2. DTC CHECK (Normal Mode)
NOTICE:
If no DTC appears in normal mode:
On the OBD ll scan tool or the hand-held tester check
the pending fault code using the Continuous Test Re-
sults function (Mode 7 for SAE J1979).
When the diagnosis system is changed from normal
mode to check mode or vice-versa, all DTCs and
freeze frame data recorded in normal mode will be
erased. Before changing modes, always check and
make a note of DTCs and freeze frame data.
(a) Checking DTCs using the OBD II scan tool or hand-held
tester.
(1) Connect the OBD II scan tool or the hand-held tes-
ter to DLC3.
(2) Turn the ignition switch ON.
(3) Use the OBD II scan tool or the hand-held tester to
check the DTCs and freeze frame data and then
write them down.
For the hand-held tester, enter the following me-
nus: DIAGNOSIS / ENHANCED OBD II / DTC INFO
/ CURRENT CODEDS. For the OBD II scan tool,
see its instruction manual.
(4) See page DI-36 to confirm the details of the
DTCs.
NOTICE:
When simulating a symptom with the OBD II scan tool (ex-
cluding hand-held tester) to check the DTCs, use the nor-
mal mode. For DTCs chart subject to º2 trip detection log-
icº, perform either of the following actions.
Check the pending fault code:
For the hand-held tester, enter the following menus:
DIAGNOSIS / ENHANCED OBD II / DTC INFO / PEND-
ING CODES.
Turn the ignition switch OFF after the symptom is
simulated once. Then repeat the simulation process
again. When the problem has been simulated twice,
the MIL comes on and the DTCs are recorded in the
ECM.
Page 1410 of 3115

A07061DLC3
Hand-Held Tester
BR3904
0.13 sec.0.13 sec.
ON
OFF
- DIAGNOSTICSENGINE
DI-7
200 Author: Date:
Check the pending fault code using the Continuous
Test Results function (Mode 7 for SAE J1979) on the
OBD II scan tool.
(b) Clearing the DTCs using the OBD II scan tool or the
hand-held tester.
(1) Connect the OBD II scan tool or the hand-held tes-
ter to the DLC3.
(2) Turn the ignition switch ON.
(3) Erase DTCs and freeze frame data with the OBD II
scan tool (complying with SAE J1978) or the hand-
held tester. For the hand-held tester: 1) enter the
following menus: DIAGNOSIS / ENHANCED OBD
II / DTC INFO / CLEAR CODES; and 2) press YES.
For the OBD II scan tool, see its instruction manual.
(c) Clearing the DTCs not using the OBD II scan tool or the
hand-held tester.
Remove the EFI or ECD No. 1 and ETCS fuses from the
engine room J/B for more than 60 seconds, or disconnect
the battery terminal for more than 60 seconds.
After disconnecting the battery terminal, perform the ºINI-
TIALIZE procedure.
3. DTC CHECK (Check Mode)
HINT:
Hand-held tester only:
Check mode has a higher sensitivity to detect malfunctions and
can detect malfunctions that normal mode cannot detect.
Check mode can also detect all the malfunctions that normal
mode can detect.
(a) Follow these steps when preparing to use the hand-held
tester check mode.
(1) Make sure that the items below are true:
Battery positive voltage 11 V or more
Throttle valve fully closed
Transmission in the P or N position
A/C switched OFF
(2) Turn the ignition switch OFF.
(3) Connect the hand-held tester to the DLC3.
(4) Turn the ignition switch ON.
(5) Change the ECM to check mode with the hand-
held tester. Enter the following menus: DIAGNOSIS
/ ENHANCED OBD II / CHECK MODE. Make sure
the MIL flashes as shown in the illustration.
NOTICE:
All DTCs and freeze frame data recorded will be erased if:
1) the hand-held tester is used to change the ECM from
normal mode to check mode or vice-versa; or 2) during
check mode, the ignition switch is turned from ON to ACC
or OFF.
Page 1411 of 3115

DI-8
- DIAGNOSTICSENGINE
201 Author: Date:
(6) Start the engine. The MIL should turn off after the
engine starts.
(7) Simulate the conditions of the malfunction de-
scribed by the customer.
(8) After simulating the malfunction conditions, use the
hand-held tester diagnosis selector to check the
DTC, freeze frame data and other data.
(9) After checking the DTC, inspect the applicable cir-
cuit.
(b) Clearing DTCs using the OBD ll scan tool or the hand-
held tester.
(1) Connect the OBD ll scan tool or the hand-held tes-
ter to the DLC3.
(2) Turn the ignition switch ON.
(3) Erase DTCs and freeze frame data with the OBD II
scan tool (complying with SAE J1978) or the hand-
held tester. For the hand-held tester: 1) enter the
following menus: DIAGNOSIS ENHANCED OBD II
/ DTC INFO / CLEAR CODES; and 2) press YES.
For the OBD II scan tool, see its instruction manual.
(c) Clearing the DTCs without using the OBD ll scan tool or
the hand-held tester.
Remove the EFI or ECD No. 1 and ETCS fuses from the
engine room J/B for more than 60 seconds, or disconnect
the battery terminal for more than 60 seconds.
After disconnecting the battery terminal, perform the ºINI-
TIALIZEº procedure.
4. FAIL-SAFE CHART
If any of the following code is recorded, the ECM enters fail-safe mode.
DTC No.Fail-Safe OperationFail-Safe Deactivation Conditions
P0031
P0032
P0037
P0038
P0051
P0052
P0057
P0058
The heater circuit in which an abnormality is detected is
turned offIgnition switch OFF
P0100
P0102
P0103Ignition timing is calculated from engine speed and throttle
angleºPassº condition detected
P0110
P0112
P0113
Intake air temperature is fixed at 20°C (68°F)ºPassº condition detected
P0115
P0117
P0118
Engine coolant temperature is fixed at 80°C (176°F)ºPassº condition detected
Page 1412 of 3115

