INFINITI FX35 2008 Service Manual
BRC-26
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note 1: Confirm tire pressure is normal.
Note 2: ON/OFF timing of ABS warning lamp
ON: Approx. Within 2 seconds after ignition switch is

BRC-26
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note 1: Confirm tire pressure is normal.
Note 2: ON/OFF timing of ABS warning lamp
ON: Approx. Within 2 seconds after ignition switch is turned ON, or when a malfunction is detected.
OFF: Approx. 2 seconds after ignition switch is turned ON (when sy
stem is in normal operation) and VDC/TCS function is not activated.
Note 3: ON/OFF timing of VDC OFF indicator lamp
ON: Approx. Within 2 seconds after ignition switch is turned ON, or when a malfunction is detected and VDC OFF switch is ON.
OFF: Approx. 2 seconds after ignition switch is turned ON (when system is in normal operation.) And when VDC OFF switch is OFF.
Note 4: ON/OFF timing of SLIP indicator lamp
ON: Approx. Within 2 seconds after ignition switch is turned ON, or when a malfunction is detected and VDC/TCS function is activa ted
while driving.
OFF: Approx. 2 seconds after ignition switch is turned ON (when sy stem is in normal operation) and VDC/TCS function is not activated.
Flashing: VDC/TCS function is active during driving
Note 5: Only AWD models.
Note 6: Serves as EBD warning lamp.
CONSULT-III Functions (ABS)INFOID:0000000001327671
CONSULT-III MAIN FUNCTION
CONSULT-III can display each diagnostic item us ing the diagnostic test modes shown following.
Self-DiagnosisINFOID:0000000001327672
OPERATION PROCEDURE
Before performing the self-diagnosis, start engine and driv e vehicle at 30 km/h (19 MPH) or more for approxi-
mately 1 minute.
ERASE MEMORY
After erasing DTC memory, start engine and drive vehicle at 30 km/h (19 MPH) or more for approximately 1
minute as the final inspection, and make sure that the ABS warning lamp, VDC OFF indicator lamp, SLIP indi-
cator lamp and brake warning lamp turn OFF.
CAUTION:
If memory cannot be erased, perform applicably diagnosis.
NOTE:
When the wheel sensor malfunctions, after inspecting the wheel sensor system, the ABS warning lamp,
VDC OFF indicator lamp, SLIP indicator lamp and br ake waning lamp will not turn OFF even when the sys-
tem is normal unless the vehicle is driving at approxim ately 30 km/h (19 MPH) or more for approximately 1
minute.
Brake warning lamp will turn ON in case of parki ng brake operation (when switch is ON) or of brake fluid
level switch should not stay “ON” position.
VDC OFF switch should not stay “ON” position.
2WD/4WD Drive axle 2WD model 2WD
AWD model AWD
Monitor item Display content
Data monitor
Condition Reference value in
normal operation
Diagnostic test mode Function
WORK SUPPORT This mode enables a technician to adjust some devices faster and more accurately by following the
indications on CONSULT-III.
SELF-DIAG RESULTS Self-diagnostic results can be read and erased quickly.
DATA MONITOR Input/Output data in the ABS actuator and electric unit (control unit) can be read.
CAN DIAG SUPPORT MNTR The results of transmit/receive diagnosis of communication can be read.
ACTIVE TEST Diagnostic Test Mode in which CONSULT-III drives
some actuators apart from the ABS actuator and
electric unit (control unit) and also shifts some parameters in a specified range.
FUNCTION TEST Performed by CONSULT-III inst ead of a technician to determine whether each system is “OK” or “NG”.
ECU PART NUMBER ABS actuator and electric unit (control unit) part number can be read.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 1042 of 3924

INFINITI FX35 2008 Service Manual
TROUBLE DIAGNOSISBRC-27
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
DISPLAY ITEM LIST
Self-diagnostic item Malfunction detecting condition Check system
RR RH SENSOR- 1
[C1

