H20954
H20955
: 2 Clips
H18913
H18912
: 6 Clips BO-92
- BODYINSTRUMENT PANEL
2666 Author: Date:
2004 LAND CRUISER (RM1071U)
11. INSTALL REAR CONSOLE BOX
(a) w/o Disc player changer:
Install the rear console box with the 6 bolts and the 8
screws.
(b) w/ Disc player changer:
Install the rear console box with the 4 bolts and the 8
screws.
12. INSTALL REAR RADIO CONTROL PANEL
Install the rear radio control panel with the 3 screws, then con-
nect the connector.
13. INSTALL CONSOLE REAR END PANEL
(a) Install the console rear end panel with the 2 screws.
(b) Install the rear console cup holder box.
14. INSTALL FRONT CONSOLE PANEL
Install the front console panel, then install the transfer shift lever
knob.
15. INSTALL RADIO WITH A/C CONTROL ASSEMBLY
HINT:
w/ Navigation System:
When removing/installing or replacing EMV, or when discon-
necting/connecting the battery terminal, turn the IG ON and
OFF twice for initial display setting.
16. INSTALL CENTER REGISTERS
Connect the connectors, then install the center registers.
17. INSTALL LOWER NO. 2 PANEL
Install the lower No. 2 panel with the 3 screws.
Page 418 of 3115
H21422
H21421
CA
C
B
- BODYINSTRUMENT PANEL
BO-93
2667 Author: Date:
2004 LAND CRUISER (RM1071U)
18. CONNECT AIRBAG CONNECTOR (See page RS-41)
19. INSTALL GLOVE COMPARTMENT DOOR
(a) Connect the glove compartment door damper clip, then
install the glove compartment door.
(b) Install the 2 screws.
20. INSTALL COMBINATION METER
(a) Check that the set-in connectors are connected securely
in the installation holes on the instrument panel.
(b) Place the combination meter on the instrument panel.
(c) Install the combination meter by tightening the screws,
ºAº, ºBº and ºCº in order.
Page 419 of 3115

H05279
Check Pin
Check Pin
H04808
H21657
H21283
: 5 Clips BO-94
- BODYINSTRUMENT PANEL
2668 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) Tighten the connection bolts.
HINT:
When connection completes, the bolts turns idly, causing
turning noise.
Check that the connection check pins protrude from the
lower side of the connection bolts.
NOTICE:
Follow the procedures in the order of (c) and (d). Otherwise,
set-in connectors on the wire harness side and connec-
tors on the meter side might not be connected properly.
21. INSTALL STEERING COLUMN
(See page SR-24 or SR-37)
22. INSTALL NO. 2 HEATER TO REGISTER DUCT
Install the No. 2 heater to register duct with the screw.
23. INSTALL COMBINATION SWITCH
(a) Install the combination switch with the 4 screws.
(b) Install the clamp, then connect the connectors.
24. INSTALL COLUMN COVERS
Install the column covers with the 3 screws.
25. INSTALL LH LOWER PANEL
Install the LH lower panel with the 3 bolts.
26. INSTALL LOWER NO. 1 PANEL
Connect the connector, then install the lower No. 1 panel with
the screw.
27. INSTALL HOOD LOCK CONTROL CABLE LEVER AND
FUEL LID CONTROL CABLE LEVER
(a) Install the fuel lid control cable lever with the 2 screws.
(b) Install the hood lock control cable lever with the 2 screws.
Page 420 of 3115
2 Clips
H21279
H18904
- BODYINSTRUMENT PANEL
BO-95
2669 Author: Date:
2004 LAND CRUISER (RM1071U)
28. INSTALL CLUSTER FINISH PANEL
Connect the connecter, then install the cluster finish panel.
29. INSTALL STEERING WHEEL
(See page SR-24 or SR-37)
30. INSTALL FRONT PILLAR GARNISH
(a) Install the front pillar garnish.
(b) Use the same manner described above to the other side.
31. INSTALL FRONT ASSIST GRIP
(a) Install the assist grip with the 2 screws, then install the 2
assist grip plugs.
(b) Use the same manner described above to the other side.
32. INSTALL FRONT DOOR OPENING TRIMS
33. INSTALL COWL SIDE TRIMS
34. INSTALL FRONT DOOR SCUFF PLATES
Page 421 of 3115
BO1KN-01
BO-90
- BODYINSTRUMENT PANEL
2664 Author: Date:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
Reassembly is in the reverse order of disassembly (See page BO-89).
Page 422 of 3115

