Page 913 of 3115

DIC91-01
DI-526- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
719 Author: Date:
2004 LAND CRUISER (RM1071U)
PROBLEM SYMPTOMS TABLE
If a normal code is displayed during the DTC check but the problem still occurs, check the circuits for each
problem symptom in the order given in the table below and proceed to the relevant troubleshooting page.
NOTICE:
When replacing the skid control ECU, sensor, etc., turn the ignition switch OFF.
SymptomSuspected AreaSee page
ABS does not operate
BA does not operate
Only when 1. to 4. are all normal and the problem is still
occurring, replace the skid control ECU.
1. Reconfirm the DTC and check that the normal code is
output.
2. IG power source circuit
3. Speed sensor circuit
4. Check the hydraulic brake booster with a checker or
hand-held tester.
If abnormal, check the hydraulic circuit for leakage (See
page DI-655).
DI-505
DI-558
DI-615
BR-40
ABS does not operate efficiently
BA does not operate
Only when 1. to 4. are all normal and the problem is still
occurring, replace the skid control ECU.
1. Reconfirm the DTC and check that the normal code is
output.
2. Speed sensor circuit
3. Stop light switch circuit
4. Check the hydraulic brake booster with a checker or
hand-held tester.
If abnormal, check the hydraulic circuit for leakage (See
page DI-655).
DI-505
DI-615
DI-573
BR-40
ABS warning light abnormal1. ABS warning light circuit
2. Skid control ECUDI-627
IN-36
DTC check cannot be done
Only when 1. to 4. are all normal and the problem is still
occurring, replace the skid control ECU.
1. ABS warning light circuit
2. VSC OFF indicator light, center diff. lock indicator switch
circuit
3. Center diff. lock indicator switch circuit
4. Tc terminal circuit
DI-627
DI-645
DI-612
DI-651
Speed sensor signal check cannot be done1. Ts terminal circuit
2. Skid control ECUDI-653
IN-36
TRAC does not operate
Only when 1. to 4. are all normal and the problem is still
occurring, replace the skid control ECU.
1. Check the DTC, reconfirming that the normal code is
output.
2. IG power source circuit
3. Check the hydraulic circuit for leakage.
4. Speed sensor circuit
DI-505
DI-558
DI-655
DI-615
VSC does not operate
Only when 1. to 7. are all normal and the problem is still
occurring, replace the skid control ECU.
1. Check the DTC, reconfirming that the normal code is
output.
2. IG power source circuit
3. Check the hydraulic circuit for leakage.
4. Speed sensor circuit
5. Deceleration sensor circuit
6. Yaw rate sensor circuit
7. Steering angle sensor circuit
DI-505
DI-558
DI-655
DI-615
DI-570
DI-553
DI-605
Page 914 of 3115
- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-527
720 Author: Date:
2004 LAND CRUISER (RM1071U) VSC TRAC warning light abnormal
1. VSC TRAC warning light circuit
2. Skid control ECUDI-631
IN-36
BRAKE warning light abnormal1. BRAKE warning light circuit
2. Skid control ECUDI-635
IN-36
SLIP indicator light abnormal1. SLIP indicator light circuit
2. Skid control ECUDI-639
IN-36
VSC OFF indicator abnormal1. VSC OFF indicator light, center diff. lock switch circuit
2. Skid control ECUDI-645
