2008 INFINITI FX35 Service Manual

boot catalytic converter infotainment ECO mode sensor brakes

Page 3689 of 3924

INFINITI FX35 2008 Service Manual
SE-50
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
2.CHECK FUNCTION
With CONSULT-III
Check operation with “TILT MOTOR” in ACTIVE TEST.
OK or NG
OK >> Steering tilt motor circuit is OK.
NG

SE-50
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
2.CHECK FUNCTION
With CONSULT-III
Check operation with “TILT MOTOR” in ACTIVE TEST.
OK or NG
OK >> Steering tilt motor circuit is OK.
NG >> GO TO 3.
3.CHECK TILT MOTOR CIRCUIT HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control uni t connector and tilt and telescopic motor connector.
3. Check continuity between automat ic drive positioner control unit
connector M50 terminals 35, 42 and tilt and telescopic motor
connector M27 terminals 1, 2.
4. Check continuity between automat ic drive positioner control unit
connector M50 terminals 35, 42 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness between automatic dr ive positioner control unit and tilt and telescopic
motor.
4.CHECK BCM OUTPUT SIGNAL
1. Connect automatic drive positioner control unit connector and tilt and telescopic motor connector.
2. Tilt switch operate, check voltage between automat ic drive positioner control unit connector and ground.
OK or NG
OK >> Replace tilt and telescopic motor.
NG >> Replace automatic drive positioner control unit.
Check Driver Side Mirror Motor CircuitINFOID:0000000001328117
1.CHECK DOOR MIRROR FUNCTION
Check the following.
Operation malfunction caused by a foreign object caught in door mirror face edge.
OK or NG
OK >> GO TO 2 (With CONSULT-III). GO TO 3 (Without CONSULT-III).
NG >> Repair the malfunctioning parts, and check the symptom again.
Te s t i t e m D e s c r i p t i o n
TILT MOTOR The tilt motor is activated by receiving the drive signal.
35 (R/L) – 1 (R/L) : Co ntinuity should exist.
42 (R/B) – 2 (R/B) : Continuity should exist.
35 (R/L) – Ground : Continuity should not exist.
42 (R/B) – Ground : Continuity should not exist.
PIIA5065E
Connector Te r m i n a l s
(Wire color) Tilt switch condition Voltage (V)
(Approx.)
(+) (–)
M50 35 (R/L)
GroundUP Battery voltage
Other than above 0
42 (R/B) DOWN Battery voltage
Other than above 0
PIIA5067E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 3690 of 3924

INFINITI FX35 2008 Service Manual
AUTOMATIC DRIVE POSITIONERSE-51
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
2.CHECK MIRROR MOTOR
With CONSULT-III
Check the operation with “MIRROR MO TOR LH” in the ACTIVE TEST.
OK o

AUTOMATIC DRIVE POSITIONERSE-51
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
2.CHECK MIRROR MOTOR
With CONSULT-III
Check the operation with “MIRROR MO TOR LH” in the ACTIVE TEST.
OK or NG
OK >> Driver side mirror motor circuit is OK.
NG >> GO TO 3.
3.CHECK DOOR MIRROR MOTOR (DRI VER SIDE) HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control uni t connector and door mirror (driver side) connector.
3. Check continuity between automat ic drive positioner control unit
connector M49 terminal 16, 31, 32 and door mirror (driver side)
connector D2 terminal 11, 12, 13.
4. Check continuity between automat ic drive positioner control unit
connector M49 terminal 16, 31, 32 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness between automatic dr ive positioner control unit and door mirror (driver
side).
4.CHECK MIRROR MOTOR SIGNAL
1. Connect automatic drive positioner contro l unit and door mirror (driver side) connector.
2. Turn ignition switch ACC.
3. Turn changeover switch LH position.
4. Mirror switch operate, check voltage betw een door mirror (driver side) connector and ground.
OK or NG
OK >> Replace door mirror motor (driver side).
NG >> Check the condition of the harness and the connector.
Test item Description
MIRROR MOTOR LH The LH mirror motor move
s the mirror UP/DOWN and
LEFT/RIGHT by receiving the drive signal.
16 (P) – 13 (P) : Continuity should exist.
31 (R/W) – 11 (GY) : Continuity should exist.
32 (G/B) – 12 (PU) : Continuity should exist.
16 (P) – Ground : Continuity should not exist.
31 (R/W) – Ground : Continuity should not exist.
32 (G/B) – Ground : Continuity should not exist.
PIIB8581E
Connector Te r m i n a l s
(Wire color) Mirror switch condition Voltage (V)
(Approx.)
(+) (–)
D2 11 ( G Y )
Ground UP Battery voltage
Other than above 0
12 (PU) LEFT Battery voltage
Other than above 0
13 (P) DOWN or RIGHT Battery voltage
Other than above 0
PIIB8582E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 3691 of 3924