TROUBLE DIAGNOSISBRC-27
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
DISPLAY ITEM LIST
Self-diagnostic item Malfunction detecting condition Check system
RR RH SENSOR- 1
[C1101] (Note 1) Circuit of rear RH wheel sensor is open, shorted or sensor power volt-
age is unusual. BRC-34, "
DTC C1101 RR RH
SENSOR-1"
RR LH SENSOR- 1
[C1102] (Note 1)
Circuit of rear LH wheel sensor is open, shorted or sensor power volt-
age is unusual. BRC-35, "DTC C1102 RR LH
SENSOR-1"
FR RH SENSOR- 1
[C1103] (Note 1)Circuit of front RH wheel sensor is open, shorted or sensor power volt-
age is unusual. BRC-35, "DTC C1103 FR RH
SENSOR-1"
FR LH SENSOR- 1
[C1104] (Note 1)Circuit of front LH wheel sensor is open, shorted or sensor power volt-
age is unusual. BRC-35, "DTC C1104 FR LH
SENSOR-1"
RR RH SENSOR- 2
[C1105] (Note 1)
ABS actuator and electric unit (control unit) can not identify sensor puls-
es, because of large gap between wheel sensor and sensor rotor. BRC-36, "DTC C1105 RR RH
SENSOR-2"
RR LH SENSOR- 2
[C1106] (Note 1)ABS actuator and electric unit (control unit) can not identify sensor puls-
es, because of large gap between wheel sensor and sensor rotor. BRC-36, "DTC C1106 RR LH
SENSOR-2"
FR RH SENSOR- 2
[C1107] (Note 1)ABS actuator and electric unit (control unit) can not identify sensor puls-
es, because of large gap between wheel sensor and sensor rotor. BRC-36, "DTC C1107 FR RH
SENSOR-2"
FR LH SENSOR- 2
[C1108] (Note 1)
ABS actuator and electric unit (control unit) can not identify sensor puls-
es, because of large gap between wheel sensor and sensor rotor. BRC-36, "DTC C1108 FR LH
SENSOR-2"
BATTERY VOLTAGE
[ABNORMAL]
[C1109]ABS actuator and electric unit (control unit) power voltage is too low. BRC-36, "DTC C1109 BAT-
TERY VOLTAGE [ABNOR-
MAL]"
CONTROLLER FAILURE
[ C 111 0 ]
Internal malfunction of ABS actuator and electric unit (control unit) BRC-37, "DTC C1110 CON-
TROLLER FAILURE"
PUMP MOTOR
[ C 1111 ] ( N o t e 3 )During actuator motor operation with ON, when actuator motor turns
OFF or when control line for actuator motor relay is open.
BRC-37, "D T C C 1111 P U M P
MOTOR"During actuator motor operation with OFF, when actuator motor turns
ON or when control line for relay is shorted to ground.
G - SENSOR
[C1113] (Note 4) Decel G sensor is malfunctioning, or signal line of decel G sensor is
open or shorted. BRC-38, "
DTC C1113 G-SEN-
SOR"
ABS SENSOR
[ABNORMAL SIGNAL]
[C1115] (Note 1)Wheel sensor input is malfunction. BRC-39, "DTC C1115 ABS
SENSOR [ABNORMAL SIG-
NAL]"
STOP LAMP SW
[ C 111 6 ]
Stop lamp switch circuit is open or shorted. BRC-39, "DTC C1116 STOP
LAMP SW"
FR LH IN ABS SOL
[C1120]Circuit of front LH IN ABS solenoid is open or shorted, or control line is
open or shorted to power supply or ground. BRC-40, "DTC C1120 FR LH IN
ABS SOL"
FR LH OUT ABS SOL
[C1121]Circuit of front LH OUT ABS solenoid is
open or shorted, or control line
is open or shorted to power supply or ground. BRC-41, "DTC C1121 FR LH
OUT ABS SOL"
FR RH IN ABS SOL
[C1122]Circuit of front RH IN ABS solenoid is op
en or shorted, or control line is
open or shorted to power supply or ground. BRC-41, "DTC C1122 FR RH IN
ABS SOL"
FR RH OUT ABS SOL
[C1123]
Circuit of front RH OUT ABS solenoid is
open or shorted, or control line
is open or shorted to power supply or ground. BRC-42, "DTC C1123 FR RH
OUT ABS SOL"
RR LH IN ABS SOL
[C1124]Circuit of rear LH IN ABS solenoid is open or shorted, or control line is
open or shorted to power supply or ground. BRC-42, "DTC C1124 RR LH IN
ABS SOL"
RR LH OUT ABS SOL
[C1125] Circuit of rear LH OUT ABS solenoid is open or shorted, or control line
is open or shorted to power supply or ground. BRC-42, "DTC C1125 RR LH
OUT ABS SOL"
RR RH IN ABS SOL
[C1126]
Circuit of rear RH IN ABS solenoid is
open or shorted, or control line is
open or shorted to power supply or ground. BRC-42, "DTC C1126 RR RH IN
ABS SOL"
RR RH OUT ABS SOL
[C1127]Circuit of rear RH OUT ABS solenoid is open or shorted, or control line
is open or shorted to power supply or ground. BRC-42, "DTC C1127 RR RH
OUT ABS SOL"
ENGINE SIGNAL 1
[C1130]Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine fuel cut system is malfunctioning. BRC-42, "DTC C1130 ENGINE
SIGNAL 1"
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 1043 of 3924

