Page 2849 of 3115
SR0M7-04
F05613
Steering Wheel Pad
50 (510, 37)
Steering Wheel Lower
No. 2 Cover
Torx Screw
8.8 (90, 78 in.´lbf)
Combination Switch
(w/ Spiral Cable)
Steering Wheel
Torx Screw
8.8 (90, 78 in.´lbf)
Steering Wheel Lower
No. 3 Cover
Column Upper Cover
Column Lower Cover
Steering Column Assembly
25 (260, 19)
Thrust Stopper
Sliding Yoke
34 (350, 25)Hose Clamp
No. 2 Hole Cover
Hole Cover
No. 2 Intermediate
Shaft AssemblyCluster Finish Panel
Lower No. 1 Panel
34 (350, 25)
LH Lower Panel
Hood Lock Release Lever
Fuel Lid Release Lever
No. 2 Heater to Register
DuctClip
Cowl Trim
Scuff Plate
N´m (kgf´cm, ft´lbf) : Specified torque
- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMNSR-27
2236 Author: Date:
2004 LAND CRUISER (RM1071U)
POWER TILT AND POWER TELESCOPIC STEERING
COLUMN
COMPONENTS
Page 2850 of 3115

F17600
Transponder Key Coil
with Amplifier
Key Cylinder
Snap Ring
Turn Signal Bracket
Column Upper
Tube Sub-assembly
Tilt Steering Bolt
20 (210, 15)
Key Interlock
Solenoid
Energy Absorbing
Clip
Energy Absorbing
Plate
Energy Absorbing
Guide
Ignition SwitchColumn Upper
Bracket
Column Upper
Tube Assembly
Break Away
Bracket15 (150, 11)
Column Tube
Support
Tube Attachment
Support Stopper
Bolt Bushing
Power Tilt Motor20 (210, 15)
Bushing
Telescopic Steering
Slider
Telescopic Steering
Slider Support
Steering Lock Wedge
Telescopic Steering
Wedge Lock Spring
Power Telescopic
Motor
Steering Column Protector
No. 1
15 (150, 11)
Column Upper
Clamp
Telescopic Steering
Column Cable
Tapered-head Bolt
Telescopic Steering
Bushing
0.8 (8.2, 7.1 in.´lbf)
Telescopic Steering
Screw
Energy Absorber
Cushion
Support Stopper
Bolt
Stopper Spring
Stopper No. 1
Adjusting Nut No. 1
Connector Bracket
E-RIng
Compression
Spring
Bearing Thrust
Collar Bearing
Main Shaft
Assembly
Snap Ring
34 (350, 25)
Thrust Stopper
Intermediate Shaft Assembly
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
Molybdenum disulfide lithium base grease
Support Stopper
Bolt Bushing
Tilt Steering Shaft
No. 2 Lower Cover
Bushing
Steering Column
Bracket Spacer
Telesco Lever
Lock Bolt
10 (100, 7)
Bearing
Bearing
No. 2 Lower Cover
11 (110, 8)
9.0 (90, 78 in.´lbf)
25 (260, 19)
Key Unlock Warning
Switch19 (190, 14)
Column Tube
Stopper SR-28
- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
2237 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 2851 of 3115

F04881
Matchmarks
SR0M9-05
SR-30- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
2239 Author: Date:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
NOTICE:
When using a vise, do not overtighten it.
1. REMOVE NO. 2 LOWER COVER
Remove the 2 nuts and lower side No. 2 lower cover.
2. REMOVE INTERMEDIATE SHAFT ASSEMBLY
(a) Place matchmarks on the intermediate shaft assembly
and main shaft assembly.
(b) Remove the bolt and intermediate shaft assembly with
the upper side No. 2 lower cover.
(c) Remove the thrust stopper from the main shaft assembly.
3. REMOVE TRANSPONDER KEY AMPLIFIER
(a) Widen the claw humg on the upper bracket by approx. 1.0
mm (0.039 in.) using a screwdriver.
(b) Pull the transponder key amplirier toward the rear of the
vehicle with the claw open.
NOTICE:
Take care not to use excessive force to prevent the case
from being damage.
4. REMOVE CONNECTOR BRACKET
Remove the bolt and connector bracket.
5. REMOVE STEERING COLUMN PROTECTOR NO. 1
Remove the bolt and steering column protector No. 1.
6. REMOVE TURN SIGNAL BRACKET
Remove the 3 bolts and turn signal bracket.
7. REMOVE POWER TILT MOTOR
(a) Using a hexagon wrench, remove the support stopper
bolt.
(b) Remove the stopper spring and stopper No. 1.
(c) Using a hexagon wrench, remove the 2 tilt steering bolts
and power tilt motor.
(d) Using a screwdriver, remove the 2 E-rings.
(e) Remove the 2 support stopper bolt bushings from the
power tilt motor.
Page 2852 of 3115

