Page 1777 of 3115

START
The vehicle should be in the following conditions:
Ignition switch ON
Hand-held tester operation:
1. Select ºL/C 100º from the menu.
2. Select ºTDSº (Theft Deterrent System).
3. Select ºWIRELESS REGISTRATIONº.
After the above operations, proceed to the succeeding operations
according to the prompts on the tester screen.
Transmitter SW Operation:
HINT: Perform this operation during the countdown screen.
Press both lock and unlock SW. (Between 1 and 1.5 sec.)
Press any one of SW. (For more than 1 sec.)
This wireless buzzer sounds when the registration is completed
normally.
Continue the registration.Register other transmitters?
Or
Finish the registration?
Finish the registration.
ENDHINT: Select the next step
on the tester screen.
Within 3 sec.
- DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
DI-943
1136 Author: Date:
(c) By TOYOTA Hand-Held Tester
HINT:
This page is to show briefly the registration procedure using the hand-held tester.
For detailed procedures, please refer to the prompts on the tester screen.
The number of currently registered codes can be checked out on the first screen of the WIRELESS REG-
ISTRATION.
Page 1778 of 3115

Close"open"close"open
START
The vehicle should be in the following conditions:
Driver door open (Other doors are closed).
Insert and remove the key into/from the ignition cylinder twice.
Insert"remove "insert"remove
HINT: If the IG switch operation is
not performed with the specified
number of times (If it is 4 times, 6
times or more), this operation is
finished with no response.
HINT: The registration operation is
cancelled if each operation is not
completed within the specified
time.
No key inserted in the IG key cylinder.
Close and open the driver door twice.
Close"open"close"open
Insert and remove the key into/from the ignition cylinder once.
Insert"remove
Insert the key into the ignition key cylinder.
Close all the doors.
Mode Selection
Turn the IG SW ON
u"LOCK once.Add modeTurn the IG SW ON
u"LOCK twice.Rewrite modeTurn the IG SW ON
u"LOCK 3 times. Confirmation modeTurn the IG SW ON
u"LOCK 5 times. Prohibition mode
Remove the key from the IG key cylinder.
Within 5 sec.
Within 40 sec.
Within 40 sec.
Within 40 sec.
Close and open the driver door twice. DI-944
- DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
1137 Author: Date:
(d) By Switch Operation:
Page 1779 of 3115

Add mode: Response of whether or not being moved to each mode is given with
the number of times of door lock working (lock/unlock).
Within 3 sec.
Within 40 sec.
Within 3 sec. Rewrite mode:
Confirmation mode:
Prohibition mode:once*1
twice*1
The number of times equivalent to the number
of currently registered codes*2
5 times*1
HINT: The confirmation mode and the prohibition mode are finished
after the responses.
Transmitter SW Operation:
Press both lock and unlock SW. (Between 1 and 1.5 sec.)
Press any one of SW. (For more than 1 sec.)
Response of whether or not the registration is completed is given in the
form of the number of times of door lock operations (lock/unlock opera-
tion).
Register other transmitters?
or
Finish the registration?
Finish the registration.
Within 3 sec.Confirmation mode
Prohibition mode
END Add mode,
Rewrite mode
When registration is completed:
When registration is not completed:once*1
twice*1
Insert the key into the IG key cylinder. Perform one of the following operations to finish the Add mode and the
Rewrite mode.
Open any one of the doors.
Wait for 40 sec. after the code registration.
HINT: In case of registering 4 codes at a time, the mode will be finished
when the 4
th code is registered. Continue
the registration.
Within 40 sec.
- DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
DI-945
1138 Author: Date:
Page 1780 of 3115