- DIAGNOSTICSENGINE
DI-9
202 Author: Date:
P0120
P0121
P0122
P0123
P0220
P0222
P0223
P0607
P0657
P2102
P2103
P2111
P2112
P2118
P2119
P2135
If the Electronic Throttle Control System (ETCS) has a mal-
function, the ECM cuts off current to the throttle control
motor. The throttle control valve returns to a predetermined
opening angle (approximately 16) by the force of the return
spring. The ECM then adjusts the engine output by control-
ling the fuel injection (intermittent fuel-cut) and ignition tim-
ing in accordance with the accelerator pedal opening angle
to enable the vehicle to continue at a minimal speed.
If the accelerator pedal is depressed firmly and slowly, the
vehicle can be driven slowly. If the accelerator pedal is
depressed quickly, the vehicle may speed up and slow
down erratically.
ºPassº condition is detected and then the ignition switch is
turned OFF.
P0325
P0330Max. timing retardationIgnition switch OFF
P0351
P0352
P0353
P0354
P0355
P0356
P0357
P0358
Fuel cutºPassº condition detected
P2120
P2121
P2122
P2123
P2125
P2127
P2128
P2138
The accelerator pedal position sensor has two (main and
sub) sensor circuits. If a malfunction occurs in either of the
sensor circuits, the ECM detects the abnormal signal volt-
age difference between the two sensor circuits and
switches to limp mode. In limp mode, the remaining circuit
is used to calculate the accelerator pedal opening to allow
the vehicle to continue driving.
If both circuits malfunction, the ECM regards the opening
angle of the accelerator pedal to be fully closed. In this
case, the throttle valve will remain closed as if the engine is
idling.
ºPassº condition is detected and the ignition switch is turned
OFF.
5. CHECK FOR INTERMITTENT PROBLEMS
Hand-held tester only:
Inspect the vehicle's ECM using check mode. Intermittent problems are easier to detect when the ECM is
in check mode with hand-held tester. In check mode, the ECM uses 1 trip detection logic, which has a higher
sensitivity to malfunctions than normal mode (default), which uses 2 trip detection logic.
(a) Clear the DTCs. (See step 2)
(b) Set the check mode. (See step 3)
(c) Perform a simulation test (See page IN-26).
(d) Check the connector and terminal (See page IN-36).
(e) Wiggle the harness and connector (See page IN-36).
Page 1413 of 3115
DI-10
- DIAGNOSTICSENGINE
203 Author: Date:
6. BASIC INSPECTION
When the malfunction is not confirmed in the DTC check, troubleshooting should be carried out in all the
possible circuits considered as causes of the problem. In many cases, by carrying out the basic engine check
shown in the following flowchart, the location causing the problem can be found quickly and efficiently. There-
fore, using this check is essential in the engine troubleshooting.
1 Is battery positive voltage 11 V or more when engine stopped?
NO Charge or replace battery.
YES
2 Is engine cranked?
NO Proceed to page ST-16 and ST-18, and contin-
ue to troubleshoot.
YES
3 Does engine start?
NO Go to step 6.
YES
Page 1414 of 3115
- DIAGNOSTICSENGINE
DI-1 1
204 Author: Date:
4 Check air filter.
PREPARATION:
Remove the air filter.
CHECK:
Visual check that the air filter is not excessively dirty or oily.
NG Repair or replace
air filter.
OK
5 Check idle speed.
PREPARATION:
(a) Warm up the engine to the normal operating temperature.
(b) Switch off all the accessories.
(c) Switch off the A/C.
(d) Shift the transmission into the N position.
(e) Connect the OBD II scan tool or hand-held tester to the DLC3 of the vehicle.
CHECK:
Use CURRENT DATA to check the idle speed.
OK:
Idle speed:
650 to 750 rpm
NG Proceed to problem symptoms table on page
DI-48.
OK
Page 1415 of 3115
B04440
UpScrew
Pulsation
Damper
DI-12
- DIAGNOSTICSENGINE
205 Author: Date:
6 Check fuel pressure.
PREPARATION:
(a) Be sure that enough fuel is in the tank.
(b) Connect the hand-held tester to the DLC3.
(c) Turn the ignition switch ON and push the hand-held tes-
ter main switch ON.
(d) Use the ACTIVE TEST mode to operate the fuel pump.
(e) Please refer to the hand-held tester operator's manual
for further details.
(f) If you have no hand-held tester, connect the positive (+)
and negative (-) leads from the battery to the fuel pump
connector (See page SF-7).
CHECK:
Check that the pulsation damper screw rises up when the fuel
pump operation (See page SF-7).
HINT:
At this time, you will hear a fuel flowing noise.
NG Proceed to page SF-7 and continue to trouble-
shoot.
OK
Page 1416 of 3115
A19431
A19884
- DIAGNOSTICSENGINE
DI-13
206 Author: Date:
7 Check for spark.
PREPARATION:
(a) Disconnect the ignition coil.
(b) Remove the spark plug.
(c) Install the spark plug to the ignition coil.
(d) Disconnect the injector connector.
(e) Ground the spark plug.
CHECK:
Check if spark occurs while the engine is being cranked.
NOTICE:
To prevent excess fuel from being injected from the injec-
tors during this test, don't crank the engine for more than
5 to 10 seconds at a time.
NG Proceed to page IG-1 and continue to trouble-
shoot.
OK
Proceed to problem symptoms table on page
DI-48.
