Page 121 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual AT147-03 D13650 Refill Plug Overflow Plug D14352 Overflow Tube AT-3-1 - AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM 1855 Author: Date: 2004 LAND CRUISER (RM1071U) AUTOMATIC TRANSMISSION FL

Page 122 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A04550 9 1011 12 13141516 12345678 DLC3 CG TC - AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM AT-3-2 1856 Author: Date: 2004 LAND CRUISER (RM1071U) 3. TRANSMISSION FILL (a) Fill the transmis

Page 123 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual D14352 Overflow Tube AT-3-3 - AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM 1857 Author: Date: 2004 LAND CRUISER (RM1071U) (b) Without hand-held tester (Using A/T OIL TEMP indicator) (1) Con

Page 124 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual AT07L-02 - AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION SYSTEM AT-1 1852 Author: Date: 2004 LAND CRUISER (RM1071U) AUTOMATIC TRANSMISSION SYSTEM PRECAUTION If the vehicle is equipped with a mobile

Page 125 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual AT080-04 D13664 Air Cleaner Cap Radiator Reservoir Fan and Fluid Coupling Assembly Fan Shroud x6x4 80 (820, 59) 80 (820, 59) 80 (820, 59) 80 (820, 59) Front Propeller Shaft 48 (490, 35) Hole Plug 18 (

Page 126 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual D01624 AT082-06 - AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION UNIT AT-33 1887 Author: Date: INSTALLATION 1. CHECK TORQUE CONVERTER CLUTCH INSTALLA- TION Using calipers and a straight edge, measure

Page 127 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual AT12V-01 D12652 (a) (b) (b) (c) Lock D12653 D12654 D12655 AT-30 - AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION UNIT 1884 Author: Date: 2004 LAND CRUISER (RM1071U) REMOVAL 1. REMOVE BATTERY 2. REMO

Page 128 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual D12656 (a)(b) (a) (a) (b)(b) D12657 D12658 D12659 (c)(b) D12660 - AUTOMATIC TRANSMISSIONAUTOMATIC TRANSMISSION UNIT AT-31 1885 Author: Date: 2004 LAND CRUISER (RM1071U) 10. SEPARATE WIRE HARNESS (
