TOYOTA LAND CRUISER 1998 Factory Repair Manual BE-24 - BODY ELECTRICALPOWER SOURCE 2397 Author: Date: 2004 LAND CRUISER (RM1071U) ACC 13 - Ground Ignition switch ACCBattery positive voltage CIG 15 - GroundIgnition switch ACCBattery positive vo

Page 298 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual I25276 Cowl Side J/B RH: - BODY ELECTRICALPOWER SOURCE BE-25 2398 Author: Date: 2004 LAND CRUISER (RM1071U) 3. INSPECT COWL SIDE J/B RH CIRCUIT

Page 299 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual I25274 Cowl Side J/B RH (Back Side): IG1 No.3 Relay ACC CUT Relay BE-26 - BODY ELECTRICALPOWER SOURCE 2399 Author: Date: 2004 LAND CRUISER (RM1071U) (a) Remove the fuse from the junction block and

Page 300 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - BODY ELECTRICALPOWER SOURCE BE-27 2400 Author: Date: 2004 LAND CRUISER (RM1071U) DIFF 12 - Ground Ignition switch ONBattery positive voltage ECU-B2 13 - GroundConstantBattery positive voltage P/

Page 301 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual BE2EI-01 I24733 Engine Room R/B Cowl Side J/B LHCowl Side J/B RH Fusible Link Block - BODY ELECTRICALPOWER SOURCE BE-1 1 2384 Author: Date: 2004 LAND CRUISER (RM1071U) POWER SOURCE LOCATION

Page 302 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual I24921 Fuses: 1. TOWING 2. MIR HTR 3. RR HTR 4. HAZ-TEN 5. ALT-S 6. NV-IR 7. FR FOG 8. TOWING BRK 9. HEAD CLNER 10. FR-IG 11. PANEL 12. TOWING TAIL 13. TAIL 14. - 15. BAT 16. TEL 17. AMP 18. EFI or E

Page 303 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual I24922 Cowl Side J/B LH ABCD Relays: A. DEFOG B. IG1 No.2 C. ACC D. DOME Fuses: 1. AHC-IG 2. POWER HTR 3. FUEL HTR 4. AHC-B 5. DEFOG 6. AM1 7. ACC 8. CIG 9. PWR OUTLET 10. OBD-2 11. STOP 12. A/C 13. B

Page 304 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual I24923 Cowl Side J/B RH Relays: A. ACC CUT B. IG1 NO.3 C. POWER MAIN Fuses: 1. P/W (RL) 2. P/W (FL) 3. VGRS 4. DOME 5. RADIO 6. WASHER 7. DIFF 8. ECU-B2 9. P/W(FR) 10.P/W(RR) 11. SECURITY 12. IGN 13.