INFINITI FX35 2008 Service Manual
BRC-28
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note 1: After completing repairs of shorted sensor circuit, when turning ignition switch ON, ABS warning lamp turned on. Make t
hat ABS
w

BRC-28
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note 1: After completing repairs of shorted sensor circuit, when turning ignition switch ON, ABS warning lamp turned on. Make t
hat ABS
warning lamp turned off while driving vehicle at approximately 30 km/h (19 MPH) or more for approximately 1 minute according to self-
diagnosis procedure. In addition, if whee l sensor 2 is displayed for wheels, check wheel sensor circuit and also check ABS actu ator and
electric unit (control unit) power voltage.
Note 2: If multiple malfunctions are detected including CAN communication line [U1000], perform diagnosis for CAN communication line
first.
Note 3: “ACTUATOR RLY” on the CONSULT-III self-diagnostic results indicates the malfunction of actuator relay or circuit. Actua tor relay
is imbedded in ABS actuator and electric unit (control unit).
Note 4:Only AWD models.
Data MonitorINFOID:0000000001327673
DISPLAY ITEM LIST
ENGINE SIGNAL 2
[C1131] Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine ETC system is malfunctioning. BRC-42, "DTC C1131 ENGINE
SIGNAL 2"
ENGINE SIGNAL 3
[C1132]Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine CAN system is malfunctioning. BRC-42, "DTC C1132 ENGINE
SIGNAL 3"
ENGINE SIGNAL 4
[C1133]Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine torque down system is malfunctioning. BRC-42, "DTC C1133 ENGINE
SIGNAL 4"
ENGINE SIGNAL 6
[C1136]
Based on the signal from ECM, ABS ac
tuator and electric unit (control
unit) judges that engine control system is malfunctioning. BRC-42, "DTC C1136 ENGINE
SIGNAL 6"
ACTUATOR RLY
[C1140] (Note 3) Actuator solenoid valve relay is ON, even if control unit sends off sig-
nal.
Actuator solenoid valve relay is OFF, even if control unit sends on sig- nal. BRC-43, "DTC C1140 ACTUA-
TOR RLY"
PRESS SEN CIRCUIT
[C1142]
Pressure sensor signal line is open or shorted, or sensor power voltage
is unusual, or pressure sensor is malfunctioning. BRC-43, "DTC C1142 PRESS
SEN CIRCUIT"
ST ANG SEN CIRCUIT
[C1143]Neutral position of steering angle sensor is dislocated, or steering angle
sensor is malfunctioning. BRC-44, "DTC C1143 ST ANG
SEN CIRCUIT"
ST ANG SEN SIGNAL
[C1144]
Neutral position correction of steering angle sensor is not finished. BRC-45, "DTC C1144 ST ANG
SEN SIGNAL"
YAW RATE SENSOR
[C1145]Yaw rate sensor has generated an error, or yaw rate sensor signal line
is open or shorted. BRC-46, "DTC C1145 YAW
RATE SENSOR"
SIDE G-SEN CIRCUIT
[C1146]Side G sensor is malfunctioning, or signal line of side G sensor is open
or shorted. BRC-46, "DTC C1146 SIDE G-
SEN CIRCUIT"
BR FLUID LEVEL LOW
[C1155]
Brake fluid level drops or
circuit between ABS actuat or and electric unit
(control unit) and brake fluid level switch is open or shorted. BRC-46, "DTC C1155 BR FLU-
ID LEVEL LOW"
ST ANG SEN COM CIR
[C1156]CAN communication line or steering angle sensor has generated an er-
ror. BRC-47, "DTC C1156 ST ANG
SEN COM CIR"
DECEL G SEN SET
[C1160] (Note 4)
Neutral position correction of decel G sensor is not finished.
BRC-47, "DTC C1160 DECEL G
SEN SET"
CV 1
[C1164]Primary side VDC switch-over solenoid valve 1 (cut valve 1) is open or
shorted, or control line is open or shorted to power supply or ground.
BRC-47, "DTC C1164 CV 1"
CV 2
[C1165]Secondary side VDC switch-over solenoid valve 2 (cut valve 2) is open
or shorted, or control line is open or shorted to power supply or ground.
BRC-47, "DTC C1165 CV 2"
SV 1
[C1166]Primary side VDC switch-over solenoid valve 1 (suction valve 1) is open
or shorted, or control line is open or shorted to power supply or ground.
BRC-47, "DTC C1166 SV 1"
SV 2
[C1167]Secondary side VDC switch-over solenoid valve 2 (suction valve 2) is
open or shorted, or control line is open or shorted to power supply or
ground.
BRC-47, "DTC C1167 SV 2"
VARIANT CODING
[C1170]
V coding is not functioning. BRC-48, "DTC C1170 VARIANT
CODING"
CAN COMM CIRCUIT
[U1000] (Note 2)When a ABS actuator and electric unit (control unit) is not transmitting
or receiving CAN communication signal for 2 seconds or more. BRC-48, "DTC U1000 CAN
COMM CIRCUIT"
Self-diagnostic item Malfunction detecting condition Check system
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 1044 of 3924

INFINITI FX35 2008 Service Manual
TROUBLE DIAGNOSISBRC-29
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : Applicable : Optional item
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAI

