- AUTOMATIC TRANSMISSIONTORQUE CONVERTER CLUTCH AND DRIVE PLATE
1888 Author: Date:
2004 LAND CRUISER (RM1071U)
TORQUE CONVERTER CLUTCH
AND DRIVE PLATE
INSPECTION
1. INSPECT ONE-WAY CLUTCH
(a) Install SST so that it fits in the notch of the converter hub
and outer race of the one-way clutch.
SST 09350-30020 (09351-32020)
(b) Press on the serrations of stator with a finger and rotate
it.
(c) Check if it rotates smoothly when turned clockwise and
locks up when turned counterclockwise.
If necessary, clean the converter clutch and retest the one-way
clutch.
Replace the converter clutch if the clutch still fails in the test.
2. MEASURE DRIVE PLATE RUNOUT AND INSPECT
RING GEAR
Set up a dial indicator and measure the drive plate runout.
Maximum runout: 0.20 mm (0.0079 in.)
If runout is not within the specification or if the ring gear is dam-
aged, replace the drive plate. If installing a new drive plate, note
the orientation of the spacers and tighten the bolts.
Torque:
1st: 49 N´m (500 kgf´cm, 36 ft´lbf)
2nd: Turn extra 90°
3. MEASURE TORQUE CONVERTER CLUTCH SLEEVE
RUNOUT
(a) Temporarily mount the torque converter clutch to the drive
plate.
Set up a dial indicator and measure the torque converter
clutch sleeve runout.
Maximum runout: 0.30 mm (0.0118 in.)
If runout is not within the specification, correct it by reorienting
the installation of the torque converter clutch.
If excessive runout cannot be corrected, replace the torque
converter clutch.
(b) Remove the torque converter clutch.
Page 146 of 3115

AT111-02
D13663
AT0103
D12703
D12704
Bolt
- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-8
1862 Author: Date:
VALVE BODY ASSEMBLY
ON-VEHICLE REPAIR
1. REMOVE ENGINE NO.2 UNDER COVER
2. DRAIN ATF
3. REMOVE OIL PAN
NOTICE:
Some fluid will remain in the oil pan.
(a) Remove the 20 bolts.
(b) Remove the oil pan gasket.
4. EXAMINE PARTICLES IN PAN
Remove the magnets and use them to collect steel particles.
Carefully look at the foreign matter and particles in the pan and
on the magnets to anticipate the type of wear you will find in the
transmission.
Steel (magnetic)...bearing, gear and clutch plate wear
Brass (non-magnetic)...bushing wear
5. REMOVE OIL STRAINER
Remove the 4 bolts, the oil strainer and the O-ring.
NOTICE:
Be careful as some fluid will come out with the oil strainer.
6. DISCONNECT TEMPERATURE SENSOR
(a) Disconnect the 7 solenoid connectors.
(b) Remove 2 bolts and the 2 temperature sensors clamp
from the valve body.
(c) Disconnect the 2 temperature sensor from the valve body.
7. DISCONNECT 7 CONNECTORS FROM SHIFT SOLE-
NOID VALVES
Page 147 of 3115

D12705
D12706
Shift
Solenoid
Valve SL2Shift
Solenoid
Valve SLUShift
Solenoid
Valve SR
Shift
Solenoid
Valve S2 Shift
Solenoid
Valve S1 Shift
Solenoid
Valve SL1 Shift
Solenoid
Valve SLT
D12707
Pin
- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-9
1863 Author: Date:
8. REMOVE VALVE BODY
(a) Remove the 19 bolts and the valve body.
(b) Remove the 3 drum seal gaskets.
9. REMOVE SOLENOID VALVE
(a) Remove the 2 bolts and the shift solenoid valve SR.
(b) Remove the 3 bolts and the shift solenoid valve S1 and
S2.
(c) Remove the 2 bolts, 2 solenoid lock plates and the 4
straight pins.
(d) Remove the shift solenoid SL2 and the shift solenoid
valve SLU.
(e) Remove the shift solenoid SL1 and the shift solenoid
valve SLT.
(f) Remove the O-ring from the solenoid valve S2.
10. INSTALL SOLENOID VALVE
(a) Install a new O-ring to shift solenoid valve S2.
(b) Install the shift solenoid SL1 and the shift solenoid valve
SLT.
(c) Install the shift solenoid SL2 and the shift solenoid valve
SLU.
(d) Install the 4 straight pins and the 2 solenoid lock plates
with the 2 bolts.
Torque:6.4 N´m (65 kgf´cm,57 in´lbf)
(e) Install the shift solenoid valve S1and S2 with the 2 bolts.
Torque:10 N´m (102 kgf´cm,7 ft´lbf)
(f) Install the shift solenoid valve SR with the 2 bolts.
Torque:6.4 N´m (65 kgf´cm,5.7 ft´lbf)
11. INSTALL VALVE BODY
HINT:
Align the groove of the manual valve with the pin of the lever.
(a) Install the 3 new drum seal gaskets to the transmission
case.
Page 148 of 3115

