DTC P1572 ASCD BRAKE SWITCHEC-1073
< SERVICE INFORMATION > [VK45DE]
C
D
E
F
G H
I
J
K L
M A
EC
NP
O
6.DETECT MALFUNCTIONING PART
Check the following.
Harness connectors E211, M41
Harness for open or short between ECM and ASCD brake switch
>> Repair open circuit or short to ground or short to power in harness or connectors.
7.CHECK ASCD BRAKE SWITCH
Refer to EC-1074, "
Component Inspection"
OK or NG
OK >> GO TO 13.
NG >> Replace ASCD brake switch.
8.CHECK STOP LAMP SWIT CH POWER SUPPLY CIRCUIT
1. Turn ignition switch OFF.
2. Disconnect stop lamp switch harness connector.
3. Check voltage between stop lamp switch terminal 1 and ground with CONSULT-III or tester.
OK or NG
OK >> GO TO 10.
NG >> GO TO 9.
9.DETECT MALFUNCTIONING PART
Check the following.
Fuse block (J/B) connector E201
10A fuse
Harness for open or short between stop lamp switch and battery
>> Repair open circuit or short to ground or short to power in harness or connectors.
10.CHECK STOP LAMP SWITCH INPUT SI GNAL CIRCUIT FOR OPEN AND SHORT
1. Disconnect ECM harness connector.
2. Check harness continuity between ECM terminal 101 and stop lamp switch terminal 2. Refer to Wiring Diagram.
3. Also check harness for short to ground and short to power.
OK or NG
OK >> GO TO 12.
PBIB2558E
Voltage: Battery voltage
PBIB1184E
Continuity should exist.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2314 of 3924
![INFINITI FX35 2008 Service Manual
EC-1074
< SERVICE INFORMATION >[VK45DE]
DTC P1572 ASCD BRAKE SWITCH
NG >> GO TO 11.
11 .DETECT MALFUNCTIONING PART
Check the following.
Harness connectors E211, M41
Harness for open or short betw INFINITI FX35 2008 Service Manual
EC-1074
< SERVICE INFORMATION >[VK45DE]
DTC P1572 ASCD BRAKE SWITCH
NG >> GO TO 11.
11 .DETECT MALFUNCTIONING PART
Check the following.
Harness connectors E211, M41
Harness for open or short betw](/manual-img/42/57017/w960_57017-2313.png)
EC-1074
< SERVICE INFORMATION >[VK45DE]
DTC P1572 ASCD BRAKE SWITCH
NG >> GO TO 11.
11 .DETECT MALFUNCTIONING PART
Check the following.
Harness connectors E211, M41
Harness for open or short between ECM and stop lamp switch
>> Repair open circuit or short to ground or short to power in harness or connectors.
12.CHECK STOP LAMP SWITCH
Refer to EC-1074, "
Component Inspection"
OK or NG
OK >> GO TO 13.
NG >> Replace stop lamp switch.
13.CHECK INTERMITTENT INCIDENT
Refer to EC-717
.
>> INSPECTION END
Component InspectionINFOID:0000000001326948
