TOYOTA LAND CRUISER 1998 Factory Repair Manual H18912 : 6 Clips H18913 : 2 Clips H20954 H20955 H21406 : 5 Clips - BODYINSTRUMENT PANEL BO-87 2661 Author: Date: 2004 LAND CRUISER (RM1071U) 23. REMOVE FRONT CONSOLE PANEL (a) Remove the transfer

Page 426 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual H18914 H18915 BO-88 - BODYINSTRUMENT PANEL 2662 Author: Date: 2004 LAND CRUISER (RM1071U) 28. REMOVE FRONT CONSOLE BOX AND FRONT CON- SOLE BOX BRACKET Remove the 2 bolts, the front console box and

Page 427 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1JO-03 H04871 H04872 H05218 - BODYLOWER BACK DOOR BO-29 2603 Author: Date: 2004 LAND CRUISER (RM1071U) ADJUSTMENT 1. ADJUST DOOR IN FORWARD/REARWARD AND VER- TICAL DIRECTIONS Loosen the door sid

Page 428 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1JM-03 H21440 Back Door Lock Control Cable Back Door Inside Handle Spacer Upper Back Door Striker Back Door Lock Control Back Door Lock Control Cable Door Lock Striker Tail Gate Stay Rear Light Asse

Page 429 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO217-02 H05258 H04862 : 16 Clips H04869 H04863 H04864 - BODYLOWER BACK DOOR BO-27 2601 Author: Date: 2004 LAND CRUISER (RM1071U) DISASSEMBLY 1. REMOVE REAR MAT SET PLATE (a) Remove the 5 screws.

Page 430 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual H04865 H04866 H04867 H04868 H04870 BO-28 - BODYLOWER BACK DOOR 2602 Author: Date: 2004 LAND CRUISER (RM1071U) 7. REMOVE KEY CYLINDER (a) Disconnect the connector. (b) Remove the clip and key cylin

Page 431 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1JP-01 BO-30 - BODYLOWER BACK DOOR 2604 Author: Date: 2004 LAND CRUISER (RM1071U) REASSEMBLY Reassembly is in the reverse order of disassembly (See page BO-27).

Page 432 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BO1LD-03 H18905 Rear Door Opening TrimRoof Headlining Rear Trim Upper Roof Side Inner Garnish Quarter Trim Jack CoverStriker Plate Quarter Trim Panel Rear Door Scuff PlateQuarter Belt MouldingRear Mat