IN-36
TRAC indicator light abnormal1. TRAC indicator light circuit
2. Skid control ECUDI-642
IN-36
Page 915 of 3115

DIC8Z-01
F02094
A44 A43
A42A41
- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-523
716 Author: Date:
2004 LAND CRUISER (RM1071U)
TERMINALS OF ECU
Symbols (Terminals No.)Wiring ColorConditionSTD Voltage (V)
SA1 (A41 - 2) - GND (A41 - 6,
31, A42 - 8, 17)G - W-BIG switch ON, ABS warning light OFF10 to 14 V
SA2 (A41 - 3) - GND (A41 - 6,
31, A42 - 8, 17)B - W-BIG switch ON, ABS warning light OFF10 to 14 V
SA3 (A41 - 4) - GND (A41 - 6,
31, A42 - 8, 17)G-W - W-BIG switch ON, ABS warning light OFF10 to 14 V
STR (A41 - 5) - GND (A41 - 6,
31, A42 - 8, 17)G-Y - W-BIG switch ON, ABS warning light OFF10 to 14 V
SFLR (A41 - 7) - GND (A41 -
6, 31, A42 - 8, 17)B-Y - W-BIG switch ON, ABS warning light OFF10 to 14 V
SRRH (A41 - 8) - GND (A41 -
6, 31, A42 - 8, 17)W - W-BIG switch ON, ABS warning light OFF10 to 14 V
SRRR (A41 - 9) - GND (A41 -
6, 31, A42 - 8, 17)B-O - W-BIG switch ON, ABS warning light OFF10 to 14 V
VCM (A41 - 10) - GND (A41 -
6, 31, A42 - 8, 17)B - W-BIG switch ON4.5 to 5.5 V
PH (A41 - 11) - GND (A41 - 6,OWBIG switch ON, pressure switch (PH) ONBelow 0.9 VPH (A41 11 ) GND (A41 6,
31, A42 - 8, 17)O - W-BIG switch ON, pressure switch (PH) OFF5 to 8 V
FR+ (A41 - 14) - FR- (A41 -
13)L - PIG switch ON, slowly turn right front wheelAC generation
FL+ (A41 - 16) - FL- (A41 -
15)R - GIG switch ON, slowly turn left front wheelAC generation
SR (A41 - 19) - R1+ (A41 - 1)G-Y - PIG switch ON, ABS warning light OFF10 to 14 V
SFLH (A41 - 21) - GND (A41 -
6, 31, A42 - 8, 17)Y - W-BIG switch ON, ABS warning light OFF10 to 14 V
PMC (A41 - 22) - E2 (A41 -
12)R - WIG switch ON, stop light switch OFF0.3 to 0.7 V
E2 (A41 - 12) - GND (A41 - 6,
31, A42 - 8, 17)W - W-BIG switch OFFContinuity
MTT (A41 - 27) - GND (A41 -
6, 31, A42 - 8, 17)B-R - W-BIG switch ON (Motor relay is OFF)Below 1.5 V
MT+ (A41 - 28) - MT- (A41 -
18)L - GRIG switch ON (Motor relay is ON)Below 1.5 V
MR1 (A41 - 29) - R1+ (A41 -
1)R - PIG switch ON, hydraulic brake booster pump motor running10 to 14 V
WA (A42 - 1) - GND (A41 - 6,
31, A42 - 8, 17)R-L - W-BIG switch ON, ABS warning light OFFBelow 2.0 V
Page 916 of 3115

DI-524- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEM
717 Author: Date:
2004 LAND CRUISER (RM1071U) BZ (A42 - 2) - GND (A41 - 6,
31, A42 - 8, 17)
L - W-BIG switch ON, VSC buzzer sound can be heardBelow 1.5 V
D/G (A42 - 3) - GND (A41 - 6,
31, A42 - 8, 17)V-W - W-BIG switch ON10 to 14 V
P (A42 - 5) - GND (A41 - 6,
31, A42 - 8, 17)G-W - W-BIG switch ON, shift lever is in P position10 to 14 V
IG1 (A42 - 6) - GND (A41 - 6,
31, A42 - 8, 17)B-W - W-BIG switch ON10 to 14 V
NEO (A42 - 7) - GND (A41 -
6, 31, A42 - 8, 17)W - W-BEngine idlingPulse generation
STP (A42 - 10) - GND (A41 -GW WBStop light switch pushed in10 to 14 VSTP (A42 10) GND (A41
6, 31, A42 - 8, 17)G-W - W-BStop light switch released2 to 5 V
Tc (A42 - 11) - GND (A41 - 6,PB WBIG switch ON and terminals Tc-E1 of DLC1 connectedBelow 1.0 VTc (A42 11 ) GND (A41 6,