TROUBLE DIAGNOSISBRC-29
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : Applicable : Optional item
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS
GEAR ××Gear position judged by PNP switch signal is displayed.
SLCT LVR POSI ××Shift position judged by PNP switch signal.
FR RH SENSOR
[km/h (MPH)] ××
Wheel speed calculated by front RH wheel sensor signal is displayed.
FR LH SENSOR
[km/h (MPH)] ××
Wheel speed calculated by front LH wheel sensor signal is displayed.
RR RH SENSOR
[km/h (MPH)] ××
Wheel speed calculated by rear RH wheel sensor signal is displayed.
RR LH SENSOR
[km/h (MPH)] ××
Wheel speed calculated by rear LH wheel sensor signal is displayed.
BATTERY VOLT
(V) ××Voltage supplied to ABS actuator and electric unit (control unit) is dis-
played.
ENGINE SPEED
(rpm) ××
Engine speed judged by CAN communication signal is displayed.
DECEL G-SEN
(G) (AWD models) ××
Longitudinal acceleration detected by decel G sensor is displayed.
OFF SW
(ON/OFF)
×× VDC OFF switch (ON/OFF) status is displayed.
STOP LAMP SW
(ON/OFF) ××
Stop lamp switch (ON/OFF) status is displayed.
YAW RATE SEN
(d/s) ××
Yaw rate detected by yaw rate sensor is displayed.
ACCEL POS SIG
(%) ×Throttle valve open/close status judged by CAN communication signal
is displayed.
STR ANGLE SIG
(deg) ×
Steering angle detected by steering angle sensor is displayed.
SIDE G-SENSOR
(m/s
2) ×
Lateral acceleration detected by side G sensor is displayed.
PRESS SENSOR
(bar) ×
Brake fluid pressure detected by pressure sensor is displayed.
FLUID LEV SW
(ON/OFF) ×
Brake fluid level switch (ON/OFF) status is displayed.
ABS WARN LAMP
(ON/OFF) ×
ABS warning lamp (ON/OFF) status is displayed.
SLIP LAMP
(ON/OFF) ×
SLIP indicator lamp (ON/OFF) status is displayed.
FR LH IN SOL
(ON/OFF) ×
Front LH IN ABS solenoid (ON/ OFF) status is displayed.
FR LH OUT SOL
(ON/OFF) ×
Front LH OUT ABS solenoid (ON/OFF) status is displayed.
RR RH IN SOL
(ON/OFF) ×
Rear RH IN ABS solenoid (ON/OFF) status is displayed.
RR RH OUT SOL
(ON/OFF) ×
Rear RH OUT ABS solenoid (ON/ OFF) status is displayed.
FR RH IN SOL
(ON/OFF) ×
Front RH IN ABS solenoid (ON/OFF) status is displayed.
FR RH OUT SOL
(ON/OFF) ×
Front RH OUT ABS solenoid (ON/OFF) status is displayed.
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 1045 of 3924

INFINITI FX35 2008 Service Manual
