Hydraulic Brake
BoosterSub-wire Harness S (SST)
AIR BLEED
FRONT
REAR BR-6
- BRAKEBRAKE FLUID
2142 Author: Date:
2004 LAND CRUISER (RM1071U)
(b) Connect the actuator checker (SST) to the hydraulic
brake booster side wire harness via the sub-wire harness
(SST), as shown in the chart below.
SST 09990-00150, 09990-00480
HINT:
Connect the connector with the label of ºAIR BLEEDº attached
to the connector of actuator checker.
(c) Connect the red cable of the checker to the battery posi-
tive (+) terminal and the black cable to the negative (-) ter-
minal.
(d) Turn the ignition switch OFF, depress the brake pedal
more than 40 times.
HINT:
When a pressure in power supply system is released, reaction
force becomes light and stroke becomes longer.
(e) Turn the ignition switch ON, check that the pump stops af-
ter 30 to 40 sec.
NOTICE:
When the pump does not stop, repeat step (d) and (e) again.
(f) With the ignition switch remained ON, depress the brake
pedal more than 20 times.
(g) Observe the procedure in step 4 and bleed the right and
left front wheel caliper.
(h) Holding the brake pedal depressed, bleed the right and
left rear brake caliper.
HINT:
It is not necessary to depress the pedal continuously, as brake
fluid flows out by first depressing.
Page 522 of 3115

F02823
F02824
F02825
- BRAKEBRAKE FLUID
BR-7
2143 Author: Date:
2004 LAND CRUISER (RM1071U)
(i) Bleed right front brake line.
(1) Turn the selector switch of the actuator checker to
the ºFRONT RHº position.
(2) Push and hold in MAIN push switch, depress the
brake pedal and hold it to bleed the right front brake
caliper.
NOTICE:
Do not keep the MAIN switch pushed in for more than 10
sec. When operating it continuously, set the interval of
more than 20 sec.
(3) Repeat step (2) until there are no more air bubbles
in the fluid.
(j) Bleed left front brake line.
(1) Turn the selector switch of the actuator checker to
the ºFRONT LHº position.
(2) Push and hold in the MAIN push switch, depress the
brake pedal and hold it to bleed the left front brake
caliper.
NOTICE:
Do not keep the MAIN switch pushed in for more than 10
sec. When operating it continuously, set the interval of
more than 20 sec.
(3) Repeat step (2) until there are no more air bubbles
in the fluid.
(k) w/ ABS & TRAC & VSC only:
Bleed right rear brake line.
(1) Push and hold in the ºSUB LHº and ºSUB RHº
switches, bleed the right rear brake caliper.
NOTICE:
Do not keep the MAIN switch pushed in for more than 10
sec. When operating it continuously, set the interval of
more than 20 sec.
(2) Repeat step (1) until there are no more air bubbles
in the fluid.
Page 523 of 3115

F04458
BR-8
- BRAKEBRAKE FLUID
2144 Author: Date:
2004 LAND CRUISER (RM1071U)
(l) Observe the procedure in step (k) and bleed left rear
brake line.
(m) Disconnect the actuator checker (SST) and sub-wire har-
ness (SST) from the actuator.
SST 09990-00150, 09990-00480
(n) Connect the 2 connectors to the hydraulic brake booster.
(o) Clear the DTC (See page DI-505).
4. BLEED BRAKE LINE
(a) Connect the vinyl tube to the brake caliper.
(b) Depress the brake pedal several times, then loosen the
bleeder plug with the pedal held down.
(c) At the point when fluid stops coming out, tighten the
bleeder plug, then release the brake pedal.
(d) Repeat (b) and (c) until all the air in the fluid has been bled
out.
(e) Repeat the above procedure to bleed the brake line for
each wheel.
Torque: 11 N´m (110 kgf´cm, 8 ft´lbf)
5. CHECK FLUID LEVEL IN RESERVOIR
(a) With the ignition switch OFF, depress the brake pedal
more than 40 times.
HINT:
When a pressure in power supply system is released, reaction
force becomes light and stroke becomes longer.
(b) Remove the reservoir cap. Add brake fluid up to the
ºMAXº line.
Fluid: SAE J1703 or FMVSS NO. 116 DOT3
Page 524 of 3115
BR0X9-02
F08309
Pedal Pad Brake PedalReturn Spring
Cowl Side TrimLower No. 1 PanelLH Lower Panel
No. 2 Heater to Register Duct
ABS ECU or
ABS & BA & TRAC
& VSC ECU
N´m (kgf´cm, ft´lbf): Specified torque
Cushion
Stop Light Switch
20 (200, 14)
Hydraulic Brake Booster Assembly
MP Grease
Front Door Scuff Plate
5.0 (51, 44 in.´lbf)
Clevis PinClip
- BRAKEBRAKE PEDAL
BR-1 1
2147 Author: Date:
2004 LAND CRUISER (RM1071U)
COMPONENTS
Page 525 of 3115
BR0XB-02
F06414
- BRAKEBRAKE PEDAL
BR-13
2149 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. REASSEMBLY BRAKE PEDAL
(a) Install the pedal pad.
(b) Install the stop light switch cushion.
(c) Temporarily install the stop light switch to the pedal brack-
et.
(d) Install the return spring with cushion and pedal pad.
HINT:
Apply MP grease to the parts indicates by arrow (See page
BR-1 1).
2. INSTALL BRAKE PEDAL ASSEMBLY
Install the brake pedal assembly and temporarily fasten the 2
bolts.
3. INSTALL HYDRAULIC BRAKE BOOSTER
(See page BR-67)
4. TIGHTEN 2 BOLTS OF BRAKE PEDAL BRACKET
Torque: 20 N´m (200 kgf´cm, 14 ft´lbf)
5. AFTER INSTALLATION, FILL BRAKE RESERVOIR
WITH BRAKE FLUID AND BLEED BRAKE SYSTEM
(See page BR-4)
6. CHECK FOR LEAKS
7. CHECK AND ADJUST BRAKE PEDAL
(See page BR-9)
