TOYOTA LAND CRUISER 1998 Factory Repair Manual A19522A19630 VC E2(+) (-) E5 ECM Connector A19627A19432 A19637 E2PTNK Vacuum Disconnect(+) (-) E5 E9 DI-240 - DIAGNOSTICSENGINE 433 Author: Date: 11 Check voltage between terminals VC and E2 of ECM

Page 1290 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A19638 PRG Air Air FF EE VSV is ON VSV is OFF E5 - DIAGNOSTICSENGINE DI-241 434 Author: Date: 13 Check for open and short in harness and connector between vapor pressure sen- sor and ECM (See page

Page 1291 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A19639VSV is OFF VSV is ON CCV Air E Air E FF E5 DI-242 - DIAGNOSTICSENGINE 435 Author: Date: 16 Check for open and short in harness and connector between EFI or ECD relay and EVAP VSV, and EVAP VSV

Page 1292 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A19641VSV is ON VSV is OFFTBP Air E Air E FF E9 - DIAGNOSTICSENGINE DI-243 436 Author: Date: 19 Check for open and short in harness and connector between EFI or ECD relay and CCV, and CCV and ECM (S

Page 1293 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual DI-244 - DIAGNOSTICSENGINE 437 Author: Date: 22 Check for open and short in harness and connector between EFI or ECD relay and pressure switching valve, and pressure switching valve and ECM (See pag

Page 1294 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A19378A20057 ECM EVAP VSV Charcoal Canister Fuel Tank Fig. 1 (2) (3) (4) (6) (8) (9) (1) (5) (7)Vapor Pressure Sensor CCVPressure Switching Valve - DIAGNOSTICSENGINE DI-245 438 Author: Date: DTC P0

Page 1295 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A21544 CCV Pressure Switching Valve EVAP VSV Cold Start ECT/IAT near same temp.Open ClosedOpen ClosedOpen Closed Closed Closed Open P0441, P0446, P0455, P2418 Negative Pressure OccursP0442, P0456 Tan

Page 1296 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - DIAGNOSTICSENGINE DI-247 440 Author: Date: HINT: Refer to DTCs P0441, P0446 and P2418 DTC No.DTC Detecting ConditionTrouble Area P0442After the negative pressure introduction has been completed, i
