By referring to the figure, measure the valve clearances at
locations marked “ ×” as shown in the table below (lo INFINITI FX35 2008 Service Manual
CAMSHAFTEM-93
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
By referring to the figure, measure the valve clearances at
locations marked “ ×” as shown in the table below (lo](/manual-img/42/57017/w960_57017-2576.png)
CAMSHAFTEM-93
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
By referring to the figure, measure the valve clearances at
locations marked “ ×” as shown in the table below (locations
indicated in the figure).
No. 1 cylinder at compression TDC
c. Rotate crankshaft by 240 degrees clockwise (when vi ewed from engine front) to align No. 3 cylinder at
TDC of its compression stroke.
NOTE:
To align cylinder No. 3 with the compression top dead center, place matching marks (A) on the crankshaft pulley (1) side and
on the cylinder block side at a point 240 ° counterclockwise
from the compression top dead center using the hex head of
the crankshaft pulley bolt as a guide.
Measuring position (right bank) No. 1 CYL. No. 3 CYL. No. 5 CYL.
No. 1 cylinder at
compression TDC EXH
×
INT ×
Measuring position (left bank) No. 2 CYL. No. 4 CYL. No. 6 CYL.
No. 1 cylinder at
compression TDC INT
×
EXH ×
PBIC2054E
PBIC4628J
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2578 of 3924
![INFINITI FX35 2008 Service Manual
EM-94
< SERVICE INFORMATION >[VQ35DE]
CAMSHAFT
By referring to the figure, measure the valve clearances at
locations marked “ ×” as shown in the table below (locations
indicated in the figure) INFINITI FX35 2008 Service Manual
EM-94
< SERVICE INFORMATION >[VQ35DE]
CAMSHAFT
By referring to the figure, measure the valve clearances at
locations marked “ ×” as shown in the table below (locations
indicated in the figure)](/manual-img/42/57017/w960_57017-2577.png)
EM-94
< SERVICE INFORMATION >[VQ35DE]
CAMSHAFT
By referring to the figure, measure the valve clearances at
locations marked “ ×” as shown in the table below (locations
indicated in the figure).
No. 3 cylinder at compression TDC
d. Rotate crankshaft by 240 degrees clockwise (when viewed from engine front) to align No. 5 cylinder at TDC of compression stroke.
NOTE:
To align cylinder No. 5 with the compression top dead center,place matching marks (A) on the crankshaft pulley (1) side and
on the cylinder block side at a point 240 ° counterclockwise
from the compression top dead center using the hex head of
the crankshaft pulley bolt as a guide.
Measuring position (right bank) No. 1 CYL. No. 3 CYL. No. 5 CYL.
No. 3 cylinder at
compression TDC EXH
×
INT ×
Measuring position (left bank) No. 2 CYL. No. 4 CYL. No. 6 CYL.
No. 3 cylinder at
compression TDC INT
×
EXH ×
PBIC2055E
PBIC4628J
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2579 of 3924
![INFINITI FX35 2008 Service Manual
CAMSHAFTEM-95
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
By referring to the figure, measure the valve clearances at
locations marked “ ×” as shown in the table below (lo INFINITI FX35 2008 Service Manual
CAMSHAFTEM-95
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
By referring to the figure, measure the valve clearances at
locations marked “ ×” as shown in the table below (lo](/manual-img/42/57017/w960_57017-2578.png)
CAMSHAFTEM-95
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
By referring to the figure, measure the valve clearances at
locations marked “ ×” as shown in the table below (locations
indicated in the figure).
No. 5 cylinder at compression TDC
3. For measured value are out of the standard, perform adjustment. Refer to "ADJUSTMENT".
ADJUSTMENT
Perform adjustment depending on selected head thickness of valve lifter.
1. Measure the valve clearance. Refer to "INSPECTION".
2. Remove camshaft. Refer to EM-84, "
Removal and Installation".
3. Remove valve lifters at the loca tions that are out of the standard.
4. Measure the center thickness of the removed valve lifters with a micrometer.
5. Use the equation below to calculate valve lifter thickness for replacement.
Measuring position (right bank) No. 1 CYL. No. 3 CYL. No. 5 CYL. No. 5 cylinder at
compression TDC EXH
×
INT ×
Measuring position (left bank) No. 2 CYL. No. 4 CYL. No. 6 CYL.