D12705
A
A
AAAA A B
D12704
A B
OrangeBlue
D12703
D13663
- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-10
1864 Author: Date:
(b) Install the 19 bolts and the valve body.
Torque:
BoltA.B: 11 N´m (110 kgf´cm, 8 ft´lbf)
Bolt length:
Bolt A: 25 mm (0.98 in.)
Bolt B: 36 mm (1.42 in.)
12. CONNECT TEMPERATURE SENSOR
(a) Connect the 2 temperature sensors to the valve body, and
install the 2 temperature sensors clamp with the 2 bolts.
Torque:
A: 11 N´m (112 kgf´cm, 8 ft´lbf)
B: 10 N´m (100 kgf´cm, 7 ft´lbf)
Bolt length:
Bolt A: 36 mm (1.42 in.)
Bolt B: 12 mm (0.47 in.)
Sensor wire harness:
Wire harnessColor
for linear controlOrange
for oil temp warning lampBlue
13. CONNECT 7 CONNECTORS TO SHIFT SOLENOID
VA LV E S
14. INSTALL OIL STRAINER
(a) Install a new O-ring.
(b) Install the oil strainer with the 4 bolts.
Torque: 10 N´m (100 kgf´cm, 7 ft´lbf)
15. INSTALL OIL PAN
HINT:
Remove any packing material, and be careful not to spill oil on
the contacting surfaces of the transmission case and the oil
pan.
(a) Install a new gasket and oil pan.
(b) Install the 20 bolts and oil pan.
Torque: 4.4 N´m (45 kgf´cm, 39 in´lbf)
Page 149 of 3115
- AUTOMATIC TRANSMISSIONVALVE BODY ASSEMBLY
AT-1 1
1865 Author: Date:
16. FILL ATF AND CHECK ATF LEVEL
(a) Install a new gasket and a drain plug.
Torque: 20 N´m (204 kgf´cm, 15 ft´lbf)
(b) Remove the refill plug.
(c) Fill new fluid through the refill hole (See page AT-3-1).
17. INSTALL ENGINE NO.2 UNDER COVER
Page 150 of 3115
D12734
AT07Y-02
D12736
D12734
AT-4
- AUTOMATIC TRANSMISSIONVEHICLE SPEED SENSOR
1858 Author: Date:
2004 LAND CRUISER (RM1071U)
VEHICLE SPEED SENSOR
ON-VEHICLE REPAIR
1. DISCONNECT NO. 1 VEHICLE SPEED SENSOR CON-
NECTOR
2. REMOVE NO. 1 VEHICLE SPEED SENSOR
Remove the bolt and the No. 1 vehicle speed sensor.
3. DISASSEMBLE NO. 1 VEHICLE SPEED SENSOR
(a) Remove the O-ring from the speedometer driven gear
assembly.
(b) Remove the clip and the speedometer driven gear from
the speedometer driven gear sleeve.
4. ASSEMBLE NO. 1 VEHICLE SPEED SENSOR
(a) Install the speedometer driven gear and the clip to the
speedometer driven gear sleeve.
(b) Coat a new O-ring with ATF.
(c) Install the O-ring to the speedometer driven gear assem-
bly.
5. INSTALL NO. 1 VEHICLE SPEED SENSOR
Install the No. 1 vehicle speed sensor with the bolt.
Torque: 16 N´m (160 kgf´cm, 12 ft´lbf)
6. CONNECT NO. 1 VEHICLE SPEED SENSOR CON-
NECTOR
Page 151 of 3115
D12737
Speed Sensor NT
Speed Sensor SP2
D02395
D12737
Speed Sensor NT
Speed Sensor SP2
- AUTOMATIC TRANSMISSIONVEHICLE SPEED SENSOR
AT-5
1859 Author: Date:
2004 LAND CRUISER (RM1071U)
7. DISCONNECT SPEED SENSOR NT AND SP2 CON-
NECTORS
8. REMOVE SPEED SENSOR NT AND SP2
(a) Remove the 2 bolts, speed sensor NT and SP2.
(b) Remove 2 O-rings from the speed sensor NT and SP2.
9. INSTALL SPEED SENSOR NT AND SP2
(a) Coat 2 new O-rings with ATF and install them to the
speed sensor NT and SP2.
(b) Install the speed sensor NT and SP2 with 2 bolts.
Torque: 5.4 N´m (55 kgf´cm, 48 in.´lbf)
10. CONNECT SPEED SENSOR NT AND SP2 CONNEC-
TORS
Page 152 of 3115
BE0SD-04
I06143
6 3
I06144
6 3
I24666
Integration panel control assembly
- BODY ELECTRICALANTENNA
BE-175
2548 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. Auto Antenna Models:
INSPECT ANTENNA MOTOR
(a) Connect the positive (+) lead from the battery to terminal
3 and the negative (-) lead to terminal 6.
(b) Check that the motor turns (moves upward).
NOTICE:
These tests must be done quickly (within 3 - 5 seconds) to
prevent the coil from burning out.
(c) Then, reverse the polarity, check that the motor turns the
opposite way (moves downward).
NOTICE:
These tests must be done quickly (within 3 - 5 seconds) to
prevent the coil from burning out.
2. INSPECT ANTENNA SWITCH CONTINUITY
Switch positionTester connectionSpecified condition
UP button FREE4 - 5No continuity
UP button Pushed in4 - 5Continuity
DOWN button FREE9 - 5No continuity
DOWN button Pushed in9 - 5Continuity
If continuity is not as specified, replace the switch.
