Page 161 of 3924

INFINITI FX35 2008 Service Manual
AT-88
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
*2: These malfunctions cannot be displayed MIL if another malfunction is assigned to MIL.
DATA MONITOR MODE
Display Items List
X: Standard, —: Not a

Page 162 of 3924

INFINITI FX35 2008 Service Manual
TROUBLE DIAGNOSISAT-89
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
1 POSITION SW (ON/OFF) X —
SLCT LVR POSI — X Selector lever position is recognized by the TCM.
For fail-safe operati

Page 163 of 3924

INFINITI FX35 2008 Service Manual
AT-90
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
R POSI IND (ON/OFF) — —
N POSI IND (ON/OFF) — —
D POSI IND (ON/OFF) — —
4TH POSI IND (ON/OFF) — —
3RD POSI IND (ON/OFF) — —
2ND POS

Page 164 of 3924

INFINITI FX35 2008 Service Manual
TROUBLE DIAGNOSISAT-91
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
DTC WORK SUPPORT MODE
Display Items List
Diagnosis Procedure without CONSULT-IIIINFOID:0000000001327164
OBD-II SELF-D

TROUBLE DIAGNOSISAT-91
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
DTC WORK SUPPORT MODE
Display Items List
Diagnosis Procedure without CONSULT-IIIINFOID:0000000001327164
OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST)
Refer to EC-125, "Generic Scan Tool (GST) Function" (for VQ35DE) or EC-704, "Generic Scan Tool (GST)
Function" (for VK45DE).
OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Refer to EC-71, "Malfunction Indicator Lamp (MIL)" (for VQ35DE) or EC-649, "Malfunction Indicator Lamp
(MIL)" (for VK45DE).
TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)
Description
When the ignition switch is turned ON, the indicator la mp lights up for 2 seconds. As a method for locating the
suspect circuit, when the self-diagnostics start signal is input, the memory for the malfunction location is output
and the A/T CHECK indicator lamp flashes to display the corresponding DTC.
Diagnostic Procedure
Voltage (V) — — Displays the value measured by the voltage
probe.
Frequency (Hz) — —
The value measured by the pulse probe is dis-
played.
DUTY-HI (high) (%) — —
DUTY-LOW (low) (%) — —
PLS WIDTH-HI (ms) — —
PLS WIDTH-LOW (ms) — — Monitored item (Unit)
Select Monitor Item
Remarks
ECU IN-
PUT SIG- NALS MAIN SIG-
NALS SELEC-
TION
FROM
MENU
DTC work support item Description Check item
1ST GR FUNCTN P0731 Following items for “1st gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
Input clutch solenoid valve
Front brake solenoid valve
Direct clutch solenoid valve
High and low reverse clutch solenoid valve
Each clutch
Hydraulic control circuit
2ND GR FUNCTN P0732
Following items for “2nd gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
3RD GR FUNCTN P0733 Following items for “3rd gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
4TH GR FUNCTN P0734 Following items for “4th gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
5TH GR FUNCTN P0735 Following items for “5th gear function” can be confirmed.
Self-diagnosis status (whether the diagnosis is being performed
or not)
Self-diagnostic results (OK or NG)
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 165 of 3924

INFINITI FX35 2008 Service Manual
AT-92
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
1.CHECK A/T CHECK INDICATOR LAMP
1. Start the engine with selector lever in “P” pos ition. Warm engine to normal operating temperature.
2. Turn ign

AT-92
< SERVICE INFORMATION >
TROUBLE DIAGNOSIS
1.CHECK A/T CHECK INDICATOR LAMP
1. Start the engine with selector lever in “P” pos ition. Warm engine to normal operating temperature.
2. Turn ignition switch ON and OFF at least twice, then leave it in the OFF position.
3. Wait 10 seconds.
4. Turn ignition switch ON. (Do not start engine.)
Does A/T CHECK indicator lamp come on for about 2 seconds?
YES >> GO TO 2.
NO >> Go to AT-170, "
A/T Check Indicator Lamp Does Not Come On".
2.JUDGEMENT PROCEDURE
1. Turn ignition switch OFF.
2. Keep pressing shift lock release button.
3. Move selector lever from “P” to “D” position.
4. Release accelerator pedal. (Set the closed throttle position signal ON.)
5. Depress brake pedal. (Stop lamp switch signal ON.)
6. Turn ignition switch ON. (Do not start engine.)
7. Wait 3 seconds.
8. Move the selector lever to the manual shift gate side. (Manual mode signal ON.)
9. Release brake pedal. (Stop lamp switch signal OFF.)
10. Move the selector lever to “D” position. (Manual mode signal OFF.)
11. Depress brake pedal. (Stop lamp switch signal ON.)
12. Release brake pedal. (Stop lamp switch signal OFF.)
13. Depress accelerator pedal fully and release it.
>> GO TO 3.
3.CHECK SELF-DIAGNOSIS CODE
Check A/T CHECK indicator lamp. Refer to "Judgement Self-diagnosis Code".
If the system does not go into self-diagnostics. Refer to AT-102
, AT-155, AT-164, AT-165.
>> DIAGNOSIS END
Judgement Self-diagnosis Code
If there is a malfunction, the lamp lights up fo r the time corresponding to the suspect circuit.
No. Malfunctioning item No. Malfunctioning item
1 Revolution sensor AT- 1 0 8
12 A/T interlock AT- 1 3 9
2 Direct clutch solenoid valve AT- 1 4 713 A/T 1st engine braking AT-141
3 Torque converter clutch solenoid valve AT- 1 2 4, AT- 1 2 614 Start signal AT- 9 7
4 Line pressure solenoid valve AT- 1 2 815 Accelerator pedal position sensor AT- 1 3 0
5 Input clutch solenoid valve AT- 1 4 316 Engine speed signal AT- 11 2
6 Front brake solenoid valve AT- 1 4 517 CAN communication line AT- 9 4
7 Low coast brake solenoid valve AT- 1 5 1, AT- 1 5 318 1st gear function AT- 11 4
8 High and low reverse clutch solenoid valve AT- 1 4 919 2nd gear function AT- 11 6
9 PNP switch AT- 1 0 220 3rd gear function AT- 11 8
10 A/T fluid temperature sensor AT-13221 4th gear function AT- 1 2 0
11 Turbine revolution sensor AT- 1 0 622 5th gear function AT- 1 2 2
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 166 of 3924

INFINITI FX35 2008 Service Manual
TROUBLE DIAGNOSISAT-93
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
Erase Self-diagnosis
In order to make it easier to find the cause of
hard-to-duplicate malfunctions, malfunction info

Page 167 of 3924

INFINITI FX35 2008 Service Manual
AT-94
< SERVICE INFORMATION >
DTC U1000 CAN COMMUNICATION LINE
DTC U1000 CAN COMMUNICATION LINE
DescriptionINFOID:0000000001327165
CAN (Controller Area Network) is a serial communication line for rea

Page 168 of 3924

INFINITI FX35 2008 Service Manual
DTC U1000 CAN COMMUNICATION LINEAT-95
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
Wiring Diagram - AT - CANINFOID:0000000001327169
TCWM0496E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A
