TOYOTA LAND CRUISER 1998 Factory Repair Manual IG0152
B03199
Ohmmeter
B02713
Ohmmeter IG-4
- IGNITIONIGNITION SYSTEM
1807 Author: Date:
2004 LAND CRUISER (RM1071U)
(f) Clean the spark plugs.
If the electrode has traces of wet carbon, allow it

Page 2402 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual IN0JF-01
BO4111
Negative Cable
IN-10
- INTRODUCTIONFOR ALL OF VEHICLES
10 Author: Date:
2004 LAND CRUISER (RM1071U)
FOR ALL OF VEHICLES
PRECAUTION
1. FOR VEHICLES EQUIPPED WITH SRS AIRBAG AND
SEAT

IN0JF-01
BO4111
Negative Cable
IN-10
- INTRODUCTIONFOR ALL OF VEHICLES
10 Author: Date:
2004 LAND CRUISER (RM1071U)
FOR ALL OF VEHICLES
PRECAUTION
1. FOR VEHICLES EQUIPPED WITH SRS AIRBAG AND
SEAT BELT PRETENSIONER
(a) The LAND CRUISER is equipped with an SRS (Supple-
mental Restraint System), such as the driver airbag, front
passenger airbag assembly and seat belt pretensioner.
Failure to carry out service operations in the correct se-
quence could cause the supplemental restraint system to
unexpectedly deploy during servicing, possibly leading to
a serious accident.
Further, if a mistake is made in servicing the supplemental
restraint system, it is possible the SRS may fail to operate
when required. Before servicing (including removal or
installation of parts, inspection or replacement), be sure
to read the following items carefully, then follow the cor-
rect procedure described in this manual.
(b) GENERAL NOTICE
(1) Malfunction symptoms of the supplemental re-
straint system are difficult to confirm, so the diag-
nostic trouble codes become the most important
source of information when troubleshooting. When
troubleshooting the supplemental restraint system,
always inspect the diagnostic trouble codes before
disconnecting the battery (See page DI-692).
(2) Work must be started after 90 seconds from the
time the ignition switch is turned to the ºLOCKº posi-
tion and the negative (-) terminal cable is discon-
nected from the battery.
(The supplemental restraint system is equipped
with a back-up power source so that if work is
started within 90 seconds of disconnecting the neg-
ative (-) terminal cable from the battery, the SRS
may deploy.)
When the negative (-) terminal cable is discon-
nected from the battery, memory of the clock and
audio systems will be cancelled. So before starting
work, make a record of the contents memorized by
the each memory system. Then when work is fin-
ished, reset the clock and audio systems as before.
To avoid erasing the memory of each memory sys-
tem, never use a back-up power supply from anoth-
er battery.

Page 2403 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual F04784Marks
- INTRODUCTIONFOR ALL OF VEHICLES
IN-1 1
11 Author: Date:
2004 LAND CRUISER (RM1071U)
(3) Even in cases of a minor collision where the SRS
does not deploy, the steering wheel pad, fron

Page 2404 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual B09710
Example:
Correct
Wrong
Z13950
Example: IN-12
- INTRODUCTIONFOR ALL OF VEHICLES
12 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) STEERING WHEEL PAD (with Airbag)
(1) When removing the steeri

Page 2405 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual B04200
Example:
Correct
Wrong
Z13951
Example:
- INTRODUCTIONFOR ALL OF VEHICLES
IN-13
13 Author: Date:
2004 LAND CRUISER (RM1071U)
(e) FRONT PASSENGER AIRBAG ASSEMBLY
(1) Always store a removed or

Page 2406 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual B13205
Example:
Correct Wrong
B01929
Example: IN-14
- INTRODUCTIONFOR ALL OF VEHICLES
14 Author: Date:
2004 LAND CRUISER (RM1071U)
(f) SIDE AIRBAG ASSEMBLY
(1) Always store a removed or new side a

Page 2407 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual B12627
Example:
Correct Wrong
Clear Plastic Bag
R06952H12059B08605
Example:
- INTRODUCTIONFOR ALL OF VEHICLES
IN-15
15 Author: Date:
2004 LAND CRUISER (RM1071U)
(g) CURTAIN SHIELD AIRBAG ASSEMBLY

Page 2408 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual B04210
Example:
IN-16
- INTRODUCTIONFOR ALL OF VEHICLES
16 Author: Date:
2004 LAND CRUISER (RM1071U)
(h) SEAT BELT PRETENSIONER
(1) Never measure the resistance of the seat belt pre-
tensioner. (T
