- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMNSR-35
2244 Author: Date:
2004 LAND CRUISER (RM1071U)
9. INSTALL 2 ENERGY ABSORBING GUIDES, PLATES
AND CLIPS
(a) Install the 2 new energy absorbing guides and 2 new ab-
sorbing plates.
(b) Install the 2 new energy absorbing clips.
10. INSTALL COLUMN TUBE SUPPORT
(a) Install the tube attachment to the column tube support.
(b) Install the column tube support with the bolt.
Torque: 15 N´m (150 kgf´cm, 11 ft´lbf)
11. INSTALL COLUMN UPPER BRACKET AND COLUMN
UPPER CLAMP
(a) Install the 2 telescopic steering wedge lock springs, 2
steering lock wedges and column upper bracket and col-
umn upper clamp.
(b) Using a hexagon wrench, install the 2 telesco lever lock
bolts.
Torque: 10 N´m (100 kgf´cm, 7 ft´lbf)
(c) Install and tighten the 2 new tapered-head bolts until the
bolt heads break off.
(d) Install the column tube stopper.
Torque: 19 N´m (190 kgf´cm, 14 ft´lbf)
12. INSTALL POWER TELESCOPIC MOTOR
(a) Install the telescopic steering column cable.
(b) Install the power telescopic motor with the 2 bolts.
Torque: 9.0 N´m (90 kgf´cm, 78 in.´lbf)
13. INSTALL ADJUSTING NUT NO. 1
(a) Install 2 new support stopper bolt bushings to the adjust-
ing nut No. 1.
(b) Install the adjusting nut No. 1 to the column upper tube.
(c) Install the 2 tilt steering shafts.
14. INSTALL POWER TILT MOTOR
(a) Install 2 new support stopper bolt bushings to the power
tilt motor.
(b) Install 2 new E-rings.
(c) Using a hexagon wrench, install the power tilt motor and
2 tilt steering bolts.
Torque: 20 N´m (210 kgf´cm, 15 ft´lbf)
(d) Install the stopper No. 1 and stopper spring.
(e) Using a hexagon wrench, install the support stopper bolt.
15. INSTALL TURN SIGNAL BRACKET
Install the turn signal bracket with the 3 bolts.
16. INSTALL STEERING COLUMN PROTECTOR NO. 1
Install the steering column protector No. 1 with the bolt.
Torque: 15 N´m (150 kgf´cm, 11 ft´lbf)
17. INSTALL CONNECTOR BRACKET
Install the connector bracket with the bolt.
18. INSTALL TRANSPONDER KEY AMPLIFIER AS-
SEMBLY
19. INSTALL NO. 2 LOWER COVER
Page 2858 of 3115
F04881
Matchmarks SR-36
- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMN
2245 Author: Date:
2004 LAND CRUISER (RM1071U)
20. INSTALL INTERMEDIATE SHAFT ASSEMBLY
(a) Install the thrust stopper and upper side No. 2 lower cover.
(b) Align the matchmarks on the intermediate shaft assembly
and main shaft assembly.
(c) Install the bolt.
Torque: 34 N´m (350 kgf´cm, 25 ft´lbf)
21. INSTALL NO. 2 LOWER COVER
Install the No. 2 lower cover with the 2 nuts.
Torque: 25 N´m (260 kgf´cm, 19 ft´lbf)
Page 2859 of 3115
SR0M8-02
- STEERINGPOWER TILT AND POWER TELESCOPIC STEERING
COLUMNSR-29
2238 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
(See page SR-14)
Page 2860 of 3115
SR0LU-03
- STEERINGSTEERING SYSTEM
SR-1
2210 Author: Date:
2004 LAND CRUISER (RM1071U)
STEERING SYSTEM
PRECAUTION
Care must be taken to replace parts properly because they could affect the performance of the
steering system and result in a driving hazard.
The LAND CRUISER is equipped with SRS (Supplemental Restraint System) such as the driver
airbag and front passenger airbag. Failure to carry out service operation in the correct se-
quence could cause the SRS to unexpectedly deploy during servicing, possibly leading to a
serious accident. Before servicing (including removal or installation of parts, inspection or re-
placement), be sure to read the precautionary notices in the RS section.
Page 2861 of 3115
R12473
SR0M0-06
F03748
- STEERINGSTEERING WHEEL
SR-9
2218 Author: Date:
2004 LAND CRUISER (RM1071U)
STEERING WHEEL
INSPECTION
1. CHECK STEERING WHEEL FREEPLAY
(a) Stop the vehicle and face the tires straight ahead.
(b) Rock the steering wheel gently up and down with a finger
lightly, check the steering wheel freeplay.
Maximum freeplay: 40 mm (1.58 in.)
2. CHECK STEERING EFFORT
(a) Center the steering wheel.
