1998 TOYOTA LAND CRUISER Factory Repair Manual

torque service indicator open hood door lock open bonnet engine oil capacity

Load previous 8 pages

Page 1017 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual D03045
53
D13411
PWR
E5E6E7E8E9
DI-496
- DIAGNOSTICSAUTOMATIC TRANSMISSION
689 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
1 Check pattern select switch (PWR mode switch).
PREPA

Page 1018 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI3BO-03
/ /
How Often Does
Problem Occur?/ /
Automatic Transmission
System Check SheetInspector s
Name :
Customer s Name
Date Vehicle
Brought In/

Page 1019 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI3BQ-04
- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-389
582 Author: Date:
2004 LAND CRUISER (RM1071U)
DIAGNOSTIC TROUBLE CODE CHART
If a DTC is displayed during the DTC check, check the circuit listed

DI3BQ-04
- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-389
582 Author: Date:
2004 LAND CRUISER (RM1071U)
DIAGNOSTIC TROUBLE CODE CHART
If a DTC is displayed during the DTC check, check the circuit listed for that code in the table below and pro-
ceed to the page given.
*
1: ...MIL light up
DTC No.
(See Page)Detection ItemTrouble AreaMIL *1Memory
P0500
(DI-274)Vehicle Speed Sensor ºAº
Open or short in No. 1 vehicle speed sensor circuit
No. 1 vehicle speed sensor
Combination meter
ECM

P0705
(DI-402)Transmission Range Sensor Cir-
cuit Malfunction (PRNDL Input)Short in park/neutral position switch circuit
Park/neutral position switch
ECM

P0710
(DI-410)Transmission Fluid Temperature
Sensor ºAº CircuitOpen or short in ATF temperature sensor No.1 circuit
ATF temperature sensor No.1
ECM

P0711
(DI-415)Transmission Fluid Temperature
Sensor ºAº PerformanceATF temperature sensor No.1
ECM
P0712
(DI-410)Transmission Fluid Temperature
Sensor ºAº Circuit Low InputShort in ATF temperature sensor No.1 circuit
ATF temperature sensor No.1
ECM

P0713
(DI-410)Transmission Fluid Temperature
Sensor ºAº Circuit High InputOpen in ATF temperature sensor No.1 circuit
ATF temperature sensor No.1
ECM

P0717
(DI-418)Input Speed Sensor Circuit No
SignalOpen or short in speed sensor NT circuit
Speed sensor NT
ECM

P0722
(DI-421)Output Speed Sensor
Open or short in speed sensor SP2 circuit
Speed sensor SP2
ECM

P0724
(DI-424)Brake Switch ºBº Circuit High
Short in stop light switch circuit
Stop light switch
ECM

P0748
(DI-426)Pressure Control Solenoid ºAº
Electrical
(Shift Solenoid Valve SL1)Open or short in shift solenoid valve SL1 circuit
Shift solenoid valve SL1
ECM

P0751
(DI-433)Shift Solenoid ºAº Performance
(Shift Solenoid Valve S1)
Shift solenoid valve S1 is stuck open or closed
Valve body is blocked up or stuck
Shift solenoid valve S1
Automatic transmission assembly
ECM

P0756
(DI-437)Shift Solenoid ºBº Performance
(Shift Solenoid Valve S2)
Shift solenoid valve S2 is stuck open or closed
Valve body is blocked up or stuck
Shift solenoid valve S2
Automatic transmission assembly
ECM

P0771
(DI-441)Shift Solenoid ºEº Performance
(Shift Solenoid Valve SR)
Shift solenoid valve SR is stuck open or closed
Shift solenoid valve SL1 is stuck open or closed
Valve body is blocked up or stuck
Shift solenoid valve SR
Shift solenoid valve SL1
Automatic transmission assembly
ECM

Page 1020 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI-390
- DIAGNOSTICSAUTOMATIC TRANSMISSION
583 Author: Date:
2004 LAND CRUISER (RM1071U)P0776
(DI-445)
Pressure Control Solenoid ºBº
Performance
(Shift Solenoid Valve SL2)
Shift solenoid valve

