Adjusting Bolt A (Vertical Direction)
BE-34
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
2407 Author: Date:
2004 LAND CRUISER (RM1071U)
ADJUSTMENT
Page 250 of 3115

I20844
0.4 °
3 m (9.84 ft) H 20.9 mm
(0.823 in.)
7
V RH Line
90 °
V LH Line4V LH LineV Line V RH Line 65
6
V LH LineV Line
V RH Line 6
5
6
H4
O: step No.
7
H4
20.9 mm
(0.823 in.) 1,146mm (45.1 in.) Low Beam:
High Beam:20.9 mm
(0.823 in.)
20.9 mm
(0.823 in.)
1,146mm (45.1 in.)
1,146mm
(45.1 in.)H RH and
H LH lines High Beam
Low Beam
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE-35
2408 Author: Date:
2004 LAND CRUISER (RM1071U)
ADJUST HEADLIGHT AIM ONLY
(a) Place the vehicle in the following conditions.
The area around the headlight is not deformed.
The vehicle is parked on a level surface.
Tire inflation pressure is the specified value.
A driver is in the driver's seat and the vehicle is in a state ready for driving (with a tank full).
The vehicle has been bounced several times.
(b) Check the headlight aiming.
(1) Prepare a thick white paper.
(2) Stand the paper perpendicular to the ground at the position 9.84 ft away from the headlights.
(3) Ensure that the center line of the vehicle and the paper face forms a 90-degree angle as shown
in the illustration.
(4) Draw a horizontal line (H line) on the paper, showing where the headlights should strike.
(5) Draw a vertical line (V line) to where the center line of the vehicle is to be.
(6) Draw 2 vertical lines (by connecting the low and high beam center marks) to where the both head-
lights should strike (V RH and V LH lines).
(7) Draw a horizontal line (by connecting the both low beam center marks) to where the headlights
should strike (H RH and H LH lines).
HINT:
The H RH and H LH line is 0.4° below the horizontal line (H line) of the light axis.
(8) Start the engine.
(9) Turn the headlights ON.
(10) Check that the headlights properly strike the position shown in the illustration.
(11) If not, adjust the lights in the vertical direction.
HINT:
As shown in the illustration, adjust each aim of the RH and LH lights.
(c) When adjusting it in the vertical direction:
Using adjusting bolt A, adjust the headlight aim to within the specified range.
Page 251 of 3115
BE0H9-08
I25531
Switch BodyWiper and Washer Switch
Light Control Switch and
Headlight Dimmer Switch
Spiral Cable
Tilt and Telescopic Switch
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE-31
2404 Author: Date:
2004 LAND CRUISER (RM1071U)
COMPONENTS
Page 252 of 3115

I06426
HI
Flash OFFTAIL HEAD AUTO
LO
BE2EH-01
I04036
1 2
3 41 2 3
4 5 6 Connector ºBº Connector ºAº
A2 B3 B1
A3
A5 A1 B4 B2 BE-32
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
2405 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT LIGHT CONTROL SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
OFF-No continuity
TAIL14 - 16Continuity
HEAD13 - 14 - 16Continuity
AUTO12 - 16Continuity
If continuity is not as specified, replace the switch.
2. INSPECT HEADLIGHT DIMMER SWITCH CONTINU-
ITY
Switch positionTester connectionSpecified condition
Low beam16 - 17Continuity
High beam7 - 16Continuity
Flash7 - 8 - 16Continuity
If continuity is not as specified, replace the switch.
3. INSPECT DAYTIME RUNNING LIGHT NO.3 AND NO.4
RELAY CONTINUITY
Tester connectionConditionSpecified condition
A1 - B3ConstantContinuity
A3 - A5ConstantContinuity
B3 - B4ConstantContinuity
A2 - A5Apply battery positive voltage between
terminals A1 and B3.Continuity
B1 - B2Apply battery positive voltage between
terminals B3 and B4.Continuity
If continuity is not as specified, replace the relay.
Page 253 of 3115

