Page 2649 of 3115
B16436
Battery
4 5
- SFIFUEL PUMP
SF-9
1708 Author: Date:
2004 LAND CRUISER (RM1071U)
Resistance: 0.2 - 3.0 W at 20°C (68°F)
If the resistance is not as specified, replace the fuel pump and/
or the lead wire.
(g) Inspect the fuel pump operation.
Connect the battery positive (+) lead to terminal 4 of the
connector, and the battery negative (-) lead to terminal 5.
Check that the fuel pump operates.
NOTICE:
These tests must be done quickly (within 10 seconds)
to prevent the coil burning out.
Keep the fuel pump as far away from the battery as
possible.
Always change the connection on the battery side.
If operation is not as specified, replace the fuel pump and/or
lead wire.
(h) Reconnect the fuel pump & sender gauge connector.
(i) Reinstall the rear floor service hole cover with the 2
screws.
(j) Reinstall the front and rear floor carpets.
(k) Remove the 2 rear door scuff plates, the step plates and
the rear sear lock covers.
(l) Reinstall the No.1 rear seats.
Page 2650 of 3115

SF0XX-04
B16440
Pull
Enlarge
Tube Joint
Clip
B16441
Plug
Turn
Turn
- SFIFUEL PUMP
SF-13
1712 Author: Date:
2004 LAND CRUISER (RM1071U)
REMOVAL
CAUTION:
Do not smoke or work near an open frame when working
the fuel pump.
1. REMOVE NO.1 REAR SEATS
2. REMOVE REAR DOOR SCUFF PLATES, STEP
PLATES AND REAR SEAT LOCK COVERS
3. REMOVE REAR FLOOR SERVICE HOLE COVER
(a) Take off the front and rear floor carpets.
(b) Remove the 2 screws and rear floor service hole cover.
4. DISCONNECT FUEL PUMP & SENDER GAUGE CON-
NECTOR
5. DISCONNECT FUEL MAIN TUBE AND RETURN TUBE
(FUEL TUBE CONNECTORS) FROM FUEL SUCTION
PLATE
CAUTION:
Perform disconnecting operation of the fuel tube con-
nector (quick type) after reading the precautions.
(See page SF-1)
Prevent the retained pressure in the fuel line from
splashing inside the vehicle compartment.
Be careful not to damage the contact surface or let the
foreign matters on there when sealing the tube and
the suction plates with the quick connectors through
O-ring.
Be sure to perform the disconnection by hand. Do not
use tools.
Do not bend or turn the nylon tube by force.
(a) Before the operation, remove foreign matters or dirt stick-
ing to the tube joint clips.
(b) Enlarge the tip of the clips with fingers and pull them out
for disconnection.
(c) Pull out the fuel main tube and the return tube.
If the nylon tube and the suction plate stick together, ease the
connection by turning the nylon tube with fingers and pull it out
for disconnection.
NOTICE:
Plug the port of the fuel suction plate with a clean rubber
cap.
(d) After the disconnection, protect the connector with a plas-
tic bag.
Page 2651 of 3115
B16442
B04925
Pull
B04924
SF-14
- SFIFUEL PUMP
1713 Author: Date:
2004 LAND CRUISER (RM1071U)
6. REMOVE FUEL PUMP AND SENDER GAUGE AS-
SEMBLY FROM FUEL TANK
(a) Remove the 8 bolts.
(b) Pull out the fuel pump and the sender gauge assembly.
NOTICE:
Do not damage the fuel pump filter.
Be careful that the arm of the sender gauge should
not bent.
(c) Remove the gasket from the fuel section plate.
7. REMOVE LEAD WIRE FROM FUEL PUMP
8. REMOVE FUEL PUMP FROM FUEL PUMP BRACKET
(a) Pull out the lower side of the fuel pump from the pump
bracket.
(b) Disconnect the fuel hose from the fuel pump, and remove
the fuel pump.
(c) Remove the rubber cushion from the fuel pump.
9. REMOVE FUEL PUMP FILTER FROM FUEL PUMP
(a) Using a small screwdriver, remove the clip.
(b) Pull out the pump filter.
