Page 3057 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA14C-04
F04348
SST
F04349
SST
- SUSPENSION AND AXLESTEERING KNUCKLE
SA-23
1973 Author: Date:
2004 LAND CRUISER (RM1071U)
REASSEMBLY
1. INSTALL BEARING AND BUSHING
(a) Using SST and a press, insta

Page 3058 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA14A-04
F04371
F04372
F04373
SST
F04374
SST
SA-20
- SUSPENSION AND AXLESTEERING KNUCKLE
1970 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
1. REMOVE FRONT AXLE HUB (See page SA-12)
2. REMOVE

Page 3059 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual F04375
SST
- SUSPENSION AND AXLESTEERING KNUCKLE
SA-21
1971 Author: Date:
2004 LAND CRUISER (RM1071U)
(c) Using SST, disconnect the steering knuckle from the up-
per suspension arm.
SST 09628-6201

Page 3060 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA141-04
R03031
F13676
Front (A)(B)
R07928
SA-4
- SUSPENSION AND AXLETIRE AND WHEEL
1954 Author: Date:
2004 LAND CRUISER (RM1071U)
TIRE AND WHEEL
INSPECTION
1. INSPECT TIRE
(a) Check the tires fo

Page 3061 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - SUSPENSION AND AXLETIRE AND WHEEL
SA-5
1955 Author: Date:
2004 LAND CRUISER (RM1071U)
4. CHECK FRONT SUSPENSION FOR LOOSENESS
5. CHECK STEERING LINKAGE FOR LOOSENESS
6. CHECK BALL JOINT FOR LOO

Page 3062 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA140-09
- SUSPENSION AND AXLETROUBLESHOOTING
SA-1
1951 Author: Date:
2004 LAND CRUISER (RM1071U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the probl

Page 3063 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA-2
- SUSPENSION AND AXLETROUBLESHOOTING
1952 Author: Date:
2004 LAND CRUISER (RM1071U) Noise in rear axle
1. Oil level (Low or wrong grade)
2. Excessive backlash between pinion and ring gear
3.

Page 3064 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual SA28F-03
START
Preliminary Check
�Tire pressure
�Vehicle height
�Brake dragging ROAD TEST
Does the vehicle lead/pull?
Cross switch front tire & wheel
assemblies (left & right).
Does the ve

SA28F-03
START
Preliminary Check
Tire pressure
Vehicle height
Brake dragging ROAD TEST
Does the vehicle lead/pull?
Cross switch front tire & wheel
assemblies (left & right).
Does the vehicle lead/pull in
same direction as before?
Check front wheel alignment.
Is it within specification?
Adjust front wheel alignment.Reverse the front left side
tire and rebalance it.
Does the vehicle
lead/pull to the left?
COMPLETE
Are the tires uni-directional type?
Choose the position of front tire & wheel
assemblies where there is least amount of pull.
Increase left front camber and decrease
right front camber until lead/pull is eliminated.Increase right front camber and decrease
left front camber until lead/pull is eliminated.
NO
YES
YES
NO
YES
YES
NO
YES
NO COMPLETE
NONOYES NOIs there steering
off center?
Adjust front tie rods.
NO
YES
Is the lead/pull stronger
than before?
YES
NOTICE : Do not exceed 1° of cross camber.
Do not exceed adjustment range.
Select a flat road where the vehicle can be driven in a straight line for 100 meters at a constant speed
of 35mph. Please confirm safety and set the steering wheel to its straight position. Drive the vehicle in
a straight line for 100 meters at a constant speed of 35mph without holding the steering wheel.
(1) The vehicle can keep straight but the steering wheel has some angle.
STEERING OFF CENTER (See page SR-10)
(2) The vehicle cannot keep straight.
STEERING PULL
YES NO
YES ROAD TEST
Does the vehicle still lead/pull?
NO ROAD TEST
Does the vehicle still lead/pull? ROAD TEST
Does the vehicle still lead/pull?
ROAD TEST
Does the vehicle still lead/pull?NO
Contact your local retail tire distributor.YES
*
*
- SUSPENSION AND AXLETROUBLESHOOTING
SA-3
1953 Author: Date:
2004 LAND CRUISER (RM1071U)
REPAIR PROCEDURES
HINT:
This is a flow chart for vehicle pull.