INFINITI FX35 2008 Service Manual
SE-52
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
Check Passenger Side Mirror Motor Circuit
INFOID:0000000001328118
1.CHECK DOOR MIRROR FUNCTION
Check the following.
Operation malfunction cau

SE-52
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
Check Passenger Side Mirror Motor Circuit
INFOID:0000000001328118
1.CHECK DOOR MIRROR FUNCTION
Check the following.
Operation malfunction caused by a foreign object caught in door mirror face edge.
OK or NG
OK >> GO TO 2 (With CONSULT-III). GO TO 3 (WIthout CONSULT-III).
NG >> Repair the malfunctioning parts, and check the symptom again.
2.CHECK MIRROR MOTOR
With CONSULT-III
Check the operation with “MIRROR MOTOR RH” in the ACTIVE TEST.
OK or NG
OK >> Passenger side mirror motor circuit is OK.
NG >> GO TO 3.
3.CHECK DOOR MIRROR MOTOR (PASSE NGER SIDE) HARNESS CONTINUITY
1. Turn ignition switch OFF.
2. Disconnect automatic drive positioner control uni t connector and door mirror (passenger side) connector.
3. Check continuity between automat ic drive positioner control unit
connector M49 terminal 14, 15, 30 and door mirror (passenger
side) connector D32 terminal 11, 12, 13.
4. Check continuity between automat ic drive positioner control unit
connector M49 terminal 14, 15, 30 and ground.
OK or NG
OK >> GO TO 4.
NG >> Repair or replace harness between automatic drive positioner control unit and door mirror (pas-
senger side).
4.CHECK MIRROR MOTOR SIGNAL
1. Connect automatic drive positioner control unit and door mirror (passenger side) connector.
2. Turn ignition switch ACC.
3. Turn changeover switch RH position.
4. Mirror switch operate, check voltage between door mirror (passenger side) connector and ground.
Te s t i t e m D e s c r i p t i o n
MIRROR MOTOR RH The RH mirror motor moves
the mirror UP/DOWN and
LEFT/RIGHT by receiving the drive signal.
14 (L/W) – 11 (PU) : Co ntinuity should exist.
15 (L/B) – 12 (OR) : Cont inuity should exist.
30 (W/R) – 13 (GY) : Cont inuity should exist.
14 (L/W) – Ground : Continuity should not exist.
15 (L/B) – Ground : Continuity should not exist.
30 (W/R) – Ground : Continuity should not exist.
PIIB8583E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 3692 of 3924

INFINITI FX35 2008 Service Manual
AUTOMATIC DRIVE POSITIONERSE-53
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
OK or NG
OK >> Replace door mirror motor (passenger side).
NG >> Check the condition of the harness and connect

Page 3693 of 3924

INFINITI FX35 2008 Service Manual
SE-54
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
2. Check continuity between driver seat control unit connector
B152 terminals 18, 28C and sliding motor connector B161 termi-
nals 18, 28.
3.

Page 3694 of 3924

INFINITI FX35 2008 Service Manual
AUTOMATIC DRIVE POSITIONERSE-55
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
2. Check continuity between driver seat control unit connector B152 terminals 28C, 29 and reclining motor conne

Page 3695 of 3924

INFINITI FX35 2008 Service Manual
SE-56
< SERVICE INFORMATION >
AUTOMATIC DRIVE POSITIONER
2. Check continuity between driver seat control unit connector
B152 terminals 19, 28C and front lifting motor connector B164
terminals 19, 28A

Page 3696 of 3924

INFINITI FX35 2008 Service Manual
AUTOMATIC DRIVE POSITIONERSE-57
< SERVICE INFORMATION >
C
DE
F
G H
J
K L
M A
B
SE
N
O P
2. Check continuity between driver seat control unit connector B152 terminals 28C, 30 and rear lifting motor co
