Page 2937 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA154-02 F05248 Torsion Bar SpringAnchor Arm Swivel Anchor Arm Anchor Arm Adjusting Seat Anchor Arm Adjusting Bolt Torque Arm Lower Suspension Arm Engine Under Cover  No. 1 Bushing Wire  Dust Cove

Page 2938 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA156-02 F04385 SA-76 - SUSPENSION AND AXLEFRONT LOWER SUSPENSION ARM 2026 Author: Date: 2004 LAND CRUISER (RM1071U) INSPECTION INSPECT LOWER SUSPENSION ARM BALL JOINT FOR ROTATION CONDITION (a) A

Page 2939 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA158-02 - SUSPENSION AND AXLEFRONT LOWER SUSPENSION ARM SA-79 2029 Author: Date: 2004 LAND CRUISER (RM1071U) INSTALLATION Installation is in the reverse order of removal (See page SA-75). HINT: A

Page 2940 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA155-02 F04381 F04382 F04383 SST F04384 - SUSPENSION AND AXLEFRONT LOWER SUSPENSION ARM SA-75 2025 Author: Date: 2004 LAND CRUISER (RM1071U) REMOVAL 1. REMOVE FRONT WHEEL Torque: 131 N´m (1,340

Page 2941 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA157-02 F04353 SST SST F04354 SST F05253 SST F05254 SST - SUSPENSION AND AXLEFRONT LOWER SUSPENSION ARM SA-77 2027 Author: Date: 2004 LAND CRUISER (RM1071U) REPLACEMENT 1. REPLACE NO. 1 BUSHING (

Page 2942 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual F04355 SA-78 - SUSPENSION AND AXLEFRONT LOWER SUSPENSION ARM 2028 Author: Date: 2004 LAND CRUISER (RM1071U) 3. REPLACE DUST COVER (a) Remove the wire and dust cover. (b) Coat the ball joint with g

Page 2943 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA14R-02 F05252 Non-reusable part N´m (kgf´cm, ft´lbf) : Specified torque Cushion Shock Absorber 68 (700, 50) 135 (1,400, 100) Cushion Retainer Front Fender Apron Retainer SA-60 - SUSPENSION AND

Page 2944 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA14U-03 F05250 - SUSPENSION AND AXLEFRONT SHOCK ABSORBER SA-63 2013 Author: Date: 2004 LAND CRUISER (RM1071U) DISPOSAL DISCARD SHOCK ABSORBER Before discarding the shock absorber, drill a hole of