I25040
Built in relayExcept built in relay
I22144
Wire Harness Side:
1
2
3
4
56
I22145
From Back Side:
1 2
3 4
5 6
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
BE-33
2406 Author: Date:
2004 LAND CRUISER (RM1071U)
4. INSPECT ENGINE ROOM R/B RELAY CIRCUIT (See
Pase BE-15)
HINT:
The (Headlight, DIM, Tail relay) is built in engine room junction
block. Also the relay is constructed with a relay block that is in
the junction block as a unit. To disconnect the wire harness con-
necting with relay block is impossible. If the relay has a malfunc-
tion, replace it with junction block assembly wire harness to-
gether.
5. Connector disconnected:
INSPECT AUTOMATIC LIGHT CONTROL SENSOR
CIRCUIT
Disconnect the connector from the sensor and inspect the con-
nector on the wire harness side, as shown in the chart.
HINT:
Ignition switch is ON.
Light control switch is in AUTO.
Vehicle's surroundings are bright.
Tester connectionConditionSpecified condition
6 - GroundConstantContinuity
3 - GroundClose the driver's door again while the ignition
switch OFFNo voltage
3 - GroundIgnition switch position ON5.2 - 9.0V
If circuit is as specified, perform the inspection on the following
page.
If the circuits is not as specified, inspect the circuit connected
to other parts.
6. Connector disconnected:
INSPECT AUTOMATIC LIGHT CONTROL SENSOR
CIRCUIT
Connect the wire harness side connector to the sensor and in-
spect wire harness side connector from the back side, as
shown.
HINT:
Ignition switch is ON.
Light control switch is in AUTO.
Vehicle's surroundings are bright.
Tester connectionConditionSpecified condition
4 - Ground
(CLTS - Body ground)ConstantPulse generation
3 - Ground
(CLTB - Body ground)Ignition switch ON10 - 14V
If the circuits is not as specified, try replacing the sensor with a
new one.
Page 254 of 3115
BE0H8-1 1
I24735
Cowl Side J/B LH
Body ECU
ECU-IG1 Fuse
ECU-B1 Fuse
Combination Switch
Light Control Switch
Headlight Dimmer SwitchIgnition Switch Headlight
Engine Room R/B
HEAD LH-UPR Fuse
HEAD RH-UPR Fuse
HEAD LH-LWR Fuse
HEAD RH LWR Fuse
HEAD Relay
HEAD HI Relay
TAIL Fuse
TAIL Relay Automatic Light Control Sensor
Taillight Daytime Running Light No.3
and No.4 Relay
BE-30
- BODY ELECTRICALHEADLIGHT AND TAILLIGHT SYSTEM
2403 Author: Date:
2004 LAND CRUISER (RM1071U)
HEADLIGHT AND TAILLIGHT SYSTEM
LOCATION
Page 255 of 3115

BE0FZ-19
I24653
I24654
6
I04197
BE-198
- BODY ELECTRICALHORN SYSTEM
2571 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT HORN SWITCH
(a) Disconnect the negative (-) terminal from the battery.
(b) Remove the left and right covers from the steering wheel.
(c) Using a torx socket wrench, loosen the 2 bolts.
(d) Pull up the horn pad and place it on the steering column,
as shown.
HINT:
Do not disconnect the connector from the horn pad.
(e) Disconnect the connector from the slip ring.
(f) Check that no continuity exists between terminal 6 of the
connector and body ground.
(g) Check that continuity exists between terminal 6 of the
connector and body ground when the horn contact plate
is pressed against the steering spoke assembly.
If continuity is not as specified, repair or replace the steering
wheel or wire harness as necessary.
(h) Install the horn pad in place and using a torx socket
wrench, torque the 2 bolts.
Torque:
7.1 N´m (72 kgf´cm, 62 in.´lbf)
(i) Install the left and right covers.
(j) Connect the negative (-) terminal to the battery.
2. INSPECT HORN OPERATION
Connect the positive (+) lead from the battery to the terminal
and negative (-) lead to the horn body and check that the horn
blows.
If operation is not as specified, replace the horn.
Page 256 of 3115
I25040
Built in relayExcept built in relay
- BODY ELECTRICALHORN SYSTEM
BE-199
2572 Author: Date:
2004 LAND CRUISER (RM1071U)
3. INSPECT ENGINE ROOM R/B RELAY CIRCUIT (See
Pase BE-15)
HINT:
The horn relay is built in engine room junction block. Also the
relay is constructed with a relay block that is in the junction block
as a unit. To disconnect the wire harness connecting with relay
block is impossible. If the relay has a malfunction, replace it with
junction block assembly wire harness together.