BRC-30
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note: Serves as
EBD warning lamp.
Active TestINFOID:0000000001327674
CAUTION:
Do not perform active test while driving vehicle.
Make

BRC-30
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Note: Serves as
EBD warning lamp.
Active TestINFOID:0000000001327674
CAUTION:
Do not perform active test while driving vehicle.
Make sure to completely bleed air from the brake system.
Active test can not be performed when EBD, ABS, TCS or VDC operation is malfunction.
ABS and brake warning lamps tu rn on during the active test.
NOTE:
RR LH IN SOL
(ON/OFF) ×
Rear LH IN ABS solenoid (ON/ OFF) status is displayed.
RR LH OUT SOL
(ON/OFF) ×
Rear LH OUT ABS solenoid (ON/OFF) status is displayed.
OFF LAMP
(ON/OFF) ×
OFF Lamp (ON/OFF) status is displayed.
MOTOR RELAY
(ON/OFF) ×
ABS motor relay signal (ON/OFF) status is displayed.
ACTUATOR RLY
(ON/OFF) ×
ABS actuator relay signal (O N/OFF) status is displayed.
CV1
(ON/OFF) Primary side switch-over solenoid valve 1 (cut valve 1) (ON/OFF) status
is displayed.
CV2
(ON/OFF) Secondary side switch-over solenoid valve 2 (cut-valve 2) (ON/OFF)
status is displayed.
SV1
(ON/OFF) Primary side switch-over solenoid valve 1 (suction valve 1) (ON/OFF)
status is displayed.
SV2
(ON/OFF) Secondary side switch-over solenoid valve 2 (suction valve 2) (ON/
OFF) status is displayed.
VDC FAIL SIG
(ON/OFF) VDC fail signal (ON/OFF) status is displayed.
TCS FAIL SIG
(ON/OFF) TCS fail signal (ON/OFF) status is displayed.
ABS FAIL SIG
(ON/OFF) ABS fail signal (ON/OFF) status is displayed.
EBD FAIL SIG
(ON/OFF) EBD fail signal (ON/OFF) status is displayed.
EBD SIGNAL
(ON/OFF) EBD operation (ON/OFF) status is displayed.
ABS SIGNAL
(ON/OFF) ABS operation (ON/OFF) status is displayed.
TCS SIGNAL
(ON/OFF) TCS operation (ON/OFF) status is displayed.
VDC SIGNAL
(ON/OFF) VDC operation (ON/OFF) status is displayed.
EBD WARN LAMP
(ON/OFF) Brake warning lamp (ON/OFF) status is displayed. (Note)
CRANKING SIG
(ON/OFF) Cranking condition (ON/OFF) status is displayed.
4WD FAIL REQ
(ON/OFF) AWD fail-safe signal (ON/OFF) status is displayed.
2WD/4WD
(2WD/4WD) Distinguish 2WD and AWD
Item
(Unit) Data monitor item selection
Remarks
ECU INPUT
SIGNALS MAIN
SIGNALS
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 1046 of 3924