31, A42 - 8, 17)P-B - W-BIG switch ON and terminals Tc-E1 of DLC1 not connected10 to 14 V
Ts (A42 - 12) - GND (A41 - 6,WWBIG switch ON and terminals Ts-E1 of DLC1 connectedBelow 1.0 VTs (A42 12) GND (A41 6,
31, A42 - 8, 17)W - W-BIG switch ON and terminals Ts-E1 of DLC1 not connected10 to 14 V
PKB (A42 - 13) - GND (A41 -RW WBIG switch ON, parking brake switch ONBelow 1.5 VPKB (A42 13) GND (A41
6, 31, A42 - 8, 17)R-W - W-BIG switch ON, parking brake switch OFF10 to 14 V
ENG+ (A42 - 14) - ENG -
(A42 - 22)R - GIG switch ONPulse generation
RL+ (A42 - 18) - RL- (A42 -
19)R - GIG switch ON, slowly turn left rear wheelAC generation
RR+ (A42 - 20) - RR- (A42 -
21)B - WIG switch ON, slowly turn right rear wheelAC generation
TRC+ (A42 - 24) - TRC- (A42
- 16)Y - LIG switch ONPulse generation
EXI2 (A43 - 2) - GND (A41 -BL WBIG switch ON, transfer in L4 position8 to 14 VEXI2 (A43 2) GND (A41
6, 31, A42 - 8, 17)B-L - W-BIG switch ON, transfer in any position except L4Below 1.5 V
EXI (A43 - 3) - GND (A41 - 6,PB WBIG switch ON, center diff. lock switch ONBelow 2.0 VEXI (A43 3) GND (A41 6,
31, A42 - 8, 17)P-B - W-BIG switch ON, center diff. lock switch OFF10 to 14 V
VSCW (A43 - 4) - GND (A41 -LW WBIG switch ON, VSC TRAC warning light ONBelow 2.0 VVSCW (A43 4) GND (A41
6, 31, A42 - 8, 17)L-W - W-BIG switch ON, VSC TRAC warning light OFF10 to 14 V
BRL (A43 - 5) - GND (A41 - 6,YG WBIG switch ON, BRAKE warning light ON10 to 14 VBRL (A43 5) GND (A41 6,
31, A42 - 8, 17)Y-G - W-BIG switch ON, BRAKE warning light OFFBelow 2.0 V
IND (A43 - 6) - GND (A41 - 6,LB WBIG switch ON, SLIP indicator light ONBelow 2.0 VIND (A43 6) GND (A41 6,
31, A42 - 8, 17)L-B - W-BIG switch ON, SLIP indicator light OFF10 to 14 V
WT (A43 - 7) - GND (A41 - 6,LR WBIG switch ON, VSC OFF indicator light ONBelow 2.0 VWT (A43 7) GND (A41 6,
31, A42 - 8, 17)L-R - W-BIG switch ON, VSC OFF indicator light OFF10 to 14 V
VYS (A43 - 9) - GYAW (A43 -
27)B - W-RIG switch ON4.5 to 5.5 V
GL2 (A43 - 10) - GYAW (A43 -
27)Y - PIG switch ON, vehicle is placed on the horizontal surface2.0 to 3.0 V
SS1+ (A43 - 14) - SS1- (A43 -
23)W - GEngine idling, slowly turn steering wheelPulse generation
(See page DI-546)
INFR (A43 - 15) - GND (A41 -BR WBIG switch ON, ACTIVE TRAC indicator light ONBelow 1.5 VINFR (A43 15) GND (A41
6, 31, A42 - 8, 17)B-R - W-BIG switch ON, ACTIVE TRAC indicator light OFF10 to 14 V
YD (A43 - 19) - GND (A41 - 6,
31, A42 - 8, 17)L - W-BApprox. 1 sec. after IG switch ON4.5 to 5.3 V
Page 917 of 3115

- DIAGNOSTICSABS & VEHICLE STABILITY CONTROL (VSC) &
BRAKE ASSIST (BA) SYSTEMDI-525
718 Author: Date:
2004 LAND CRUISER (RM1071U) GL1 (A43 - 22) - GYAW (A43 -
27)
G-RIG switch ON, vehicle is placed on the horizontal surface2.0 to 3.0 V
GYAW (A43 - 27) - GND (A41
- 6, 31, A42 - 8, 17)R - W-BIG switch OFFContinuity
YAW (A43 - 28) - GYAW (A43
- 27)W - RIG switch ON, vehicle is in stationary condition2 to 3 V
SRLR (A44 - 1) - GND (A41 -
6, 31, A42 - 8, 17)R-G - W-BIG switch ON, ABS warning light OFF10 to 14 V
MR2 (A44 - 2) - R2+ (A44 - 3)Y-B - W-LIG switch ON, hydraulic brake booster pump motor running10 to 14 V
AST (A44 - 6) - GND (A41 - 6,