DI-390
- DIAGNOSTICSAUTOMATIC TRANSMISSION
583 Author: Date:
2004 LAND CRUISER (RM1071U)P0776
(DI-445)
Pressure Control Solenoid ºBº
Performance
(Shift Solenoid Valve SL2)
Shift solenoid valve SL2 is stuck open or closed
Valve body is blocked up or stuck
Shift solenoid valve SL2
Automatic transmission assembly
ECM

P0778
(DI-449)Pressure Control Solenoid ºBº
Electrical
(Shift Solenoid Valve SL2)Open or short in shift solenoid valve SL2 circuit
Shift solenoid valve SL2
ECM

P0781
(DI-453)1-2 Shift
Valve body is blocked up or stuck (1-2 shift valve)
Automatic transmission assembly
ECM

P0818
(DI-457)Driveline Disconnect Switch In-
put CircuitShort in transfer neutral position switch circuit
Transfer neutral position switch
ECM

P0850
(DI-402)Park/Neutral Switch Input Circuit
Short in park/neutral position switch circuit
Park/neutral position switch
ECM

P0973
(DI-460)Shift Solenoid ºAº Control Circuit
Low (Shift Solenoid Valve S1)Open or short in shift solenoid valve S1 circuit
Shift l id l S1

P0974
(DI-460)Shift Solenoid ºAº Control Circuit
High (Shift Solenoid Valve S1)Shift solenoid valve S1
ECM

P0976
(DI-464)Shift Solenoid ºBº Control Circuit
Low (Shift Solenoid Valve S2)Open or short in shift solenoid valve S2 circuit
Shift l id l S2

P0977
(DI-464)Shift Solenoid ºBº Control Circuit
High (Shift Solenoid Valve S2)Shift solenoid valve S2
ECM

P0985
(DI-468)Shift Solenoid ºEº Control Circuit
Low (Shift Solenoid Valve SR)Open or short in shift solenoid valve SR circuit
Shift l id l SR

P0986
(DI-468)Shift Solenoid ºEº Control Circuit
High (Shift Solenoid Valve SR)Shift solenoid valve SR
ECM

P1782
(DI-472)T/F L4 Range Position Switch
PerformanceShort in transfer L4 position switch circuit
Transfer L4 position switch
ECM

P2714
(DI-476)Pressure Control Solenoid ºDº
Performance
(Shift Solenoid Valve SLT)
Shift solenoid valve SLT is stuck open or closed
Valve body is blocked up or stuck
Shift solenoid valve SLT
Automatic transmission assembly
ECM

P2716
(DI-479)Pressure Control Solenoid ºDº
Electrical
(Shift Solenoid Valve SLT)Open or short in shift solenoid valve SLT circuit
Shift solenoid valve SLT
ECM

P2740
(DI-483)Transmission Fluid Temperature
Sensor ºBº CircuitOpen or short in ATF temperature sensor No. 2 circuit
ATF temperature sensor No. 2
ECM

P2742
(DI-483)Transmission Fluid Temperature
Sensor ºBº Circuit LowShort in ATF temperature sensor No. 2 circuit
ATF temperature sensor No. 2
ECM

P2743
(DI-483)Transmission Fluid Temperature
Sensor ºBº Circuit HighOpen in ATF temperature sensor No. 2 circuit
ATF temperature sensor No. 2
ECM

Page 1021 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-391
584 Author: Date:
2004 LAND CRUISER (RM1071U)P2757
(DI-487)
Torque Converter Clutch Pres-
sure Control Solenoid Perfor-
mance
(Shift Solenoid Valve SLU)

Page 1022 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI3BN-04
Vehicle Brought to Workshop
Customer Problem Analysis
Check DTC and Freeze Frame Data (Precheck)
Record or Print DTC and Freeze Frame Data DI-361
Clear DTC and Freeze Frame Data DI-361
Visua

Page 1023 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI3BR-05
D13102
Combination Meter
DLC3 Stop Light SwitchECM
Transmission Control
Switch
(2 e L Position)
Pattern Select Switch
Park/Neutral Position Switch
Speed Sensor SP2
Shift Solenoid Valve S1
Shi

Page 1024 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DIC2W-01
- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-359
552 Author: Date:
2004 LAND CRUISER (RM1071U)
PRECAUTION
NOTICE:
Perform the RESET MEMORY (AT initialization) when replacing the automatic trans