INFINITI FX35 2008 Service Manual
TROUBLE DIAGNOSISBRC-31
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
When active test is performed while depressing, t he pedal depression amount will change. This is nor

TROUBLE DIAGNOSISBRC-31
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
When active test is performed while depressing, t he pedal depression amount will change. This is normal.
“TEST IS STOPPED” is displayed 10 seconds after operation start.
After “TEST IS STOPPED” is displayed, touch “BACK” and perform test again.
TEST ITEM
Solenoid Valve
NOTE:
The example shown is for the front right wheel. The procedure for the other wheels is the same as given
below.
When performing an active test of the ABS function, se lect the main item for each test item. In addition,
when performing an active test of the VDC/TCS function, select the item menu for each test item.
For the ABS solenoid valve, touch “UP” “KEEP” “DOWN”, and for the ABS solenoid valve (ACT), touch “UP”
“ACTUATOR UP” “ACTUATOR KEEP”, and check to make su re that all solenoid valve (in, out) are operating
as given in the table below.
*: ON for 1 to 2 seconds after the touch, and then OFF
ABS Motor
Touch “ON” and “OFF” on the screen. Make sure AB S motor relay operates as shown in table below.
For Fast and Accurate DiagnosisINFOID:0000000001327675
PRECAUTIONS FOR DIAGNOSIS
Before performing diagnosis, always read precautions. Refer to BRC-13, "How to Proceed with Diagnosis".
If ABS actuator and electric unit (control unit), steer ing angle sensor, steering system parts or suspension
system parts have been replaced, or if alignment has been adjusted, be sure to adjust neutral position of
steering angle sensor before driving. Refer to BRC-8, "
Adjustment of Steering Angle Sensor Neutral Posi-
tion".
After diagnosis is finished, be sure to erase memory. Refer to BRC-26, "
Self-Diagnosis".
When checking continuity and voltage between units, be sure to check for disconnection, looseness, bend,
or collapse of connector terminals. If any malfuncti on is found, repair or replace connector terminals.
For intermittent symptoms, possible cause is malfunc tion in harness, harness connector, or terminals. Move
harness, harness connector, and terminals to check for poor connections.
If a circuit tester is used for the check, be ca reful not to forcibly extend any connector terminal.
To use CONSULT-III to perform self-diagnosis of ABS act uator and electric unit (control unit), active tests, or
work support, first stop work, then connect CONSULT-III and select “ABS”.
While self-diagnostic results of CONSULT-III shows malf unction, if CONSULT-III active test is performed, an
engine system error may be indicated. In this case, start engine to resume the normal screen.
VDC/TCS/ABS system electronica lly controls brake operation and engine output. The following symptoms
may be caused by normal operations:
Operation ABS solenoid valve ABS so
lenoid valve (ACT)
UP KEEP DOWN UP ACTUATOR
UP ACTUATOR
KEEP
FR RH IN SOL OFF ON ON OFF OFF OFF
FR RH OUT SOL OFF OFF ON* OFF OFF OFF
CV 1 OFF OFF OFF OFF ON ON
SV 1 OFF OFF OFF OFF ON* OFF
Operation ON OFF
MOTOR RELAY ON OFF
ACTUATOR RLY ON ON
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 1047 of 3924

