Page 1913 of 3924

INFINITI FX35 2008 Service Manual TROUBLE DIAGNOSISEC-673 < SERVICE INFORMATION > [VK45DE] C D E F G H I J K L M A EC NP O Symptom Matrix ChartINFOID:0000000001326526 SYSTEM — BASIC ENGINE CONTROL SYSTEM SYMPTOM Reference page HAR

Page 1914 of 3924

INFINITI FX35 2008 Service Manual EC-674 < SERVICE INFORMATION >[VK45DE] TROUBLE DIAGNOSIS 1 - 6: The numbers refer to the order of inspection. (continued on next page) SYSTEM — ENGINE MECHANICAL & OTHER Vehicle speed signal circui

Page 1915 of 3924

INFINITI FX35 2008 Service Manual TROUBLE DIAGNOSISEC-675 < SERVICE INFORMATION > [VK45DE] C D E F G H I J K L M A EC NP O SYMPTOM Reference page HARD/NO START/RESTART (EXCP. HA) ENGINE STALL HESITATION/SURGING/FLAT SPOT SPARK KNOCK

Page 1916 of 3924

INFINITI FX35 2008 Service Manual EC-676 < SERVICE INFORMATION >[VK45DE] TROUBLE DIAGNOSIS 1 - 6: The numbers refer to the order of inspection.Exhaust Exhaust manifold/Tube/Muffler/ Gasket 55555 55 5 EM-179 , EX-3 Three way catalyst

Page 1917 of 3924

INFINITI FX35 2008 Service Manual TROUBLE DIAGNOSISEC-677 < SERVICE INFORMATION > [VK45DE] C D E F G H I J K L M A EC NP O Engine Control Com ponent Parts LocationINFOID:0000000001326527 1. IPDM E/R 2. ICC brake hold relay (ICC model

Page 1918 of 3924

INFINITI FX35 2008 Service Manual EC-678 < SERVICE INFORMATION >[VK45DE] TROUBLE DIAGNOSIS : Vehicle front 1. Mass air flow sensor (with intake air temperature sensor) 2. Camshaft position sensor (PHASE) 3. Engine coolant temperature

Page 1919 of 3924

INFINITI FX35 2008 Service Manual TROUBLE DIAGNOSISEC-679 < SERVICE INFORMATION > [VK45DE] C D E F G H I J K L M A EC NP O : Vehicle front 1. Intake valve timing control position sensor (Bank 2) 2. Intake valve timing control soleno

Page 1920 of 3924

INFINITI FX35 2008 Service Manual EC-680 < SERVICE INFORMATION >[VK45DE] TROUBLE DIAGNOSIS : Vehicle front 1. Fuel injector (Bank 2) 2. Fuel injector (Bank 1) 3. VIAS control solenoid valve 4. Vacuum tank 5. Power valve actuator 6. E
