2008 INFINITI FX35 section pg

ACC-1
ENGINE
C
DE
F
G H
I
J
K L
M
SECTION ACC
A
ACC
N
O P
CONTENTS
ACCELERATOR CONTROL SYSTEM
SERVICE INFORMATION .. ..........................2
PRECAUTIONS .............................................. .....2
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
2
ACCELERATOR CONTROL SYSTEM ..............3
Component .......................................................... .....3
Removal and Installation ..........................................3
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

ACS-1
ELECTRICAL
C
DE
F
G H
I
J
L
M
SECTION ACS
A
B
ACS
N
O P
CONTENTS
AUTO CRUISE CONTROL SYSTEM
ASCD
SERVICE INFORMATION .. ..........................
3
AUTOMATIC SPEED CONTROL DEVICE
(ASCD) ........................................................... .....
3
Description .......................................................... ......3
ICC
SERVICE INFORMATION .. ..........................
4
DTC INDEX ..................................................... .....4
DTC 11 - 65 ......................................................... ......4
DTC 74 - 109 .............................................................4
PRECAUTIONS ...................................................5
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
5
Precaution for ICC System Service ...........................5
PREPARATION ...................................................6
Special Service Tool ........................................... ......6
DESCRIPTION ....................................................7
Outline ................................................................. ......7
Functional Diagram ...................................................7
Component Description .............................................9
CAN Communication .................................................9
Switch Operation .....................................................10
ICC System Display ................................................10
ACTION TEST ....................................................11
ICC System Running Test ................................... ....11
LASER BEAM AIMING ADJUSTMENT .............14
Outline ................................................................. ....14
Preparation ..............................................................14
Outline of Adjustment Procedure ............................14
Setting the ICC Target Board ..................................14
Aiming Adjustment ..................................................16
ELECTRICAL UNITS LOCATION ....................18
Component Parts and Harness Connector Loca-
tion ....................................................................... ....
18
WIRING DIAGRAM ...........................................19
Schematic ................................................................19
Wiring Diagram - ICC - ............................................20
TERMINALS AND REFERENCE VALUE .........27
Terminal and Reference Value for ICC Unit ............27
Terminal and Reference Value for ICC Sensor ... ....28
TROUBLE DIAGNOSIS — GENERAL DE-
SCRIPTION .......................................................
29
Work Flow ................................................................29
CONSULT-III Function (ICC) ...................................29
Self-Diagnostic Function ..........................................32
TROUBLE DIAGNOSIS FOR SELF-DIAG-
NOSTIC ITEMS .................................................
35
Diagnostic Trouble Code (DTC) Chart ....................35
DTC 11 CONTROL UNIT ........................................36
DTC 20 CAN COMM CIRCUIT ................................36
DTC 31 POWER SUPPLY CIR, DTC 34 POWER
SUPPLY CIR 2 ........................................................
37
DTC 41 VHCL SPEED SE CIRC .............................37
DTC 43 ABS/TCS/VDC CIRC .................................38
DTC 45 BRAKE SW/STOP L SW ............................38
DTC 46 OPERATION SW CIRC ......................... ....40
DTC 61 PRESS SEN CIRCUIT ...............................41
DTC 62 BOOSTER SOL/V CIRCUIT .................. ....42
DTC 63 RELEASE SW CIRCUIT ............................43
DTC 65 PRESSURE CONTRO L .............................45
DTC 74 LASER BEAM OFF CNTR ..................... ....45
DTC 90 STOP LAMP RLY FIX ................................46
DTC 92 ECM CIRCUIT ............................................50
DTC 96 NP RANGE ................................................51
DTC 97 AT CIRCUIT ...............................................52
DTC 98 GEAR POSITION .......................................52
DTC 102 RADAR STAIN .........................................53
DTC 103 LASER SENSOR FAIL .............................53
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-1
TRANSMISSION/TRANSAXLE
DE
F
G H
I
J
K L
M
SECTION AT
A
B
AT
N
O P
CONTENTS
AUTOMATIC TRANSMISSION
SERVICE INFORMATION .. ..........................5
INDEX FOR DTC ............................................ .....5
Alphabetical Index ............................................... ......5
DTC No. Index ..........................................................5
PRECAUTIONS ...................................................7
Precaution for Supplemental Restraint System
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" ............................................................. ......
