TOYOTA LAND CRUISER 1998 Factory Repair Manual B06412
B06415
Drain Plug
B06413Drain Plug
- MAINTENANCECHASSIS
MA-9
57 Author: Date:
(b) Differential:
Remove the filler plug and feel inside the hole with your
finger. Check that the oil comes to w

Page 2474 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual B06416
Lubricating Positions: 1. Spider
2. Slide Yoke21
1
MA-10
- MAINTENANCECHASSIS
58 Author: Date:
Grease grade:
Lithium base chassis grease (NLGI No.2)
(b) Tightening bolts for propeller shaft

Page 2475 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual MA02S-01
MA-6
- MAINTENANCEENGINE
54 Author: Date:
2004 LAND CRUISER (RM1071U)
ENGINE
INSPECTION
HINT:
Inspect these items when the engine is cold.
1. REPLACE TIMING BELT (See page EM-15)
2. INSPE

Page 2476 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual MA02Q-01
MA-2
- MAINTENANCEINSIDE VEHICLE
50 Author: Date:
2004 LAND CRUISER (RM1071U)
INSIDE VEHICLE
GENERAL MAINTENANCE
These are the maintenance and inspection items which are considered to be

MA02Q-01
MA-2
- MAINTENANCEINSIDE VEHICLE
50 Author: Date:
2004 LAND CRUISER (RM1071U)
INSIDE VEHICLE
GENERAL MAINTENANCE
These are the maintenance and inspection items which are considered to be owner's responsibility. They
can be done by the owner or be can have them done at a service shop. These items include those which
should be checked on a daily basis, those which, in most cases, do not require (special) tools and those
which are considered to be reasonable for the owner to do. Items and procedures for general maintenance
are as follows.
1. GENERAL NOTES
Maintenance items may very from country and country. Check the owner's manual supplement in
which the maintenance schedule is shown.
Every service items in the periodic maintenance schedule must be performed.
Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).
Maintenance service after the last period should be performed at the same time interval as before un-
less otherwise noted.
Failure to do even one item an cause the engine to run poorly and increase exhaust emissions.
2. LIGHTS
(a) Check that the headlights, stop lights, taillights, turn signal lights, and other lights are all working.
(b) Check the headlights aim.
3. WARNING LIGHTS AND BUZZERS
Check that all warning lights and buzzers function properly.
4. HORN
Check that it is working.
5. WINDSHIELD GLASS
Check for scratches, pits or abrasions.
6. WINDSHIELD WIPER AND WASHER
(a) Check operation of the wipers and washer.
(b) Check that the wipers do not streak.
7. WINDSHIELD DEFROSTER
Check that air comes out from the defroster outlet when operating the heater or air conditioner at defroster
mode.
8. REAR VIEW MIRROR
Check that it is mounted securely.
9. SUN VISORS
Check that they move freely and mounted securely.
10. STEELING WHEEL
Check that it has the specified freeplay. Be alert for changes in steering condition, such as hard steering,
excessive freeplay or strange noises.
11. SEATS
(a) Check that all front seat controls such as seat adjusters, seatback recliner, etc. operate smoothly.
(b) Check that all latches lock securely in any position.
(c) Check that the head restraints move up and down smoothly and that the locks hold securely in any
latch position.
(d) For folding-down rear seat backs, check that the latches look securely.
12. SEAT BELTS
(a) Check that the seat belt system such as buckles, retractors and anchors operate properly and smooth-
ly.
(b) Check that the belt webbing is not cut, frayed, worn or damaged.

Page 2477 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - MAINTENANCEINSIDE VEHICLE
MA-3
51 Author: Date:
2004 LAND CRUISER (RM1071U)
13. ACCELERATOR PEDAL
Check the pedal for smooth operation and uneven pedal effort or catching.
14. BRAKE PEDAL (See p

Page 2478 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual MA02P-02
- MAINTENANCEOUTSIDE VEHICLE
MA-1
49 Author: Date:
2004 LAND CRUISER (RM1071U)
OUTSIDE VEHICLE
GENERAL MAINTENANCE
These are some maintenance and inspection items which are considered to

MA02P-02
- MAINTENANCEOUTSIDE VEHICLE
MA-1
49 Author: Date:
2004 LAND CRUISER (RM1071U)
OUTSIDE VEHICLE
GENERAL MAINTENANCE
These are some maintenance and inspection items which are considered to be the owner's responsibility.
They can be done by the owner or they can have them done at a service shop. These items include those
which should be checked on a daily basis, those which, in most cases, do not require (special) tools and
those which are considered to be reasonable for the owner to do. Items and procedures for general mainte-
nance are as follows.
1. GENERAL NOTES
Maintenance items may very from country and country. Check the owner's manual supplement in
which the maintenance schedule is shown.
Every service items in the periodic maintenance schedule must be performed.
Periodic maintenance service must be performed according to whichever interval in the periodic main-
tenance schedule occurs first, the odometer reading (miles) or the time interval (months).
Maintenance service after the last period should be performed at the same time interval as before un-
less otherwise noted.
Failure to do even one item an cause the engine to run poorly and increase exhaust emissions.
2. TIRES
(a) Check the pressure with a gauge. If necessary, adjust.
(b) Check for cuts, damage or excessive wear.
3. WHEEL NUTS
When checking the tires, check the nuts for looseness or for missing nuts. If necessary, tighten them.
4. TIRE ROTATION
Check the owner's manual supplement in which the maintenance schedule is shown.
5. WINDSHIELD WIPER BLADES
Check for wear or cracks whenever they do not wipe clean. If necessary, replace.
6. FLUID LEAKS
(a) Check underneath for leaking fuel, oil, water or other fluid.
(b) If you smell gasoline fumes or notice any leak, have the cause found and corrected.
7. DOORS AND ENGINE HOOD
(a) Check that all doors and the tailgate operate smoothly, and that all larches lock securely.
(b) Check that the engine hood secondary latch secures the hood from opening when the primary latch
is released.

Page 2479 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual MA02R-05
MA-4
- MAINTENANCEUNDER HOOD
52 Author: Date:
2004 LAND CRUISER (RM1071U)
UNDER HOOD
GENERAL MAINTENANCE
1. GENERAL NOTICE
Maintenance items may vary from country to country. Check the

Page 2480 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual - MAINTENANCEUNDER HOOD
MA-5
53 Author: Date:
2004 LAND CRUISER (RM1071U)
11. EXHAUST SYSTEM
Visually inspect for cracks, holes or loose supports.
If any change in the sound of the exhaust or smel
