEN INTAKE SENSOR AND UNIFIED METER AND A/C AMP.
1. Turn ignition switch OFF.
2. Disconnect unified meter and A/C amp. connector.
3. Check continuity between intake sensor harness connector M254 terminal 2 and unified meter and A/C amp. harness con-
nector M57 terminal 41.
4. Check continuity between intake sensor harness connector M254 terminal 2 and ground.
OK or NG
OK >> 1. Replace unified meter and A/C amp. 2. Go to self-diagnosis ATC-43, "
Self-Diagnosis Function" and perform self-diagnosis STEP-2.
Confirm that code No. 20 is displayed.
NG >> Repair harness or connector.
COMPONENT INSPECTION
Intake Sensor
2 – Ground : Approx. 5 V
RJIA2031E
1 – 49 : Continuity should exist.
RJIA2032E
2 – 41 : Continuity should exist.
2 – Ground : Continuity should not exist.
RJIA2033E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 501 of 3924
ATC-96
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
After disconnecting intake sensor connector M254, measure resis-
tance between terminals 1 and 2 at sensor side. Refer to the table
below.
If NG, replace intake sensor.
Temperature °C ( °F) Resistance k Ω
− 15 (5) 12.34
− 10 (14) 9.62
− 5 (23) 7.56
0 (32) 6.00
5 (41) 4.80
10 (50) 3.87
15 (59) 3.15
20 (68) 2.57
25 (77) 2.12
30 (86) 1.76
35 (95) 1.47
40 (104) 1.23 45 (113) 1.04
RJIA2034E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 502 of 3924
CONTROLLERATC-97
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
CONTROLLER
Removal and Installation of A/C and AV SwitchINFOID:0000000001328200
REMOVAL
Refer to AV-42, "Removal and Installation for A/C and AV Switch".
INSTALLATION
Installation is basically the reverse order of removal.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 503 of 3924
ATC-98
< SERVICE INFORMATION >
AUTO AMP
AUTO AMP
Removal and Installation of Unified Meter and A/C AmpINFOID:0000000001328201
REMOVAL
1. Remove audio unit. Refer to AV-41, "Removal and Installation of Audio Unit".
2. Remove mounting screws, and then remove unified meter and A/C amp.
INSTALLATION
Installation is basically the reverse order of removal.
SJIA1603E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 504 of 3924
AMBIENT SENSORATC-99
< SERVICE INFORMATION >
C
DE
F
G H
I
K L
M A
B
AT C
N
O P
AMBIENT SENSOR
Removal and InstallationINFOID:0000000001328202
REMOVAL
1. Remove front grille. Refer to EI-22.
2. Disconnect ambient sensor c onnector, and then remove ambi-
ent sensor.
INSTALLATION
Installation is basically the reverse order of removal.
RJIA2016E