7
Precaution for On Board Diagnosis (OBD) System
of A/T and Engine .....................................................
7
Precaution .................................................................7
Service Notice or Precaution .....................................8
PREPARATION ...................................................9
Special Service Tool ........................................... ......9
Commercial Service Tool ..........................................9
A/T FLUID ...........................................................11
Changing A/T Fluid ............................................. ....11
Checking A/T Fluid ..................................................11
A/T Fluid Cooler Cleaning .......................................13
A/T CONTROL SYSTEM ....................................16
Cross-Sectional View (2WD Models) .................. ....16
Cross-Sectional View (VQ35DE Models for AWD) ....17
Cross-Sectional View (VK45DE Models for AWD) ....18
Shift Mechanism .................................................. ....18
TCM Function ..........................................................29
CAN Communication ...............................................30
Input/Output Signal of TCM .....................................31
Line Pressure Control .............................................31
Shift Control ............................................................33
Lock-up Control .......................................................34
Engine Brake Control ..............................................35
Control Valve ...........................................................36
ON BOARD DIAGNOSTIC (OBD) SYSTEM ......38
Introduction ......................................................... ....38
OBD-II Function for A/T System ..............................38
One or Two Trip Detection Logic of OBD-II ............38
OBD-II Diagnostic Trouble Code (DTC) .............. ....38
Malfunction Indicator Lamp (MIL) ............................40
TROUBLE DIAGNOSIS ....................................41
DTC Inspection Priority Chart ..................................41
Fail-Safe ..................................................................41
How to Perform Trouble Diagnosis for Quick and
Accurate Repair .......................................................
42
A/T Electrical Parts Location ...................................48
Circuit Diagram ........................................................49
Inspections Before Trouble Diagnosis .....................49
Road Test ................................................................53
Vehicle Speed at Which Gear Shifting Occurs ........58
Vehicle Speed at Which Lock-up Occurs/Releas-
es .............................................................................
58
Symptom Chart ........................................................59
TCM Input/Output Signal Reference Value .............83
CONSULT-III Function (TRANSMISSION) ..............84
Diagnosis Procedure without CONSULT-III ............91
DTC U1000 CAN COMMUNICATION LINE .....94
Description ........................................................... ....94
On Board Diagnosis Logic .......................................94
Possible Cause ........................................................94
DTC Confirmation Procedure ..................................94
Wiring Diagram - AT - CAN .....................................95
Diagnosis Procedure ...............................................96
DTC P0615 START SIGNAL CIRCUIT .............97
Description ...............................................................97
CONSULT-III Reference Value in Data Monitor
Mode ........................................................................
97
On Board Diagnosis Logic .......................................97
Possible Cause ........................................................97
DTC Confirmation Procedure ..................................97
Wiring Diagram - AT - STSIG ..................................98
Diagnosis Procedure ...............................................99
DTC P0700 TCM .............................................101
Description .............................................................101
On Board Diagnosis Logic .....................................101
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-8
< SERVICE INFORMATION >
PRECAUTIONS
After performing each TROUBLE DIAGNOSIS, perform “DTC
(Diagnostic Trouble Code) Confirmation Procedure”.
If the repair is completed the DTC should not be displayed in
the “DTC Confirmation Procedure”.
 Always use the specified brand of ATF. Refer to MA-9, "
Fluids and Lubricants".
 Use lint-free paper not cloth rags during work.
 After replacing the ATF, dispose of the waste oil using the methods prescribed by law, ordinance, etc.
 Before proceeding with disassembly, thoroughly clean the out side of the transmission. It is important to pre-
vent the internal parts from becoming cont aminated by dirt or other foreign matter.
 Disassembly should be done in a clean work area.
 Use lint-free paper or towels for wiping parts clean. Common shop rags can leave fibers that could interfere
with the operation of the transmission.
 Place disassembled parts in order for easier and proper assembly.