INFINITI FX35 2008 Service Manual
BRC-32
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Basic Inspection
INFOID:0000000001327676
BRAKE FLUID AMOUNT, LEAKS, AND BRAKE PADS INSPECTION
1. Check fluid level in the brake reservoir

BRC-32
< SERVICE INFORMATION >[VDC/TCS/ABS]
TROUBLE DIAGNOSIS
Basic Inspection
INFOID:0000000001327676
BRAKE FLUID AMOUNT, LEAKS, AND BRAKE PADS INSPECTION
1. Check fluid level in the brake reservoir tank. If fluid level is low, refill brake fluid.
2. Check brake piping and around ABS actuator and electric uni t (control unit) for leaks. If there is leaking or
oozing fluid, check the following items.
If ABS actuator and electric unit (control unit) connec tion is loose, tighten piping to the specified torque
and re-perform the leak inspection to make sure there are no leaks.
If there is damage to the connection flare nut or AB S actuator and electric unit (control unit) screw,
replace the damaged part and re-perform the leak inspection to make sure there are no leaks.
When there is fluid leaking or oozing from a part other than ABS actuator and electric unit (control unit)
connection, if fluid is just oozing out, use a clean cl oth to wipe off the oozing fluid and re-check for leaks.
If fluid is still oozing out, replace the damaged part.
When there is fluid leaking or oozing at ABS actuator and electric unit (control unit), if fluid is just oozing
out, use a clean cloth to wipe off oozing fluid and re-che ck for leaks. If fluid is still oozing out, replace
ABS actuator and electric unit (control unit) body.
CAUTION:
ABS actuator and electric unit (contr ol unit) body can not be disassembled.
3. Check brake pad degree of wear. Refer to BR-18, "
On-Vehicle Inspection" in “Front Disc Brake” and BR-
24, "On-Vehicle Inspection" in “Rear Disc Brake”
POWER SYSTEM TERMINAL LOOSENESS AND BATTERY INSPECTION
Make sure battery positive cable, negative cabl e and ground connection are not loose. If looseness is
detected, tighten the cables. In additi on, check the battery voltage to make sure it has not dropped and alter-
nator is normal.
ABS WARNING LAMP, VDC OFF INDICATOR LAMP, SLIP INDICATOR LAMP AND BRAKE WARN-
ING LAMP INSPECTION
Symptom Symptom description Result
Motor operation noise This is noise of motor in
side ABS actuator and electr ic unit (control unit).
Slight noise may occur during VDC, TCS, and ABS operation.
Normal
When the vehicle speed goes over 20 km/h (12.5 MPH), motor and valves
operating noise may be heard. It happens only once after ignition switch is
ON. This is a normal status of the system operation check.
System operation check noise When engine starts, slight “click” noise may be heard from engine room.
This is normal and is part of system operation check. Normal
VDC/TCS operation
(SLIP indicator lamp blinking) TCS may activate momentarily if wheel speed changes when driving over
location where friction coefficient varies, when up/downshifting, or when ful-
ly depressing accelerator pedal.
Normal
Cancel the VDC/TCS
function for the inspec-
tion on a chassis dyna-
mometer.
For inspection of speedometer or other instruments, press VDC OFF switch
to turn VDC/TCS function off.
When accelerator pedal is depressed on a chassis dynamometer (fixed
front-wheel type), vehicle speed will not increase. This is not normal. It is re-
sult of TCS being activated by stationary front wheels. Warning lamp may
also illuminate to indicate “sensor system error”. This is also normal, and is
the result of the stationary front wheels being detected. To be certain, restart
engine, and drive vehicle at 30 km/h (19 MPH) or more. Make sure warning
lamp does not illuminate.
ABS operation
(Longer stopping distance) On roads with low friction coefficients, such as snowy roads or gravel roads,
vehicles with ABS may require a longer stopping distance. Therefore, when
driving on such roads, avoid overconfidence and keep speed sufficiently
low.
Normal
Insufficient feeling of accelera-
tion Depending on road conditions, driver may feel that feeling of acceleration is
insufficient. This is because traction control, which controls engine and
brakes to achieve optimal traction, has the highest priority (for safety). As a
result, there may be times when acceleration is slightly less than usual for
the same accelerator pedal operation.
Normal
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Page 1048 of 3924