DI0DV-12
DI-948
- DIAGNOSTICSWIRELESS DOOR LOCK CONTROL SYSTEM
1141 Author: Date:
2004 LAND CRUISER (RM1071U)
PROBLEM SYMPTOMS TABLE
Perform troubleshooting of the circuit for the applicable problem symptom in the order given in the chart be-
low. Proceed to the page located for each circuit.
HINT:
Troubleshooting of the wireless door lock control system is based on the premise that the door lock
control system and theft deterrent system are operating normally. Accordingly, before troubleshooting
the wireless door lock control system, first make certain that the door lock control system and theft de-
terrent system are operating normally.
If the instruction ºProceed to next circuit inspection shown on matrix chartº is given in the flow chart
for each circuit, proceed to the circuit with the next highest number in the table to continue the check.
If the trouble still reappears even through there are no abnormalities in any of the other circuits, check
and replace the Wireless Door Lock ECU as the last step.
SymptomSuspect AreaSee page
All function of wireless door lock control system do no operate.
1. ECU Power Source Circuit.
2. Door Courtesy Switch Circuit.
3. Door Key Lock and Unlock Switch Circuit.
4. Key Unlock Warning Switch Circuit.
5. Wireless Door Lock ECU.
6. Body ECU (Main).DI-951
DI-1062
DI-1 106
DI-1060
IN-36
IN-36
Only door unlock operation is not possible (Lock operation is pos-
sible).
1. Door Key Lock and Unlock Switch Circuit
2. Door Unlock Detection Switch Circuit
3. Wireless Door Lock ECU.
4. Body ECU (Main).DI-1 106
DI-1060
IN-36
IN-36
Only door lock operation is not possible (Unlock operation is pos-
sible).1. Door Key Lock and Unlock Switch Circuit
2. Wireless Door Lock ECU
3. Body ECU (Main).DI-1 106
IN-36
IN-36
Only transmitter misoperation prevention function is not possible.
1. Key Unlock Warning Switch Circuit
2. Wireless Door Lock ECU
3. Body ECU (Main).DI-1060
IN-36
IN-36
Wireless door lock function operates even when each door is
opened.1. Door Courtesy Switch Circuit
2. Wireless Door Lock ECU
3. Body ECU (Main).DI-1062
IN-36
IN-36
Wireless door lock functions incorrectly.
(Although one door is unlocked, when the transmitter switch is
pressed, all doors unlock. )1. Door Unlock Detection Switch Circuit
2. Wireless Door Lock ECU
3. Body ECU (Main).DI-1060
IN-36
IN-36
Wireless door lock operates, but the taillight does not respond.
1. Taillight Relay Circuit
2. Taillight Circuit
3. Wireless Door Lock ECU
4. Body ECU (Main).DI-1076
DI-1076
IN-36
IN-36
Page 1781 of 3115
EC07H-02
- EMISSION CONTROLEMISSION CONTROL SYSTEM
EC-1
1689 Author: Date:
2004 LAND CRUISER (RM1071U)
EMISSION CONTROL SYSTEM
PURPOSE
The emission control systems are installed to reduce the amount of HC, CO and NOx exhausted from the
engine ((3) and (4)), to prevent the atmospheric release of blow-by gas-containing HC (1) and evaporated
fuel containing HC being released from the fuel tank (2).
The function of each system is shown in these table:
SystemAbbreviationFunction
(1) Positive Crankcase Ventilation
(2) Evaporative Emission Control
(3) Three-Way Catalytic Converter
(4) Sequential Multiport Fuel Injection*PCV
EVAP
TWC
SFIReduces HC
Reduces evaporated HC
Reduces HC, CO and NOx
Injects a precisely timed, optimum amount of fuel for reduced exhaust
emissions
Remark: * For inspection and repair of the SFI system, refer to the SF section in this manual.
Page 1782 of 3115

EC0MF-01
B04812
Gasket
B06544
Vacuum
Gauge
I24672
TOYOTA Hand-Held Tester
B06759
Battery
- EMISSION CONTROLEVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
EC-5
1693 Author: Date:
2004 LAND CRUISER (RM1071U)
EVAPORATIVE EMISSION (EVAP)
CONTROL SYSTEM
INSPECTION
1. INSPECT LINES AND CONNECTIONS
Visually check for loose connections, sharp bends or damage.
2. INSPECT FUEL TANK
Visually check for deformation, cracks or fuel leakage.
3. INSPECT FUEL TANK CAP
Visually check if the cap and/or gasket are deformed or dam-
aged.
If necessary, repair or replace the cap.
4. INSPECT EVAP SYSTEM LINE
(a) Warm up the engine and stop the engine.
Allow the engine to warm up to normal operating tempera-
ture.
(b) Install a vacuum gauge (EVAP control system test equip-
ment vacuum gauge) to the EVAP service port on the
purge line.
(c) TOYOTA Hand-Held tester:
Forced driving of the VSV for the EVAP.
(1) Connect a TOYOTA hand-held tester to the DLC3.
(2) Start the engine.
(3) Push the TOYOTA hand-held tester main switch
ON.
(4) Use the ACTIVE TEST mode on the TOYOTA
hand-held tester to operate the VSV for the EVAP.
(d) If you have no TOYOTA Hand-Held Tester:
Forced driving of the VSV for the EVAP.
(1) Disconnect the VSV connector for the EVAP.
(2) Connect the positive (+) and negative (-) leads from
the battery to the VSV terminals for the EVAP.
(3) Start the engine.
Page 1783 of 3115

