- SUSPENSION AND AXLEREAR STABILIZER BAR
SA-185
2135 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE REAR WHEELS
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
2. SUPPORT REAR AXLE HOUSING WITH JACK
3. DISCONNECT LH AND RH STABILIZER BAR BRACK-
ETS
Remove the 4 bolts and disconnect the LH and RH stabilizer bar
brackets.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
4. REMOVE STABILIZER BAR
(a) Remove the 4 bolts and stabilizer bar with the bushings
and brackets.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(b) Remove the 2 brackets and 2 bushings from the stabilizer
bar.
5. REMOVE BOTH STABILIZER BAR LINKS FROM STA-
BILIZER BAR
(a) Remove the nut, 3 retainers, 2 cushions and disconnect
the stabilizer bar link from the bracket.
Torque: 15 N´m (150 kgf´cm, 11 ft´lbf)
(b) Employ the same manner described above to the other
side.
(c) Remove the 2 nuts, bolts and stabilizer bar links.
Torque: 26 N´m (270 kgf´cm, 19 ft´lbf)
(d) Remove the 2 collars and cushions.
Page 3050 of 3115
SA16I-02
F05240
ABS Speed Sensor
Wire Harness
Lower Control Arm
N´m (kgf´cm, ft´lbf) : Specified torque
18 (185, 13)
150 (1,530, 111)
150 (1,530, 111)
150 (1,530, 111)
150 (1,530, 111)
Upper Control Arm
Heat Insulator
150 (1,530, 111)
Non-reusable part
- SUSPENSION AND AXLEREAR UPPER AND LOWER CONTROL ARM
SA-181
2131 Author: Date:
2004 LAND CRUISER (RM1071U)
REAR UPPER AND LOWER CONTROL ARM
COMPONENTS
Page 3051 of 3115
SA16K-01
- SUSPENSION AND AXLEREAR UPPER AND LOWER CONTROL ARM
SA-183
2133 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
Installation is in the reverse order of removal (See page SA-182).
Page 3052 of 3115
SA16J-02
F04397
F04398
SA-182
- SUSPENSION AND AXLEREAR UPPER AND LOWER CONTROL ARM
2132 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE REAR WHEEL
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
2. SUPPORT REAR AXLE HOUSING WITH JACK
3. REMOVE UPPER CONTROL ARM
(a) Disconnect the ABS speed sensor wire harness.
(b) RH side:
Remove the bolt and heat insulator.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
(c) Remove the 2 nuts, washers, bolts and upper control arm.
Torque: 150 N´m (1,530 kgf´cm, 111 ft´lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nuts.
4. REMOVE LOWER CONTROL ARM
Remove the 2 nuts, washers, bolts and lower control arm.
Torque: 150 N´m (1,530 kgf´cm, 111 ft´lbf)
HINT:
At the time of installation, after stabilizing the suspension,
torque the nuts.
Page 3053 of 3115
SA15J-02
F04387
F04389
F04390
- SUSPENSION AND AXLEREAR WHEEL HUB BOLT
SA-93
2043 Author: Date:
2004 LAND CRUISER (RM1071U)
REAR WHEEL HUB BOLT
REPLACEMENT
1. REMOVE REAR WHEEL
2. REMOVE BRAKE CALIPER AND DISC
(a) Remove the 2 bolts, brake caliper and disc.
(b) Support the brake caliper securely.
3. REMOVE HUB BOLT
Using a brass bar and hammer, remove the hub bolt.
4. INSTALL HUB BOLT
Install a washer and nut to a new hub bolt, as shown in the il-
lustration, and install the hub bolt by torquing the nut.
5. INSTALL DISC AND BRAKE CALIPER
Install the disc and brake caliper with the 2 bolts.
Torque: 103 N´m (1,050 kgf´cm, 76 ft´lbf)
6. INSTALL REAR WHEEL
Torque: 131 N´m (1,340 kgf´cm, 97 ft´lbf)
Page 3054 of 3115
SA149-05
F05160
Cotter Pin
Cotter Pin
159 (1,625, 117)
Cotter Pin
Axle Hub with Disc
Tie Rod End
ABS Speed Sensor
and Wire Harness28 (290, 21)
13 (130, 10)
Brake Caliper
Dust Cover
Gasket
Oil Seal
18 (185, 13)
Bearing
Claw Washer
Adjusting Nut
Lock Nut Lock Washer
Gasket
Flange
Snap Ring
Grease Cap
33 (335, 24)
x6
Steering Knuckle
Oil Seal
Bushing
Bearing
147 (1,500, 108)
Steering Knuckle Arm
N´m (kgf´cm, ft´lbf) : Specified torque
Non-reusable part
Precoated part
Steering Knuckle
8.0 (82, 71 in.´lbf)
123 (1,250, 91)
122 (1,250, 90)
28 (290, 21)
64 (650, 47)
See page SA-16
110 (1,125, 81)
- SUSPENSION AND AXLESTEERING KNUCKLE
SA-19
1969 Author: Date:
2004 LAND CRUISER (RM1071U)
STEERING KNUCKLE
COMPONENTS
Page 3055 of 3115
SA14B-04
F04346
SA-22
- SUSPENSION AND AXLESTEERING KNUCKLE
1972 Author: Date:
2004 LAND CRUISER (RM1071U)
DISASSEMBLY
1. REMOVE STEERING KNUCKLE ARM
Remove the 2 bolts and steering knuckle arm.
2. REMOVE OIL SEAL
Using a screwdriver and hammer, remove the oil seal.
3. REMOVE BEARING AND BUSHING
Using a brass and hammer, remove the bearing and bushing.
Page 3056 of 3115

SA14D-04
F04405
F04372
A
BC SA-24
- SUSPENSION AND AXLESTEERING KNUCKLE
1974 Author: Date:
2004 LAND CRUISER (RM1071U)
INSTALLATION
1. INSTALL STEERING KNUCKLE
(a) Apply synthetic oil and lithium soap base chassis grease,
NLGI No. 1 to the drive shaft.
(b) Support the lower suspension arm with jack and connect
the steering knuckle to the lower suspension arm.
NOTICE:
Be careful not to damage the oil seal.
(c) Temporarily install the nut to lower suspension arm.
(d) Raise up the lower suspension arm using a jack and
install the steering knuckle to the upper suspension arm
with a nut.
Torque: 110 N´m (1,125 kgf´cm, 81 ft´lbf)
(e) Install a new cotter pin.
If the holes for the cotter pin are not aligned, tighten the nut fur-
ther up to 60°.
(f) Torque the nut of the lower suspension arm.
Torque: 159 N´m (1,625 kgf´cm, 117 ft´lbf)
(g) Install a new cotter pin.
2. CONNECT TIE ROD END
(a) Connect the tie rod end to steering knuckle with nut.
Torque: 122 N´m (1,250 kgf´cm, 91 ft´lbf)
(b) Install a new cotter pin.
If the holes for the cotter pin are not aligned, tighten the nut fur-
ther up to 60°.
3. CONNECT ABS SPEED SENSOR AND WIRE HAR-
NESS
Install the wire harness and 3 bolts.
Torque:
A: 8.0 N´m (82 kgf´cm, 71 in.´lbf)
B: 13 N´m (130 kgf´cm, 10 ft´lbf)
C: 28 N´m (290 kgf´cm, 21 ft´lbf)
4. INSTALL DUST COVER, GASKET AND OIL SEAL
Install the dust cover, new gasket and oil seal with the 4 bolts.
Torque: 18 N´m (185 kgf´cm, 13 ft´lbf)
5. INSTALL FRONT AXLE HUB (See page SA-16)