INFINITI FX35 2008 Service Manual
TROUBLE DIAGNOSISBRC-33
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : ON –: OFF
Note 1:Brake warning lamp will turn on in case of operating parking brake (switch turn

TROUBLE DIAGNOSISBRC-33
< SERVICE INFORMATION > [VDC/TCS/ABS]
C
D
E
G H
I
J
K L
M A
B
BRC
N
O P
× : ON –: OFF
Note 1:Brake warning lamp will turn on in case of operating parking brake (switch turned on) or of actuating brake fluid level switch
(brake fluid is insufficient).
Note 2:After starting engine, turn OFF.
1. Make sure ABS warning lamp, VDC OFF indicator lamp (when VDC OFF switch is OFF), and SLIP indica- tor lamp turn on approximately 2 second, and brake warning lamp turns on when ignition switch is turned
ON. If they do not, check VDC OFF indicator lamp and then VDC OFF switch. Refer to BRC-48, "
Compo-
nent Inspection". Check CAN communications. Refer to “CAN Communication Inspection”. If there are no
errors with VDC OFF switch and CAN communication system, check combination meter. Refer to DI-5
.
2. Make sure ABS warning lamp, VDC OFF indicator lamp, SLIP indicator lamp turn off approximately 2 sec- ond after turn ignition switch ON, and brake warning lamp turns off after engine starts. If lamps do not turn
off, perform self-diagnosis.
3. With engine running, make sure VDC OFF indicator lamp turns on and off when VDC OFF switch is turned ON and OFF. If indicator lamp status does not correspond to switch operation, check the VDC OFF
switch system. Refer to BRC-48, "
Component Inspection".
4. Make sure ABS warning lamp, VDC OFF indicator lamp, and SLIP indicator lamp turn off 2 seconds after engine is started. If ABS warning lamp, VDC OFF indicator lamp, and SLIP indicator lamp have not turned
off 10 seconds after engine has been started, perform self-diagnosis of ABS actuator and electric unit
(control unit).
5. After performing the self-diagnosis, be sure to erase the error memory. Refer to BRC-26, "
Self-Diagnosis".
NOTE:
Brake warning lamp will turn ON in case of parking brake operation (when switch is ON) or of brake fluid level
switch should not stay “ON” position.
Condition ABS warning
lamp VDC OFF in-
dicator lamp SLIP indicator
lamp Brake warning
lamp (Note 1) Remarks
Ignition switch OFF. – – – — —
Approx. 2 seconds after ignition
switch is turned ON. ×× ××
(Note 2) —
Approx. 2 seconds later after ig-
nition switch ON. –– –
× (Note 2) Go out 2 seconds after igni-
tion switch is turned ON.
VDC OFF switch is turned ON.
(VDC/TCS function is OFF.) –
× –— —
VDC/TCS/ABS error. ×× × —There is an ABS actuator
and electric unit (control unit)
error. (Power, ground or sys-
tem malfunction)
When VDC/TCS is not function-
ing normally. –
×× ——
EBD error. ×× × × —
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

Load next 8 pages

Page: < prev 1-10 ... 1009-1016 1017-1024 1025-1032 1033-1040 1041-1048 1049-1056 1057-1064 1065-1072 1073-1080 ... 3928 next >

transmission oil alternator oil viscosity sport mode towing capacity oil