31, A42 - 8, 17)R-Y - W-BIG switch ON, ABS warning light OFF10 to 14 V
SRLH (A44 - 7) - GND (A41 -
6, 31, A42 - 8, 17)R-W - W-BIG switch ON, ABS warning light OFF10 to 14 V
SFRR (A44 - 8) - GND (A41 -
6, 31, A42 - 8, 17)B-W - W-BIG switch ON, ABS warning light OFF10 to 14 V
PL (A44 - 9) - GND (A41 - 6,WWBIG switch ON, pressure switch ON3 to 5 VPL (A44 9) GND (A41 6,
31, A42 - 8, 17)W - W-BIG switch ON, pressure switch OFF7 to 11 V
TRIG (A44 - 20) - GND (A41 -
6, 31, A42 - 8, 17)L - RIG switch ON, ABS warning light OFF10 to 14 V
+BO (A44 - 21) - GND (A41 -
6, 31, A42 - 8, 17)LG - LIG switch ON10 to 14 V
SFRH (A44 - 16) - GND (A41
- 6, 31, A42 - 8, 17)LG - W-BIG switch ON, ABS warning light OFF10 to 14 V
IG2 (A44 - 22) - GND (A41 -
6, 31, A42 - 8, 17)B-W - W-BIG switch ON10 to 14 V
Page 918 of 3115
- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-497
690 Author: Date:
2004 LAND CRUISER (RM1071U)
Pattern Select Switch Circuit (2nd Start Switch)
CIRCUIT DESCRIPTION
When 2nd start mode is selected with the pattern select switch, the ECM controls the solenoid valves and
the transmission starts from 2nd gear.
In D position, the transmission automatically shifts up through 3rd to 5th as usual.
In 2nd position, the transmission is held in 2nd gear.
DIB3N-02
Page 919 of 3115
D12771
ECM
PWR E829 J/B No.4
E4
(*) Electronically Controlled
Transmission Pattern Select SW
5
W-B
IF IU19
SB Combination Meter
C1519
Cowl Side J/B LH
L-R
1
2
3 C1520
SB312
4F 4C
W-BB
B
E8
E8
E818
28 2nd
PWR
5L-W 10
3M
3PCowl Side J/B RH
18
2E66 24
2E 2QP-B
SNWI MPX1 MPX2
(*) Pattern Select Switch (2nd Start Switch)
When the 2nd start switch is pushed, the switch contact is made and the 2nd mode is selected.
To cancel the 2nd start, push the 2nd start switch once again. The 2nd start is automatically cancelled
out when the ignition switch is turned OFF. DI-498
- DIAGNOSTICSAUTOMATIC TRANSMISSION
691 Author: Date:
2004 LAND CRUISER (RM1071U)
WIRING DIAGRAM
Page 920 of 3115

D03047
32
D13411
SNWI E5
E6E7E8E9
- DIAGNOSTICSAUTOMATIC TRANSMISSION
DI-499
692 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION PROCEDURE
1 Check pattern select switch (2nd start switch).
PREPARATION:
Disconnect the pattern select switch connector.
CHECK:
Check continuity between terminals 2 and 3 of pattern select
switch connector when pattern select switch is set to 2nd start
switch ON and OFF.
OK:
2nd start switchSpecified condition
Press continuously º2ndº switchContinuity
Release º2ndº switchNo continuity
NG Replace the pattern select switch.
OK
2 Check harness and connector between terminal SNWI of ECM and body ground.
PREPARATION:
(a) Connect the pattern select switch connector.
(b) Disconnect the connector of ECM.
CHECK:
Check continuity between terminal SNWI of ECM and body
ground when the pattern select switch is set to 2nd start switch
ON and OFF.
OK:
2nd start switchSpecified condition
Press contnuously º2ndº switchContinuity
Release º2ndº switchNo Continuity
OK Proceed to next circuit inspection shown on
matrix chart (See page DI-396).
NG
Repair or replace harness or connector
(See page IN-36).
