Page 665 of 3924

AV-118
< SERVICE INFORMATION >
NAVIGATION SYSTEM
5. Perform self-diagnosis by selecting the “Self Diagnosis (NAVI)”. Self-diagnosis screen is displayed, and then self-diagnosisstarts.
The bar graph visible below self-diagnosis screen displays progress of the diagnosis.
6. On the diagnosis results screen, each unit name and connection line will be colored according to the diagnosis result, as follows.
NOTE:
Control unit = NAVI control unit
Only Control unit (NAVI control unit) is displayed in red.
If multiple malfunctions occur at the same time for a single unit, the screen switch colors are determined
according to the following order of priority: red > yellow > gray.
7. Select a switch on the diagnosis results screen, and comments for the diagnosis results will be shown.
SELF-DIAGNOSIS RESULT
Check the applicable display in the following table, and then repair the malfunctioning parts.
Quick Reference Table
SKIB6972E
Diagnosis results Unit Connection line
Normal Green Green
Connection malfunction Gray Yellow
DVD-ROM drive undiagnosed Gray Green
DVD-ROM and DVD-ROM drive malfunction Yellow Green
Unit returned an error Red Green
SKIB7772E
SKIB3659E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 666 of 3924

NAVIGATION SYSTEMAV-119
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
AV
N
O P
Confirmation/Adjustment ModeINFOID:0000000001328755
OPERATION PROCEDURE
1. Start the engine.
2. Turn the audio system OFF.
Self-diagnosis result screen Possible cause Action to take
NAVI control unit malfunction is detect-
ed. Replace NAVI control unit.
Refer to
AV- 1 4 1 , "
Removal and Installa-
tion of NAVI Control Unit".
Malfunction is detected on DVD- ROM drive pickup lens in NAVI con-
trol unit.
There is dirt and damage on the
DVD-ROM. 1. Check if the inserted DVD-ROM is
specified for this navigation system,
and the DVD-ROM is dirty, scratched
or warped.
2. If the results from the above checkup show no malfunction, insert the
same DVD-ROM, and then restart
self-diagnosis.
3. If self-diagnosis results still show any malfunction, replace NAVI control
unit.
DVD-ROM not inserted is detected. Insert DVD-ROM.
GPS antenna connection malfunction
is detected. 1. Check if GPS antenna feeder line is
snapped or pinched.
2. If the results from the above checkup
show no malfunction, replace GPS
antenna, and then restart self-diag-
nosis.
3. If self-diagnosis results still show any malfunction, replace NAVI control
unit.
SKIB7773E
SKIB7774E
SKIB7775E
SKIB7776E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 667 of 3924

AV-120
< SERVICE INFORMATION >
NAVIGATION SYSTEM
3. While pressing the “4” button, turn the volume control dial clock-wise or counterclockwise for 30 clicks or more. (When the self-
diagnosis mode is started, a short beep will be heard.)
Shifting from current screen to previous screen is performed
by pressing “BACK” button.
4. The initial trouble diagnosis screen will be shown, and items “Self Diagnosis (DCU)”, “Self Diagnosis (NAVI)”, “Confirmation/
Adjustment” and “CAN DIAG SUPPORT MONITOR” will
become selective.
5. Select “Confirmation/Adjustment”.
6. Each diagnosis is shown by selecting each screen switch on Confirmation/Adjustment screen.
DISPLAY DIAGNOSIS
Color tone and shading of the display control unit-generat ed image can be checked by the display of a color
bar and a gray scale.
If RGB signal is malfunctioning, the tint of the color bar display is as follows.
SKIB8642E
SKIB7874E
SKIA4220E
SKIB7777E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 668 of 3924

