Page 545 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual F04478Pin
F04503
SST
- BRAKEHYDRAULIC BRAKE BOOSTER
BR-63
2199 Author: Date:
2004 LAND CRUISER (RM1071U)
8. REMOVE PISTON
(a) Pressing the piston in with a screwdriver, use a pin or an
equivalent

Page 546 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BR0TH-09
F04504
BA
A: 20 mm (0.791 in.)
B: 30 mm (1.18 in.)
- BRAKEHYDRAULIC BRAKE BOOSTER
BR-65
2201 Author: Date:
2004 LAND CRUISER (RM1071U)
DISPOSAL
DISPOSAL METHOD OF ACCUMULATOR
(a) Place th

Page 547 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BR120-08
F06051
1
2 BR-64
- BRAKEHYDRAULIC BRAKE BOOSTER
2200 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
INSPECT HYDRAULIC BRAKE BOOSTER PUMP MOTOR
OPERATION
(a) Connct the positive (+)

Page 548 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BR0KD-04
- BRAKEHYDRAULIC BRAKE BOOSTER
BR-67
2203 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page BR-60).
HINT:
After installatio

Page 549 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual F04470
Brake Pedal Effort Gauge
SST
SST
BR12B-07
BR-40
- BRAKEHYDRAULIC BRAKE BOOSTER
2176 Author: Date:
2004 LAND CRUISER (RM1071U)
HYDRAULIC BRAKE BOOSTER
ON-VEHICLE INSPECTION
1. CHECK HYDRAUL

Page 550 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual I24672
TOYOTA Hand-held Tester
- BRAKEHYDRAULIC BRAKE BOOSTER
BR-41
2177 Author: Date:
2004 LAND CRUISER (RM1071U)
(f) w/ ABS & TRAC & VSC ECU only, when booster operate:
(1) Turn the ignition swi

Page 551 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BR-42
- BRAKEHYDRAULIC BRAKE BOOSTER
2178 Author: Date:
2004 LAND CRUISER (RM1071U)
To protect the solenoids, TOYOTA hand-held tester turns
OFF automatically for 2 sec. after every solenoid has
b

Page 552 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - BRAKEHYDRAULIC BRAKE BOOSTER
BR-43
2179 Author: Date:
2004 LAND CRUISER (RM1071U)
(5) When the solenoids are OFF, check that the brake
pedal can be depressed.
If the pedal cannot be depressed, r

- BRAKEHYDRAULIC BRAKE BOOSTER
BR-43
2179 Author: Date:
2004 LAND CRUISER (RM1071U)
(5) When the solenoids are OFF, check that the brake
pedal can be depressed.
If the pedal cannot be depressed, replace the hydraulic brake
booster.
(6) Once, release the brake pedal. After depressing
and holding the brake pedal with stable force, turn
the SFLH and SFLR solenoids ON simultaneously.
HINT:
To protect the solenoids, TOYOTA hand-held tester turns OFF
automatically for 2 sec. after every solenoid has been turned
ON.
(7) Once release the brake pedal when the solenoids
are OFF, check that the brake pedal can be de-
pressed.
If the pedal cannot be depressed, replace the hydraulic brake
booster.
(g) Jack up and support the vehicle.
(h) Release the parking brake lever.
(i) Inspect the rear ABS solenoid.
(1) Select the ºSRHº on the TOYOTA hand-held tester.
(2) Turn the ºSRHº ON with the TOYOTA hand-held
tester and depress the brake pedal with stable
force, and rotate the right rear wheel by hand and
check it.
HINT:
To protect the solenoids, TOYOTA hand-held tester turns
OFF automatically for 2 sec. after every solenoid has
been turned ON.
When rotating the wheel fast, the fail-safe function is acti-
vated and judgement cannot be made properly. So rotate
the wheel as slowly as possible.
When solenoid is OFF, the wheel might stop temporarily.
However if the wheel rotates again, the function works
normally.
If the rear wheels stop, replace the hydraulic brake booster.
(3) Once, release the brake pedal and turn the ºSRHº
OFF, after depressing the brake pedal with stable
force and stop the rear right wheel by hand and
check it.
If the rear wheel rotate, replace the hydraulic brake booster.
(4) Depress the pedal with stable force, then turn the
ºSRHº and ºSRRº ON simultaneously.
(5) When the solenoids are ON, rotate the rear wheel
by hand and check it.
HINT:
To protect the solenoids, TOYOTA hand-held tester turns
OFF automatically for 2 sec. after every solenoid has
been turned ON.