 All parts should be carefully cleansed with a general purpose, non-flammable solvent before inspection or
reassembly.
 Gaskets, seals and O-rings should be replaced any time the transmission is disassembled.
 It is very important to perform functional tests whenever they are indicated.
 The valve body contains precision parts and requires extreme care when parts are removed and serviced. Place disassembled valve body parts in order for easier and proper assembly. Care will also prevent springs
and small parts from becoming scattered or lost.
 Properly installed valves, sleeves, plugs, etc. will s lide along bores in valve body under their own weight.
 Before assembly, apply a coat of recommended ATF to all parts. Apply petroleum jelly to protect O-rings and
seals, or hold bearings and washers in place during assembly. Do not use grease.
 Extreme care should be taken to avoid damage to O-rings, seals and gaskets when assembling.
 After overhaul, refill the transmission with new ATF.
 When the A/T drain plug is removed, only some of t he ATF is drained. Old ATF will remain in torque con-
verter and ATF cooling system.
Always follow the procedures under “Changing A/T Fluid” in the AT section when changing A/T fluid. Refer to
AT- 11 , "
Changing A/T Fluid", AT- 11 , "Checking A/T Fluid".
Service Notice or PrecautionINFOID:0000000001327125
ATF COOLER SERVICE
If ATF contains frictional material (clutches, bands, etc. ), or if an A/T is repaired, overhauled, or replaced,
inspect and clean the A/T fluid cooler mounted in the radiat or or replace the radiator. Flush cooler lines using
cleaning solvent and compressed air after repair. For A/T fluid cooler cleaning procedure, refer to AT-13, "
A/T
Fluid Cooler Cleaning". For radiator replacement, refer to CO-13 (for VQ35DE), CO-40 (for VK45DE).
OBD-II SELF-DIAGNOSIS
 A/T self-diagnosis is performed by the TCM in comb ination with the ECM. The results can be read through
the blinking pattern of the A/T CHECK indicator or the malfunction indicator lamp (MIL). Refer to the table on
AT-84, "
CONSULT-III Function (TRANSMISSION)" for the indicator used to display each self-diagnostic
result.
 The self-diagnostic results indicated by the MIL ar e automatically stored in both the ECM and TCM memo-
ries.
Always perform the procedure on AT-38, "
OBD-II Diagnostic Trouble Code (DTC)" to complete the
repair and avoid unnecessary blinking of the MIL.
For details of OBD-II, refer to EC-54
(for VQ35DE) or EC-632 (for VK45DE).
 Certain systems and components, especially those re lated to OBD, may use the new style slide-lock-
ing type harness connector. For descrip tion and how to disconnect, refer to PG-68
.
SEF217U
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-16
< SERVICE INFORMATION >
A/T CONTROL SYSTEM
A/T CONTROL SYSTEM
Cross-Sectional View (2WD Models)INFOID:0000000001327131
1. Front planetary gear 2. Mid planetary gear 3. Rear planetary gear
4. Direct clutch 5. High and low reverse clutch 6. Reverse brake
7. Drum support 8. Forward brake 9. Low coast brake
10. Input shaft 11. Torque converter 12. Oil pump
13. Front brake 14. 3rd one-way clutch 15. Input clutch
16. 1st one-way clutch 17. Control valve with TCM 18. Forward one-way clutch
19. Rear extension 20. Output shaft
SCIA5262E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

A/T CONTROL SYSTEMAT-17
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
Cross-Sectional View (VQ35DE Models for AWD)INFOID:0000000001327132
1. Front planetary gear 2. Mid planetary gear 3. Rear planetary gear
4. Direct clutch 5. High and low reverse clutch 6. Reverse brake
7. Drum support 8. Forward brake 9. Low coast brake
10. Input shaft 11. Torque converter 12. Oil pump
13. Front brake 14. 3rd one-way clutch 15. Input clutch
16. 1st one-way clutch 17. Control valve with TCM 18. Forward one-way clutch
19. Adapter case 20. Output shaft
SCIA5263E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

AT-18
< SERVICE INFORMATION >
A/T CONTROL SYSTEM
Cross-Sectional View (V K45DE Models for AWD)
INFOID:0000000001327133
Shift MechanismINFOID:0000000001327134
The A/T uses compact triple planetary gear systems to improve power transmission efficiency, simplify con-
struction and reduce weight.
