Page 369 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO21B-01 H04847 : 9 Clips ba a - a b - b ab H04848 : 10 Clips H04076 BO-66 - BODYBACK DOOR GLASS 2640 Author: Date: 2004 LAND CRUISER (RM1071U) REMOVAL 1. REMOVE ASSIST GRIP (a) Using a screwdrive

Page 370 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO5232 H04077 Protective Tape - BODYBACK DOOR GLASS BO-67 2641 Author: Date: 2004 LAND CRUISER (RM1071U) 7. REMOVE BACK DOOR GLASS (a) Disconnect the connector. (b) Push piano wire through between

Page 371 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1JQ-03 H05391 150 mm (5.91 in.) - BODYBACK DOOR STAY BO-31 2605 Author: Date: 2004 LAND CRUISER (RM1071U) BACK DOOR STAY REPLACEMENT 1. REMOVE BACK DOOR STAY (a) Remove the bolts and back door s

Page 372 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1K1-02 H05285 Outside Quarter Moulding Upper Rear Outside Rear Door Moulding Outside Rear Door Moulding Outside Front Door Moulding Outside Front Fender Moulding - BODYBODY OUTSIDE MOULDING BO-43 26

Page 373 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1K3-02 H05286 Adhesive Tape Outside Front Fender MouldingOutside Front Door MouldingOutside Rear Door Moulding Adhesive Tape Upper Rear Outside Rear Door Moulding Adhesive Tape Outside Quarter Mould

Page 374 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO5229 - BODYBODY OUTSIDE MOULDING BO-47 2621 Author: Date: 2004 LAND CRUISER (RM1071U) (c) Press firmly on the moulding. Refer to the illustration for the moulding application procedures. NOTICE:

Page 375 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1K2-02 H05280 Adhesive Tape H05281 Adhesive Tape H05282 Adhesive Tape BO-44 - BODYBODY OUTSIDE MOULDING 2618 Author: Date: 2004 LAND CRUISER (RM1071U) REMOVAL 1. REMOVE OUTSIDE FRONT FENDER MOUL

Page 376 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual H05283 Adhesive Tape H05284 Adhesive Tape - BODYBODY OUTSIDE MOULDING BO-45 2619 Author: Date: 2004 LAND CRUISER (RM1071U) (c) Using a screwdriver, remove the moulding. HINT: Tape the screwdriver