BO4IX-01
H20976
H20977
H20975
: 8 Clips
H20978
BO-84
- BODYINSTRUMENT PANEL
2658 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. w/ CD Changer Built In The Audio System:
SHIP MODE SETTING
(a) Take out all of the CDs.
NOTICE:
If they cannot be taken out, do not attempt to take out forci-
bly and send the unit for repair.
(b) Turn the ignition switch to ACC as pressing the ºSEEK
UPº and ºDISCº switches at the same time.
HINT:
When the ship mode has been set, ºSHIPº must be displayed.
(c) Turn the ignition switch to OFF and disconnect the battery
negative cable.
NOTICE:
Connecting the battery negative cable automatically end
the ship mode.
2. REMOVE CENTER REGISTER
(a) Using a moulding remover, remove the center register.
(b) Disconnect the connector.
(c) Use the same manner described above to the other side.
3. REMOVE RADIO WITH A/C CONTROL ASSEMBLY
(a) Remove the 4 bolts.
(b) Disconnect the radio with A/C control assembly cable and
remove the radio with A/C control assembly.
4. w/ CD Changer Built In The Audio System:
SHIP MODE CONFIRMATION
Check that a metal can be seen from holes marked ºSHIPº on
the back of the radio with A/C control assembly.
NOTICE:
If a metal cannot be seen from a hole on the back of the ra-
dio with A/C control assembly, repeat ºSHIP MODEº.
5. REMOVE FRONT DOOR SCUFF PLATES
6. REMOVE COWL SIDE TRIMS
7. REMOVE FRONT DOOR OPENING TRIMS
Page 423 of 3115

H18904
H21279
2 Clips
H21283
: 5 Clips
H21657
- BODYINSTRUMENT PANEL
BO-85
2659 Author: Date:
2004 LAND CRUISER (RM1071U)
8. REMOVE FRONT ASSIST GRIP
(a) Using a screwdriver, remove the assist grip plugs, then re-
move the 2 screws and assist grip.
HINT:
Tape up the screwdriver tip before use.
(b) Use the same manner described above to the other side.
9. REMOVE FRONT PILLAR GARNISH
(a) Using a screwdriver, remove the front pillar garnish.
HINT:
Tape up the screwdriver tip before use.
(b) Use the same manner described above to the other side.
10. REMOVE STEERING WHEEL
(See page SR-14 or SR-29)
11. REMOVE CLUSTER FINISH PANEL
Using a screwdriver, remove the cluster finish panel, then dis-
connect the connector.
HINT:
Tape up the screwdriver tip before use.
12. REMOVE HOOD LOCK CONTROL CABLE LEVER
AND FUEL LID CONTROL CABLE LEVER
(a) Remove the 2 screws and the hood lock control cable le-
ver.
(b) Remove the 2 screws and the fuel lid control cable lever.
13. REMOVE LOWER NO. 1 PANEL
(a) Remove the screw.
(b) Using a screwdriver, remove the lower No. 1 panel, then
disconnect the connectors.
HINT:
Tape up the screwdriver tip before use.
14. REMOVE LH LOWER PANEL
Remove the 3 bolts and the LH lower panel.
15. REMOVE COLUMN COVERS
Remove the 3 screws and the column covers.
16. REMOVE COMBINATION SWITCH
(a) Disconnect the connectors.
(b) Remove the clamp.
(c) Remove the 4 screws and the combination switch.
Page 424 of 3115

H04808
H21420
H04807
H21418
BO-86
- BODYINSTRUMENT PANEL
2660 Author: Date:
2004 LAND CRUISER (RM1071U)
17. REMOVE NO. 2 HEATER TO REGISTER DUCT
Remove the screw and the No. 2 heater to register duct as
shown in the illustration.
18. REMOVE STEERING COLUMN
(See page SR-14 or SR-29)
19. REMOVE COMBINATION METER
(a) Disconnect the connectors.
HINT:
The connectors can be disconnected by loosening the bolts.
(b) Remove the 4 screws.
(c) Using a screwdriver, remove the combination meter.
HINT:
Tape up the screwdriver tip before use.
20. REMOVE GLOVE COMPARTMENT DOOR
(a) Remove the 2 screws.
(b) Remove the glove compartment door, then disconnect
the glove compartment door damper clip.
21. DISCONNECT AIRBAG CONNECTOR
(See page RS-31)
(a) Using a screwdriver, remove the No. 1 under cover.
HINT:
Tape up the screwdriver tip before use.
(b) Slide the airbag connector to pull out from the No. 1 under
cover.
(c) Disconnect the airbag connector.
NOTICE:
When handling the airbag connector, take care not to dam-
age the airbag wire harness.
22. REMOVE LOWER NO. 2 PANEL
Remove the 3 screws and the lower No. 2 panel.
