Page 1 of 2248

SUBARU LEGACY 1995 Service Repair Manual G2M0544 1. Front Catalytic Converter A: REMOVAL 1) Disconnect front oxygen sensor connector. B2M0312 2) Lift-up the vehicle. 3) Disconnect rear oxygen sensor connector. B2M0055 4) Separate center exha

Page 2 of 2248

SUBARU LEGACY 1995 Service Repair Manual B2M0060 7) Separate front catalytic converter from front exhaust pipe and center exhaust pipe. B2M0060 B: INSTALLATION CAUTION: Replace gaskets with new ones. 1) Install front catalytic converter to f

Page 3 of 2248

SUBARU LEGACY 1995 Service Repair Manual B2M0313 5) Tighten bolt which holds center exhaust pipe to hanger bracket. Tightening torque: 35±5 N⋅m (3.6±0.5 kg-m, 26.0±3.6 ft-lb) B2M0312 6) Connect rear oxygen sensor connector. G2M0544 7) L

Page 4 of 2248

SUBARU LEGACY 1995 Service Repair Manual B2M0313 5) Tighten bolt which holds center exhaust pipe to hanger bracket. Tightening torque: 35±5 N⋅m (3.6±0.5 kg-m, 26.0±3.6 ft-lb) B2M0312 6) Connect rear oxygen sensor connector. G2M0544 7) L

Page 5 of 2248

SUBARU LEGACY 1995 Service Repair Manual B2M0421 4) Separate center exhaust pipe and rear catalytic con- verter assembly from front catalytic converter. B2M0313 5) Remove center exhaust pipe and rear catalytic con- verter assembly from hange

Page 6 of 2248

SUBARU LEGACY 1995 Service Repair Manual B2M0313 4) Tighten bolt which holds center exhaust pipe to hanger bracket. Tightening torque: 35±5 N⋅m (3.6±0.5 kg-m, 26.0±3.6 ft-lb) B2M0312 5) Connect rear oxygen sensor connector. G2M0375 3. C

Page 7 of 2248

SUBARU LEGACY 1995 Service Repair Manual B2M0313 4) Tighten bolt which holds center exhaust pipe to hanger bracket. Tightening torque: 35±5 N⋅m (3.6±0.5 kg-m, 26.0±3.6 ft-lb) B2M0312 5) Connect rear oxygen sensor connector. G2M0375 3. C

Page 8 of 2248

SUBARU LEGACY 1995 Service Repair Manual B2M0313 4) Tighten bolt which holds center exhaust pipe to hanger bracket. Tightening torque: 35±5 N⋅m (3.6±0.5 kg-m, 26.0±3.6 ft-lb) B2M0312 5) Connect rear oxygen sensor connector. G2M0375 3. C