B06545
B13332Hose Clipper Air Drain Hose
B06546
Pressure
Gauge
Pressure EC-6
- EMISSION CONTROLEVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
1694 Author: Date:
2004 LAND CRUISER (RM1071U)
(e) Check the vacuum at idle.
Vacuum:
Maintain at 0.368 - 19.713 in.Hg (5 - 268 in.Aq) for over
5 seconds
HINT:
If the vacuum does not change, you can conclude that the hose
connecting the VSV to the service port has come loose or is
blocked, or the VSV is malfunctioning.
(f) TOYOTA Hand-Held Tester:
Conclude forced driving of the VSV for the EVAP.
(1) Stop the engine.
(2) Disconnect the TOYOTA hand-held tester from the
DLC3.
(g) If you have no TOYOTA Hand-Held Tester:
Conclude forced driving of the VSV for the EVAP.
(1) Stop the engine.
(2) Disconnect the positive (+) and negative (-) leads
from the battery from the VSV terminals for the
EVAP.
(3) Connect the VSV connector for the EVAP.
(h) Disconnect the vacuum gauge from the EVAP service
port on the purge line.
(i) Connect a pressure gauge to the EVAP service port on
the purge line.
(j) Check the pressure.
(1) Close off the air drain hose at the marked position
of the canister with a hose clipper or similar instru-
ment.
(2) Add the pressure (13.5 - 15.5 in.Aq) from the EVAP
service port.
Pressure:
2 minutes after the pressure is added, the gauge
should be over 7.7 - 8.8 in.Aq.
HINT:
If you can't add pressure, you can conclude that the hose con-
necting the VSVcanisterfuel tank has slipped off or the
VSV is open.
Page 1784 of 3115

B06547
Fuel Tank Cap
B13333
EVAP Line Hose
Air
B13334
EVAP Line Hose
Purge Line Hose
Air
- EMISSION CONTROLEVAPORATIVE EMISSION (EVAP) CONTROL SYSTEM
EC-7
1695 Author: Date:
2004 LAND CRUISER (RM1071U)
(3) Check if the pressure decreases when the fuel tank
cap is removed while adding pressure.
HINT:
If the pressure does not decrease when the filler cap is re-
moved, then you can conclude that the hose connecting the
service port to the fuel tank is blocked, etc.
(k) Disconnect the pressure gauge from the EVAP service
port on the purge line.
5. CHECK AIRTIGHTNESS IN FUEL TANK AND FILLER
PIPE
(a) Disconnect the EVAP line hose from the charcoal canister
side and then pressurize and make the internal pressure
in the fuel tank 4 kPa (41 gf/cm
2, 0.58 psi).
(b) Check that the internal pressure of the fuel tank can be
hold for 1 minute.
(c) Check the connected portions of each hose and pipe.
(d) Check the installed parts on the fuel tank.
If there is no abnormality, replace the fuel tank and filler pipe.
(e) Reconnect the EVAP line hose to the charcoal canister.
6. INSPECT FUEL CUTOFF VALVE AND FILL CHECK
VA LV E
(a) Disconnect the purge line hose and EVAP line hose from
the charcoal canister.
(b) Plug the cap to the air drain hose.
(c) Pressurize 4 kPa (41 gf/cm
2, 0.58 psi) to the purge port
and check that there is ventilation through the EVAP line
hose.
HINT:
In the condition that the fuel is full, as the float value of the fill
check valve is closed and has no ventilation, it is necessary to
check the fuel amount (volume).
(d) Check if there is any struck in the vent line hose and EVAP
line hose.
If there is no stuck in hoses, replace the fuel cutoff valve and fill
check valve.
(e) Reconnect the purge line hose and EVAP line hose to the
charcoal canister.