F04867
Tilt Steering
ShaftBolt
Plate Washer
SST
F08835
Screw
Extractor
F04863
- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMNSR-31
2240 Author: Date:
2004 LAND CRUISER (RM1071U)
8. REMOVE ADJUSTING NUT NO. 1
(a) Set SST, a plate washer (36 mm outer diameter) and bolt
(6 mm normal diameter, 1.0 mm pitch, 50 mm length), as
shown.
SST 09910-00015 (09911-0001 1, 09912-00010)
Reference:
Plate washer 90201-10201
Bolt 91111-51050
(b) Remove the 2 tilt steering shafts by using the sliding ham-
mer on SST.
(c) Remove the adjusting nut No. 1.
(d) Remove the 2 support stopper bolt bushings from the ad-
justing nut No. 1.
9. REMOVE POWER TELESCOPIC MOTOR
(a) Remove the 2 bolts and power telescopic motor.
(b) Remove the telescopic steering column cable.
10. REMOVE COLUMN UPPER BRACKET AND COLUMN
UPPER CLAMP
(a) Remove the column tube stopper.
(b) Using a centering punch, mark the center of the 2 ta-
pered-head bolts.
(c) Using a 3 - 4 mm (0.12 - 0.16 in.) drill, drill into the 2 bolts.
(d) Using a screw extractor, remove the 2 bolts, column up-
per bracket and column upper clamp.
(e) Using a hexagon wrench, remove the 2 telesco lever lock
bolts.
(f) Remove the 2 telescopic steering wedge lock springs, 2
steering lock wedges and column upper bracket and col-
umn upper clamp.
11. REMOVE COLUMN TUBE SUPPORT
(a) Remove the bolt.
(b) Remove the column tube support with tube attachment.
(c) Remove the tube attachment from the column tube sup-
port.
12. REMOVE 2 ENERGY ABSORBING PLATES
(a) Using pliers, remove the 2 energy absorbing clips.
(b) Remove the 2 energy absorbing plates and 2 energy ab-
sorbing guides.
Page 2853 of 3115

F04864
SST
SR-32- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
2241 Author: Date:
2004 LAND CRUISER (RM1071U)
13. REMOVE TELESCOPIC STEERING SLIDER SUP-
PORT
Remove the 2 bolts and telescopic steering slider support.
14. REMOVE TELESCOPIC STEERING BUSHING
15. REMOVE TELESCOPIC STEERING SLIDER
16. REMOVE STEERING COLUMN BRACKET SPACER
17. REMOVE TELESCOPIC STEERING SCREW
Remove the nut, 4 energy absorber cushions, 2 bearings and
telescopic steering screw.
18. REMOVE COLUMN UPPER TUBE SUB-ASSEMBLY
WITH MAIN SHAFT ASSEMBLY
(a) Using a screwdriver, remove the lower side snap ring from
the main shaft assembly.
(b) Using a hexagon wrench, remove the 2 tilt steering bolts
and column upper tube sub-assembly with the main shaft
assembly.
(c) Remove the column upper tube assembly from the break
away bracket.
(d) Remove the 2 support stopper bolt bushings from the col-
umn upper tube assembly.
(e) Remove the 3 bushings from the break away bracket.
19. REMOVE MAIN SHAFT ASSEMBLY
(a) Using SST, compress the compression spring.
SST 09950-4001 1 (09958-04011)
NOTICE:
Do not bend the universal joint of the shaft assembly more
than 20°.
(b) Using a snap ring expander, remove the upper side snap
ring.
(c) Remove the main shaft assembly from the column upper
tube sub-assembly.
(d) Remove the compression spring and bearing thrust collar
from the main shaft assembly.
Page 2854 of 3115
SR0MA-02
- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMNSR-33
2242 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
(See page SR-20)
Page 2855 of 3115
SR0MC-02
- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMNSR-37
2246 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
(See page SR-24)
Page 2856 of 3115

SR0RE-04
F04864
SST
SR-34- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
2243 Author: Date:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
NOTICE:
When using a vise, do not over tighten it.
1. COAT WITH PARTS INDICATED BY ARROWS MOLYB-
DENUM DISULFIDE LITHIUM BASE GREASE (See
page SR-27)
2. INSTALL MAIN SHAFT ASSEMBLY
(a) Install the bearing thrust collar and compression spring to
the shaft.
(b) Install the shaft assembly to the column upper tube sub-
assembly.
(c) Using SST, compress the compression spring.
SST 09950-4001 1 (09958-04011)
NOTICE:
Do not bend the universal joint of the shaft more than 20°.
(d) Using a snap ring expander, install a new snap ring to the
shaft.
3. INSTALL COLUMN UPPER TUBE SUB-ASSEMBLY
WITH MAIN SHAFT ASSEMBLY
(a) Install the 3 bushings to the break away bracket.
(b) Install 2 new support stopper bolt bushings to the column
tube assembly.
(c) Install the column upper tube assembly to the break away
bracket.
(d) Install the column upper tube sub-assembly with the
main shaft assembly to the break away bracket.
(e) Using a hexagon wrench, install the 2 tilt steering bolts.
Torque: 20 N´m (210 kgf´cm, 15 ft´lbf)
(f) Install a new snap ring.
4. INSTALL TELESCOPIC STEERING SCREW
(a) Install the 4 energy absorber cushions, 2 bearings and
telescopic steering screw.
(b) Install the nut.
Torque: 0.8 N´m (8.2 kgf´cm, 7.1 in.´lbf)
(c) Using a punch, stake the nut.
5. INSTALL STEERING COLUMN BRACKET SPACER
6. INSTALL TELESCOPIC STEERING SLIDER
7. INSTALL TELESCOPIC STEERING BUSHING
8. INSTALL TELESCOPIC STEERING SLIDER SUPPORT
Install the telescopic steering slider support with the 2 bolts.
Torque: 11 N´m (110 kgf´cm, 8 ft´lbf)