No. 5 cylinder at
compression TDC INT
×
EXH ×
PBIC2056E
KBIA0057E
Valve lifter thickness calculation: t = t1+ (C1 – C2)
t = Valve lifter thickness to be replaced
t
1 = Removed valve lifter thickness
C
1= Measured valve clearance
C
2= Standard valve clearance: Intake : 0.30 mm (0.012 in)*
Exhaust : 0.33 mm (0.013 in)*
*: Approximately 20 °C (68 °F)
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2580 of 3924
![INFINITI FX35 2008 Service Manual
EM-96
< SERVICE INFORMATION >[VQ35DE]
CAMSHAFT
Thickness of new valve lifter can be identified by stamp marks
on the reverse side (inside the cylinder).
Available thickness of valve lifter: 27 size INFINITI FX35 2008 Service Manual
EM-96
< SERVICE INFORMATION >[VQ35DE]
CAMSHAFT
Thickness of new valve lifter can be identified by stamp marks
on the reverse side (inside the cylinder).
Available thickness of valve lifter: 27 size](/manual-img/42/57017/w960_57017-2579.png)
EM-96
< SERVICE INFORMATION >[VQ35DE]
CAMSHAFT
Thickness of new valve lifter can be identified by stamp marks
on the reverse side (inside the cylinder).
Available thickness of valve lifter: 27 sizes with range 7.88 to 8.40 mm (0.3102 to 0.3307 in) in steps of 0.02
mm (0.0008 in) (when manufactured at factory). Refer to EM-149, "
Standard and Limit".
CAUTION:
Install identification letter at the end, “U”, “R” and “V” at each of proper positions.
6. Install selected valve lifter.
7. Install camshaft. Refer to EM-84, "
Removal and Installation".
8. Manually turn crankshaft pulley a few turns.
9. Make sure that the valve clearances for cold engine ar e within the specifications by referring to the speci-
fied values. Refer to "INSPECTION".
10. Install all removal parts in the reverse order of removal. Refer to EM-84, "
Removal and Installation".
11. Warm up the engine, and check for unusual noise and vibration.
KBIA0119E
Stamp mark Thickness
788U
790U ·
·
840U 788R
790R
·
·
840R 788V
790V
·
·
840V 7.88 mm
7.90 mm
·
·
8.40 mm
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2581 of 3924
![INFINITI FX35 2008 Service Manual
OIL SEALEM-97
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
OIL SEAL
Removal and Installation of Valve Oil SealINFOID:0000000001325734
REMOVAL
1. Remove camshaft relating to valve INFINITI FX35 2008 Service Manual
OIL SEALEM-97
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
OIL SEAL
Removal and Installation of Valve Oil SealINFOID:0000000001325734
REMOVAL
1. Remove camshaft relating to valve](/manual-img/42/57017/w960_57017-2580.png)
OIL SEALEM-97
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
OIL SEAL
Removal and Installation of Valve Oil SealINFOID:0000000001325734
REMOVAL
1. Remove camshaft relating to valve oil seal to be removed. Refer to
EM-83, "Component".
2. Remove valve lifters. Refer to EM-83, "
Component".
3. Turn crankshaft until the cylinder requiring new oil seal s is at TDC. This will prevent valve from dropping
into cylinder.
4. Remove valve collet. Compress valve spring with the valve spring compressor, theattachment, the adapter (SST). Remove valve collet with a
magnet hand.
CAUTION:
When working, take care not to damage valve lifter holes.
5. Remove valve spring retainer, and valve spring.
6. Remove valve oil seal using the valve oil seal puller (SST).
INSTALLATION
1. Apply new engine oil on new valve oil seal joint and seal lip.
2. Using the valve oil seal drift (SST), press fit valve seal to height “H” shown in figure.
NOTE:
Dimension “H”: Height measured before valve spring seat instal-
lation
3. Install in the reverse order of removal after this step.
Removal and Installati on of Front Oil SealINFOID:0000000001325735
REMOVAL
1. Remove the following parts:
Undercover
Drive belts: Refer to EM-15, "
Removal and Installation".
Crankshaft pulley: Refer to EM-64, "
Component".
PBIC1803E
PBIC0884E
Intake and exhaust : 14.3 - 14.9 mm (0.563 - 0.587 in)
PBIC2769E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2582 of 3924
![INFINITI FX35 2008 Service Manual
EM-98
< SERVICE INFORMATION >[VQ35DE]
OIL SEAL
2. Remove front oil seal using a suitable tool.
CAUTION:
Be careful not to damage front timing chain case and crank-
shaft.
INSTALLATION
1. Apply new en INFINITI FX35 2008 Service Manual
EM-98
< SERVICE INFORMATION >[VQ35DE]
OIL SEAL
2. Remove front oil seal using a suitable tool.
CAUTION:
Be careful not to damage front timing chain case and crank-
shaft.
