Page 1529 of 3115

H01021AB0119H10600 H01069H20664
"u
Side Squib RHAirbag
Sensor
Assembly
DLC3DTC B0110/43 ON
TC
CG
DI-748
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
941 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check side squib RH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the side airbag assembly RH (side squib RH)
connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0110/43 is not output.
HINT:
Codes other than code B0110/43 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly RH
(side squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1530 of 3115

H01019H16275H16616
Side Squib RHAirbag
Sensor
Assembly
(-) (+)
SFR+
SFR- Floor No. 2 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-749
942 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B0111/44 Open in Side Squib RH Circuit
CIRCUIT DESCRIPTION
The side squib RH circuit consists of the airbag sensor assembly and the side airbag assembly RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0111/44 is recorded when an open is detected in the side squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0111/44
Open in side squib RH circuit
Side squib RH malfunction
Airbag sensor assembly malfunctionSide airbag assembly RH (Side squib RH)
Airbag sensor assembly
Floor No. 2 wire
HINT:
DTC B0111/44 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
See page DI-745.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 2 wire (side squib RH circuit).
CHECK:
Measure the resistance between SFR+ and SFR- of the floor
No. 2 wire connector on the side airbag assembly RH (side
squib RH) side.
OK:
Resistance: Below 1 W
NG Repair or replace floor No. 2 wire.
OK
DI6PC-20
Page 1531 of 3115

AB0119
H01070 H10600H01020H16278H16617
Side Squib RHAirbag
Sensor
Assembly
SFR+
SFR-
DTC B0111/44
" u
ON
DLC3
CGTC Floor No. 2 Wire
DI-750
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
943 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect SFR+ and SFR- of the floor
No. 2 wire connector on the side airbag assembly RH
(side squib RH) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0111/44 is not output.
HINT:
Codes other than code B0111/44 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1532 of 3115

H10600 H01021
H01070 AB0119H11010
"u
Side Squib RH
Airbag
Sensor
Assembly
DTC B0111/44 ON
DLC3
CGTC
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-751
944 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check side squib RH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the side airbag assembly RH (side squib RH)
connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0111/44 is not output.
HINT:
Codes other than code B0111/44 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly RH
(side squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check.
Page 1533 of 3115

H01019H16276H16618
Airbag
Sensor
Assembly Side Squib RH
(+)SFR+
(-)
Floor No. 2 Wire
DI-752
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
945 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B0112/41 Short in Side Squib RH Circuit
(to Ground)
CIRCUIT DESCRIPTION
The side squib RH circuit consists of the airbag sensor assembly and the side airbag assembly RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0112/41 is recorded when ground short is detected in the side squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0112/41
Short in side squib RH circuit (to ground)
Side squib RH malfunction
Airbag sensor assembly malfunctionSide airbag assembly RH (Side squib RH)
Airbag sensor assembly
Floor No. 2 wire
HINT:
DTC B0112/41 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
See page DI-745.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 2 wire (side squib RH circuit).
CHECK:
Measure the resistance between the body ground and SFR+ of
the floor No. 2 wire connector on the side airbag assembly RH
(side squib RH) side.
OK:
Resistance: 1 MW or Higher
NG Repair or replace floor No. 2 wire.
OK
DI6PD-21
Page 1534 of 3115

AB0119
H10600H01020H16278H01067H16619
Airbag
Sensor
Assembly Side Squib RH
SFR-
DLC3
" u
SFR+
TC CGON
DTC B0112/41 Floor No. 2 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-753
946 Author: Date:
2004 LAND CRUISER (RM1071U)
3 Check airbag sensor assembly.
PREPARATION:
(a) Connect the connector to the airbag sensor assembly.
(b) Using a service wire, connect SFR+ and SFR- of the floor
No. 2 wire connector on the side airbag assembly RH
(side squib RH) side.
(c) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0112/41 is not output.
HINT:
Codes other than code B0112/41 may be output at this time, but
they are not relevant to this check.
NG Replace airbag sensor assembly.
OK
Page 1535 of 3115

H10600 H01021 AB0119H01067H16610
"u
DTC B0112/41
TC CGON Airbag
Sensor
Assembly
DLC3
Side Squib RH
DI-754
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
947 Author: Date:
2004 LAND CRUISER (RM1071U)
4 Check side squib RH.
PREPARATION:
(a) Turn the ignition switch to LOCK.
(b) Disconnect the negative (-) terminal cable from the bat-
tery, and wait at least for 90 seconds.
(c) Connect the side airbag assembly RH (side squib RH)
connector.
(d) Connect the negative (-) terminal cable to the battery,
and wait at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(b) Clear the DTC stored in memory (See page DI-692).
(c) Turn the ignition switch to LOCK, and wait at least for 10
seconds.
(d) Turn the ignition switch to ON, and wait at least for 10 se-
conds.
(e) Check the DTC (See page DI-692).
OK:
DTC B0112/41 is not output.
HINT:
Codes other than code B0112/41 may be output at this time, but
they are not relevant to this check.
NG Replace side airbag assembly RH
(side squib RH).
OK
From the results of the above inspection, the malfunctioning part can now be considered normal.
To make sure of this, use the simulation method to check. If the malfunctioning part can not be
detected by the simulation method, replace all SRS components including the wire harness.
Page 1536 of 3115

H01019AB0119H16277H16621
Side Squib RHAirbag
Sensor
Assembly
(-) (+)SFR+
ON
Floor No. 2 Wire
- DIAGNOSTICSSUPPLEMENTAL RESTRAINT SYSTEM
DI-755
948 Author: Date:
2004 LAND CRUISER (RM1071U)
DTC B0113/42 Short in Side Squib RH Circuit (to B+)
CIRCUIT DESCRIPTION
The side squib RH circuit consists of the airbag sensor assembly and the side airbag assembly RH.
It causes the SRS to deploy when the SRS deployment conditions are satisfied.
For details of the function of each component, see OPERATION on page RS-3.
DTC B0113/42 is recorded when a B+ short is detected in the side squib RH circuit.
DTC No.DTC Detecting ConditionTrouble Area
B0113/42
Short in side squib RH circuit (to B+)
Side squib RH malfunction
Airbag sensor assembly malfunctionSide airbag assembly RH (Side squib RH)
Airbag sensor assembly
Floor No. 2 wire
HINT:
DTC B0113/42 is indicated only for the vehicle equipped with the side airbag.
WIRING DIAGRAM
See page DI-745.
INSPECTION PROCEDURE
1 Prepare for inspection (See step 1 on page DI-923).
2 Check floor No. 2 wire (side squib RH circuit).
PREPARATION:
Connect the negative (-) terminal cable to the battery, and wait
at least for 2 seconds.
CHECK:
(a) Turn the ignition switch to ON.
(b) Measure the voltage between the body ground and SFR+
of the floor No. 2 wire connector on the side airbag assem-
bly RH (side squib RH) side.
OK:
Voltage: Below 1 V
NG Repair or replace floor No. 2 wire.
OK
DI6PE-22