NAVIGATION SYSTEMAV-121
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
AV
N
O P
VEHICLE SIGNALS
A comparison check can be made of each actual vehicle signal and
the signals recognized by the display control unit.
NOTE:
In case of confirming light signal, set the following D/N mode to ON/
OFF of lighting switch (normal setting).
OFF: D (Day mode)
ON: N (Night mode)
Unless above setting, light signal (ON/OFF) may not be accurately
displayed.
AUTO CLIMATE CONTROL
Refer to ATC-43, "Self-Diagnosis Function".
NAVIGATION
Each diagnosis is shown by selecting each screen switch on Confir-
mation/Adjustment screen.
Display Diagnosis
R (red) signal error : Light blue (Cyan) tint
G (green) signal error : Purple (Magenta) tint
B (blue) signal error : Yellow tint
SKIB7778E
Diagnosis item Display Condition Remarks
Vehicle Speed ON When vehicle speed is more than 0 km/h (0 MPH)
Changes in indication may be delayed.
This is normal.
OFF When vehicle speed is 0 km/h (0 MPH)
— Ignition switch in ACC position
IGN ON Ignition switch ON
—
OFF Ignition switch ACC position
Reverse ON Selector lever in R position
Changes in indication may be delayed.
This is normal.
OFF Selector lever in any position other than R position
— Ignition switch in ACC position
IVCS OFF — This vehicle does not use it.
Light ON Lighting switch ON
—
OFF Lighting switch OFF
SKIB7386E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 669 of 3924

AV-122
< SERVICE INFORMATION >
NAVIGATION SYSTEM
Color tone and shading of the NAVI control unit-generated image can be checked by the display of a color bar
and a gray scale.
If RGB signal is malfunctioning, the tint of the color bar display is as follows.
Vehicle Signals
A comparison check can be made of each actual vehicle signal and
the signals recognized by the NAVI control unit.
Navigation
Steering Angle AdjustmentR (red) signal error : Light blue (Cyan) tint
G (green) signal error :
Purple (Magenta) tint
B (blue) signal error : Yellow tint
SKIB6976E
SKIB6977E
Diagnosis item Display Condition Remarks
Vehicle speed ON When vehicle speed is more than 0 km/h (0 MPH)
Changes in indication may be delayed.
This is normal.
OFF When vehicle speed is 0 km/h (0 MPH)
— Ignition switch in ACC position
Lights ON Lighting switch ON
—
OFF Lighting switch OFF
Ignition ON Ignition switch ON
—
OFF Ignition switch ACC position
Reverse ON Selector lever in R position
Changes in indication may be delayed.
This is normal.
OFF Selector lever in any position other than R position
— Ignition switch in ACC position
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 670 of 3924

NAVIGATION SYSTEMAV-123
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
AV
N
O P
The steering angle output value detected by the gyroscope can be
adjusted.
Speed Calibration
Usually the automatic distance correction function adjusts the mal-
function in distance caused by the tires wearing down or the tire
pressure change. If prompt adjus tment is necessary when the tire
chains are installed, et c., perform this procedure.
Error History
Diagnosis results of self-diagnosis depend on if any error occurred during the time after selecting “Self Diag-
nosis” until self-diagnosis results is displayed.
Meanwhile, when an error occurs before selecting “Sel f Diagnosis”, and if an error does not occur until self-
diagnosis results is displayed, a diagnosis result is judged as normal.
Consequently, a diagnosis needs to be performed with “Error His tory” for the past error that is not available
with self-diagnosis.
“Error History” displays the time and place of the most re cent occurrence of that error. However, take note of
the following points.
Correct time of the error occurrence may not be displayed when the GPS antenna substrate within the NAVI
control unit has malfunctioned.
Place of the error occurrence is represented by the pos ition of the vehicle mark at the time when the error
occurred. If the vehicle mark has deviated from the co rrect position, then the place of the error occurrence
may not be located correctly.
When the ignition switch is turned ON if the error is det ected, the counter increases 1. Even if it is normal
when the ignition switch is turned ON t he next time, the counter does not decrease.
The upper limit of the counter is 50. 51 or more is displayed as 50. It can be reset to 0 by “Delete log” switch.
SKIB3684E
SKIB3685E
SKIB6978E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 671 of 3924