INSTALLATION
1. Apply new en](/manual-img/42/57017/w960_57017-2581.png)
EM-98
< SERVICE INFORMATION >[VQ35DE]
OIL SEAL
2. Remove front oil seal using a suitable tool.
CAUTION:
Be careful not to damage front timing chain case and crank-
shaft.
INSTALLATION
1. Apply new engine oil to both oil seal lip and dust seal lip of new front oil seal.
2. Install front oil seal. Install front oil seal so that each seal lip is oriented as shown in
the figure.
Using a suitable drift, press-fit until the height of front oil seal is level with the mounting surface.
- Suitable drift: outer diameter 60 mm (2.36 in), inner diameter
50 mm (1.97 in).
Make sure the garter spring is in position and seal lips not inverted
CAUTION:
Be careful not to damage front timing chain case and
crankshaft.
Press-fit straight and avoid causing burrs or tilting oil
seal.
3. Install in the reverse order of removal after this step.
Removal and Installation of Rear Oil SealINFOID:0000000001325736
REMOVAL
1. Remove oil pan (upper). Refer to EM-30, "Component (2WD Models)".
2. Remove transmission assembly. Refer to AT-241, "
Removal and Installation (2WD Models)".
3. Remove drive plate. Refer to EM-122, "
Component".
4. Use a seal cutter (SST) to cut away liquid gasket and remove rear oil seal retainer.
CAUTION:
Be careful not to damage mounting surface.
NOTE:
Regard both rear oil seal and retainer as an assembly.
SEM829E
SEM715A
SEM829E
SEM830E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2583 of 3924
OIL SEALEM-99
< SERVICE INFORMATION > [VQ35DE]
C
D
E
F
G H
I
J
K L
M A
EM
NP
O
INSTALLATION
1. Remove old liquid gasket on mating surfaces of cylinder block and oil pan (upper) using a scraper.
2. Apply new engine oil to both oil seal lip and dust seal lip of new rear oil seal retainer.
3. Apply a continuous bead of liquid gasket with the tube presser
(commercial service tool) to rear oil seal retainer as shown in the
figure.
Use Genuine RTV Silicone Seal ant or equivalent. Refer to
GI-44, "
Recommended Chemical Product and Sealant".
Assembly should be done within 5 minutes after coating.
4. Install rear oil seal retainer to cylinder block. Refer to EM-122, "
Component".
Make sure the garter spring is in position and seal lips not inverted.
5. Install in the reverse order of removal after this step.
PBIC2661E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 2584 of 3924
![INFINITI FX35 2008 Service Manual
EM-100
< SERVICE INFORMATION >[VQ35DE]
CYLINDER HEAD
CYLINDER HEAD
On-Vehicle ServiceINFOID:0000000001325737
CHECKING COMPRESSION PRESSURE
1. Warm up engine thoroughly. Then, stop it.
2. Release fuel INFINITI FX35 2008 Service Manual
EM-100
< SERVICE INFORMATION >[VQ35DE]
CYLINDER HEAD
CYLINDER HEAD
On-Vehicle ServiceINFOID:0000000001325737
CHECKING COMPRESSION PRESSURE
1. Warm up engine thoroughly. Then, stop it.
2. Release fuel](/manual-img/42/57017/w960_57017-2583.png)
EM-100
< SERVICE INFORMATION >[VQ35DE]
CYLINDER HEAD
CYLINDER HEAD
On-Vehicle ServiceINFOID:0000000001325737
CHECKING COMPRESSION PRESSURE
1. Warm up engine thoroughly. Then, stop it.
2. Release fuel pressure. Refer to
EC-87, "
Fuel Pressure Check".
3. Disconnect fuel pump fuse to avoid fuel injection during mea- surement.
4. Remove engine cover with power tool. Refer to EM-19, "
Component".
5. Remove ignition coil and spark plug from each cylinder. Refer to EM-42, "
Component" and EM-43, "Com-
ponent".
6. Connect engine tachometer (not required in use of CONSULT-III).
7. Install compression gauge with an adapter (commercial service tool) onto spark plug hole.
Use the adapter whose picking up end inserted to spark plughole is smaller than 20 mm (0.79 in) in diameter. Otherwise, it
may be caught by cylinder head during removal.
8. Turn ignition switch to “START” for cranking. When the gauge pointer stabilizes, read the compression
pressure and the engine rpm. Perform these steps to check each cylinder.
Compression pressure:
Unit: kPa (kg/cm2, psi) /rpm
CAUTION:
Always use a fully changed battery to obtain the specified engine speed.
SBIA0466E
PBIC0900E
SBIA0533E
Standard Minimum Deference limit between cylinders
1,275 (13.0, 185)/300 981 (10.0, 142)/300 98 (1.0, 14)/300
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
