Page 537 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BR0JI-1 1 F04993 F04994 F04995 BR-16 - BRAKEFRONT BRAKE PAD 2152 Author: Date: 2004 LAND CRUISER (RM1071U) REPLACEMENT 1. REMOVE FRONT WHEEL 2. INSPECT PAD LINING THICKNESS Check the pad thickness

Page 538 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - BRAKEFRONT BRAKE PAD BR-17 2153 Author: Date: 2004 LAND CRUISER (RM1071U) NOTICE: There should be no oil or grease adhering to the friction surfaces of the pads or the disc. 8. INSTALL 2 PAD RE

Page 539 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BR0K1-06 F05023 N´m (kgf´cm, ft´lbf) : Specified torque Front Speed Sensor 8.0 (82, 71 in.´lbf) 13 (130, 9) 13 (130, 9) BR-68 - BRAKEFRONT SPEED SENSOR 2204 Author: Date: 2004 LAND CRUISER (R

Page 540 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BR0K3-13 BR-70 - BRAKEFRONT SPEED SENSOR 2206 Author: Date: 2004 LAND CRUISER (RM1071U) INSTALLATION Installation is in the reverse order of removal (See page BR-69). HINT: After installation, che

Page 541 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BR0K2-03 F05358 F05002 - BRAKEFRONT SPEED SENSOR BR-69 2205 Author: Date: 2004 LAND CRUISER (RM1071U) REMOVAL REMOVE SPEED SENSOR (a) Disconnect the speed sensor connector. (b) Remove the resin cl

Page 542 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BR0K8-20 F17443Non-reusable part N´m (kgf´cm, ft´lbf) : Specified torqueGasket Hydraulic Brake Booster Assembly LH Lower PanelFluid Level Warning Switch Connector No. 2 Heater to Register Duct C

Page 543 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual F13209 Reservoir Set Screw Accumulator Bracket No. 1 Pump Bracket Actuator No. 1 TubeAccumulator O-ring Silencer Tube Grommet PistonCylinder Boot Clevis Reservoir Cap No. 2 Pump Bracket SleeveCollar

Page 544 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual F04472 SST SST BR12D-05 F04473 SST F13233 30 mm Deeper Socket BR-62 - BRAKEHYDRAULIC BRAKE BOOSTER 2198 Author: Date: 2004 LAND CRUISER (RM1071U) DISASSEMBLY 1. PLACE HYDRAULIC BRAKE BOOSTER IN VI