AV-124
< SERVICE INFORMATION >
NAVIGATION SYSTEM
Diagnosis by Error History
When having a difficulty on the investigation of cause due to multiple errors with a reproducible malfunction,
turn ON the ignition switch from OFF mode after maki ng a memo of the item and number of time (or delete
“Error History”). Check “Error History” again afte r the malfunction was reproduced, and then perform diagno-
sis focusing on the item of which number of time increased.
DVD-ROM error history may be restored because DV D-ROM cannot be temporarily read. (Driving on rough
road etc.) Then, erase the error history. (This is not a ma lfunction.) Perform service in “Action to take” if error
history are repeatedly indicated again.
Delete Unit Connection Log
Error item Possible cause Action to take
GPS Antenna Error GPS antenna connection malfunction
is detected.1. Start self-diagnosis, and make sure
of the result.
2. If any error is found, GO TO 3. If any
error is not found, delete the error
history and end the diagnosis. (This
is not a malfunction.)
3. Check if GPS antenna feeder line is snapped or pinched.
4. If the results from the above checkup
show no malfunction, replace GPS
antenna, and then restart self-diag-
nosis.
5. If self-diagnosis results still show any malfunction, replace NAVI control
unit.
FLASH-ROM Error Of Control Unit
NAVI control unit malfunction is detect-
ed.1. Start self-diagnosis, and make sure
of the result.
2. If any error is found, replace NAVI control unit. Refer to AV- 1 4 1 , "
Re-
moval and Installation of NAVI Con-
trol Unit". If any error is not found,
delete the error history and end the
diagnosis. (This is not a malfunc-
tion.)
Connection Of Gyro
GPS Communication Error
GPS malfunction is detected.If the symptoms such as the GPS receipt
malfunction occur, intermittent malfunc-
tion caused by strong radio interference
may be detected.
If the malfunction always occurs, replace
NAVI control unit.
GPS ROM Error
GPS RAM Error
GPS RTC Error
DVD-ROM Mechanism not Detected
Malfunction is detected on DVD-ROM drive pickup lens in NAVI con-
trol unit.
There is dirt and damage on the DVD-ROM. 1. Check if the inse
rted DVD-ROM is
specified for this navigation system,
and the DVD-ROM is dirty, scratched
or warped.
2. If the results from the above checkup show no malfunction, insert the
same DVD-ROM, and then restart
self-diagnosis.
3. If self-diagnosis results still show any
malfunction, replace NAVI control
unit.
DVD-ROM Communication Error
DVD-ROM Mechanism Error
DVD-ROM Focus Error
DVD-ROM TOC Error
DVD-ROM Disc Error
DVD-ROM Seek Error
DVD-ROM Error Correction Error
DVD-ROM Read Error
DVD-ROM Data Transfer Error
DVD-ROM Data Error
DVD-ROM Loading / Eject Error
DVD-ROM Time-out
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
Page 672 of 3924

NAVIGATION SYSTEMAV-125
< SERVICE INFORMATION >
C
DE
F
G H
I
J
L
M A
B
AV
N
O P
Erase the connection history of unit and error history that is recorded
in NAVI control unit (clear the connection history of the removed
unit).
CAN Diagnostic Support MonitorINFOID:0000000001328756
OPERATION PROCEDURE
1. Start the engine.
2. Turn the audio system OFF.
3. While pressing the “4” button, turn the volume control dial clock- wise or counterclockwise for 30 clicks or more. (When the self-
diagnosis mode is started, a short beep will be heard.)
Shifting from current screen to previous screen is performedby pressing “BACK” button.
4. The initial trouble diagnosis screen will be shown, and items “Self Diagnosis (DCU)”, “Self Diagnosis (NAVI)”, “Confirmation/
Adjustment” and “CAN DIAG SUPPORT MONITOR” will
become selective.
5. Select “CAN DIAG SUPPORT MONITOR”.
6. The transmitting/receiving of CAN communication can be moni- tored.
SKIB6979E
SKIB8642E
SKIB7874E
Item Content Error counter
(Reference value)
CAN_COMM OK/NG 0 - 50
CAN_CIRC_1 OK/UNKWN 0 - 50
CAN_CIRC_2 OK/UNKWN 0 - 50
CAN_CIRC_3 OK/UNKWN 0 - 50
CAN_CIRC_4 OK/UNKWN 0 - 50
CAN_CIRC_5 OK/UNKWN 0 - 50
CAN_CIRC_6 OK/UNKWN 0 - 50
CAN_CIRC_7 OK/UNKWN 0 - 50
SKIA4288E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C