Page 2652 of 3115
SF0Y9-09
B16456
N´m (kgf´cm, ft´lbf)
Non-reusable part: Specified torqueHeated Oxygen
Sensor Connector
Heated Oxygen Sensor
Gasket
Engine Under Cover Bank 2 Sensor 1
Bank 2 Sensor 2
44 (450, 32)
20 (200, 14)
Heated Oxygen Sensor
Bank 1 Sensor 2
Bank 1 Sensor 1
Heated Oxygen
Sensor Connector
Heated Oxygen Sensor
Heated Oxygen
Sensor Connector
Heated Oxygen
Sensor
20 (200, 14)
Gasket
44 (450, 32)
Heated Oxygen
Sensor Connector
SF-56
- SFIHEATED OXYGEN SENSOR
1755 Author: Date:
2004 LAND CRUISER (RM1071U)
HEATED OXYGEN SENSOR
COMPONENTS
Page 2653 of 3115
SF0YA-12
B04936B04937B04998
Sensor 1
Sensor 2Ohmmeter
OhmmeterHT
+B
HT+B
- SFIHEATED OXYGEN SENSOR
SF-57
1756 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT HEATER RESISTANCE OF HEATED OXY-
GEN SENSORS
(a) Disconnect the oxygen sensor connector.
(b) Using an ohmmeter, measure the resistance between ter-
minal +B and HT.
Resistance: 11 - 16 W at 20°C (68°F)
If the resistance is not as specified, replace the sensor.
Torque:
44 N´m (450 kgf´cm, 32 ft´lbf) for sensor 1
20 N´m (200 kgf´cm, 14 ft´lbf) for sensor 2
(c) Reconnect the oxygen sensor connector.
2. INSPECT OPERATION OF HEATED OXYGEN SEN-
SORS (See pages DI-106 and DI-138)
Page 2654 of 3115
SF0OS-13
B16445
V-Bank Cover
PS Air Hose
Air Inlet Hose for EVAP
PCV Hose
Intake Air Connector
Vacuum Sensing Hose
Fuel Return Hose
SF-20
- SFIINJECTOR
1719 Author: Date:
2004 LAND CRUISER (RM1071U)
COMPONENTS
Page 2655 of 3115
B16446
Engine Wire Clamp
No.4 V-bank Cover BracketEngine Wire Protector
Fuel Pressure
Regulator
Gasket
Upper Gasket
Lower GasketRH Delivery PipeSpacer
Front Fuel Pipe Grommet
InjectorLH Delivery Pipe
Insulator
Fuel Main Hose
VSV for EVAP
* 33 (340, 24)
39 (400, 29)
Fuel Pressure
Pulsation Damper
Spacer
Gasket
SpacerSpacer
O-Ring
Injector Connector
PCV Hose
Vacuum Sensing Hose
No.2 V-Bank
Cover Bracket
N´m (kgf´cm, ft´lbf)
Non-reusable part: Specified torque
* For use with SST
Engine Wire Clamp
Gasket
Gasket
39 (400, 29)
39 (400, 29)
Fuel Return Pipe O-Ring
Fuel Return Hose
No.1 V-Bank Cover Bracket
7.5 (80, 66 in.´lbf)
No.3 V-Bank Cover Bracket
21 (214, 15)
21 (214, 15)
- SFIINJECTOR
SF-21
1720 Author: Date:
2004 LAND CRUISER (RM1071U)
Page 2656 of 3115

SF0Y3-06
B04989
SST
InjectorFuel Filter
(On-V ehicle)
Fuel Tube
Connector
SST
SST
SST
Pressure Regulator
B05006
Disconnect
Pull
Push
B04990
B05011
SST (Hose)
B04988
Pressure Regulator
SST (Hose)
SST (Union)
Fuel Return Hose
SF-24
- SFIINJECTOR
1723 Author: Date:
2004 LAND CRUISER (RM1071U)
INSPECTION
1. INSPECT INJECTOR INJECTION
CAUTION:
Keep injector clean of sparks during the test.
(a) Disconnect the fuel inlet hose (fuel tube connector) from
the fuel filter.
CAUTION:
Perform disconnecting operations of the fuel tube
connector (quick type) after reading the precautions
(See page SF-1).
Prevent the retained pressure in the fuel pipe line
from splashing inside the engine compartment.
(b) Use a new fuel main hose and take out the fuel tube con-
nector from its hose.
Part No. 23271-50150
(c) Connect SST (hose) and fuel tube connector to the fuel
filter outlet.
SST 09268-41047
CAUTION:
Perform connecting operations of the fuel tube connector
(quick type) after reading the precautions (See page
SF-1).
HINT:
Use the vehicle's fuel filter.
(d) Remove the pressure regulator from the delivery pipe.
(e) Install the O-ring to the fuel inlet of the pressure regulator.
(f) Connect SST (hose) to the fuel inlet of the pressure regu-
lator with SST (union) and the 2 bolts.
SST 09268-41047 (09268-41091)
Torque: 7.5 N´m (80 kgf´cm, 66 in.´lbf)
(g) Connect the fuel return hose to the fuel outlet of the pres-
sure regulator.
