Page 2473 of 3924

INFINITI FX35 2008 Service Manual EI-36 < SERVICE INFORMATION > DOOR FINISHER DOOR FINISHER Component Parts LocationINFOID:0000000001328074 Removal and InstallationINFOID:0000000001529409 DOOR FINISHER (FRONT AND REAR) Removal 1. Rem

Page 2474 of 3924

INFINITI FX35 2008 Service Manual DOOR FINISHEREI-37 < SERVICE INFORMATION > C DE F G H J K L M A B EI N O P 3. Insert screw driver rolled with cloth between panel on vehicle and clips (as indicated with arrow), and remove finisher.

Page 2475 of 3924

INFINITI FX35 2008 Service Manual EI-38 < SERVICE INFORMATION > BODY SIDE TRIM BODY SIDE TRIM Component Parts LocationINFOID:0000000001328075 Removal and InstallationINFOID:0000000001529410 CAUTION: Wrap the tip of flat-bladed screwd

Page 2476 of 3924

INFINITI FX35 2008 Service Manual BODY SIDE TRIMEI-39 < SERVICE INFORMATION > C DE F G H J K L M A B EI N O P 3. Remove center pillar lower garnish. NOTE: Insert screwdriver rolled with cloth between panel on vehicle and clips, then

Page 2477 of 3924

INFINITI FX35 2008 Service Manual EI-40 < SERVICE INFORMATION > BODY SIDE TRIM FRONT PILLAR GARNISH Removal Remove front pillar garnish clips and remove front pillar garnish. Installation Install in the reverse order of removal. KICK

Page 2478 of 3924

INFINITI FX35 2008 Service Manual FLOOR TRIMEI-41 < SERVICE INFORMATION > C DE F G H J K L M A B EI N O P FLOOR TRIM Component Parts LocationINFOID:0000000001328076 Removal and InstallationINFOID:0000000001529411 REMOVAL 1. Remove fr

Page 2479 of 3924

INFINITI FX35 2008 Service Manual EI-42 < SERVICE INFORMATION > FLOOR TRIM 11. Remove floor carpet from carpet fixing clip and remove floor car-pet. INSTALLATION Install in the reverse order of removal. PIIA1223E 3AA93ABC3ACD3AC03ACA

Page 2480 of 3924

INFINITI FX35 2008 Service Manual HEADLININGEI-43 < SERVICE INFORMATION > C DE F G H J K L M A B EI N O P HEADLINING Component Parts LocationINFOID:0000000001328077 1. Headlining 2. Assist grip (rear) 3. Assist grip (front) 4. Sun-vi