It also employs an optimum shift control and super wide gear ratios. They improve starting performance and
acceleration during medium and high-speed operation.
CONSTRUCTION
1. Front planetary gear 2. Mid planetary gear 3. Rear planetary gear
4. Direct clutch 5. High and low reverse clutch 6. Reverse brake
7. Drum support 8. Forward brake 9. Low coast brake
10. Input shaft 11. Torque converter 12. Oil pump
13. Front brake 14. 3rd one-way clutch 15. Input clutch
16. 1st one-way clutch 17. Control valve with TCM 18. Forward one-way clutch
19. Adapter case 20. Output shaft
SCIA5268E
3AA93ABC3ACD3AC03ACA3AC03AC63AC53A913A773A893A873A873A8E3A773A983AC73AC93AC03AC3
3A893A873A873A8F3A773A9D3AAF3A8A3A8C3A863A9D3AAF3A8B3A8C

TROUBLE DIAGNOSISAT-59
< SERVICE INFORMATION >
DE
F
G H
I
J
K L
M A
B
AT
N
O P
 At closed throttle, the accelerator opening is less than 1/8 condition. (Closed throttle position signal: OFF)
 At half throttle, the accelerator opening is 4/8 of the full opening.
 At closed throttle, the accelerator opening is less than 1/8 condition. (Closed throttle position signal: OFF)
 At half throttle, the accelerator opening is 4/8 of the full opening.
Symptom ChartINFOID:0000000001327161
 The diagnostics item numbers show the sequence for inspection. Check in order from item 1.
 Overhaul and check inside the A/T only if A/T fluid condition is NG. Refer to AT-49, "
Inspections Before Trou-
ble Diagnosis".
Engine model VK45DE
Throttle positionVehicle speed km/h (MPH)
Lock-up ON Lock-up OFF
Closed throttle 66 - 74 (41 - 46) 53 - 61 (33 - 38)
Half throttle 191 - 199 (119 - 124) 145 - 153 (90 - 95)
No. Items Symptom Condition Diagnostic Item Reference
page
1 Shift
Shock Large shock. (“N”
→
“D” position)
Refer to AT- 1 7 3 ,
"Large Shock ("N" to
"D" Position)". ON vehicle 1. Engine idle speed
EC-84
(for
VQ35DE)
or EC-661

(for
VK45DE)
2. Engine speed signal AT- 11 2
3. Accelerator pedal position sensorAT- 1 3 0
4. A/T positionAT- 2 0 7
5. A/T fluid temperature sensorAT- 1 3 2
6. Front brake solenoid valveAT- 1 4 5
7. CAN communication line AT- 9 4
8. A/T fluid level and stateAT- 4 9
9. Line pressure testAT- 4 9
10. Control valve with TCMAT- 2 1 5
OFF vehicle11. Forward brake (Parts behind drum support is impossible
to perform inspection by disassembly. Refer to
AT- 1 6 , "
Cross-
Sectional View (2WD Models)", AT- 1 7 , "Cross-Sectional View
(VQ35DE Models for AWD)" or AT- 1 8 , "Cross-Sectional View
(VK45DE Models for AWD)") AT- 2 6 7
2
Shock is too large
when changing D1
→
D
2 or M1 → M2. ON vehicle 1. Accelerator pedal position sensor
AT- 1 3 0
2. A/T positionAT- 2 0 7
3. Direct clutch solenoid valveAT- 1 4 7
4. CAN communication line AT- 9 4
5. Engine speed signalAT- 11 2
6. Turbine revolution sensorAT- 1 0 6
7. Vehicle speed sensor A/T and vehicle speed sensor MTRAT- 1 0 8,
AT- 1 3 7
8. A/T fluid level and state AT- 4 9
9. Control valve with TCMAT- 2 1 5
OFF vehicle 10. Direct clutch AT- 3 0 3