(b) Remove the steering wheel pad (See page SR-14).
(c) Start the engine and run it at idle.
(d) Measure the steering effort in both directions.
Steering effort (Reference):
4.9 N´m (50 kgf´cm, 43 in.´lbf)
HINT:
Be sure to consider the tire type, pressure and contact surface
before making your diagnosis.
(e) Torque the steering wheel set nut.
Torque: 50 N´m (510 kgf´cm, 37 ft´lbf)
(f) Install the steering wheel pad (See page SR-24).
Page 2862 of 3115
SR1HO-15
F16015
Steering Wheel
Masking Tape
Steering Column
Upper Cover
F16016
Steering Column
Upper Cover
Marked Line
Steering
Wheel
Masking
Tape
SR-10
- STEERINGSTEERING WHEEL
2219 Author: Date:
2004 LAND CRUISER (RM1071U)
REPAIR PROCEDURES
HINT:
This is the repair procedure for steering off center.
1. INSPECT STEERING WHEEL OFF CENTER
(a) Apply masking tape on the top center of the steering
wheel and steering column upper cover.
(b) Drive the vehicle in a straight line for 100 meters at a
constant speed of 35 mph (56 km/h), and hold the steer-
ing wheel to maintain the course.
(c) Draw a line on the masking tape as shown in the illustra-
tion.
Page 2863 of 3115

F16017
Steering Column
Upper Cover
New Marked
Line
Steering Wheel
R00429
Marked Line
F16018
- STEERINGSTEERING WHEEL
SR-1 1
2220 Author: Date:
2004 LAND CRUISER (RM1071U)
(d) Turn the steering wheel to its straight position.
HINT:
Refer to the upper surface of the steering wheel, steering spoke
and SRS airbag line for the straight position.
(e) Draw a new line on the masking tape of the steering wheel
as shown in the illustraion.
(f) Measure the distance between the 2 lines on the masking
tape of the steering wheel.
(g) Convert the measured distance to steering angle.
Measured distance 1 mm (0.04 in.) = Steering angle
approximately 1 deg.
HINT:
Make a note of the steering angle.
2. ADJUST STEERING ANGLE
(a) Draw a line on the RH and LH tie rod and rack ends where
it can easily be seen.
(b) Using a paper gauge, measure the distance from RH and
LH tie rod ends to the rack end screws.
HINT:
Measure the RH side and LH side.
Make a note of the measured values.
(c) Remove the RH and LH boot clips from the rack boots.
(d) Loosen the RH and LH lock nuts.
(e) Turn the RH and LH rack end by the same amount (but
in different directions) according to the steering angle.
1 turn 360 deg. of rack end (1.5 mm (0.059 in.) horizon-
tal movement) = 12 deg. of steering angle
(f) Tighten the RH and LH lock nuts.
Torque: 55 N´m (560 kgf´cm, 41 ft´lbf)
NOTICE:
Make sure that the difference in length between RH and LH
tie rod ends and rack end screws are within 1.5 mm (0.059
in.).
(g) Install the RH and LH boot clips.
(h) Perform the zero point calibration of yaw rate and decel-
eration sensors (See page DI-505).
Page 2864 of 3115

SR0LV-03
SR-2
- STEERINGTROUBLESHOOTING
2211 Author: Date:
2004 LAND CRUISER (RM1071U)
TROUBLESHOOTING
PROBLEM SYMPTOMS TABLE
Use the table below to help you find the cause of the problem. The numbers indicate the priority of the likely
cause of the problem. Check each part in the order shown. If necessary, repair or replace these parts.
SymptomSuspect AreaSee page
Hard steering
3. Tires (Improperly inflated)
4. Power steering fluid level (Low)
5. Drive belt (Loose)
6. Front wheel alignment (Incorrect)
7. Steering system joints (Worn)
8. Suspension arm ball joints (Worn)
9. Steering column (Binding)
10.Power steering gearSA-4
SR-5
-
SA-6
-
SA-71
SA-76
-
SR-48
Poor return
1. Tires (Improperly inflated)
2. Front wheel alignment (Incorrect)
3. Steering column (Binding)
4. Power steering gearSA-4
SA-6
-
SR-48
Excessive play
1. Steering system joints (Worn)
2. Suspension arm ball joints (Worn)
3. Intermediate shaft, Universal joint, Sliding yoke (Worn)
4. Front wheel bearing (Worn)
5. Power steering gear-
SA-71
SA-76
-
SA-1 1
SR-48
Abnormal noise
1. Power steering fluid level (Low)
2. Steering system joints (Worn)
3. Power steering gearSR-5
-
SR-48
HINT:
When the problem occurs on the power tilt and telescopic steering system, refer to the DI section
(See page DI-656).
