Page 1905 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A03111
Adjusting Shim Selection Chart (Intake)
Shim No. Installed shim thickness
mm (in.)
mm (in.) Measured clearance
Thickness
New shim thicknessShim No. Thickness Shim No. Thickness
mm (in.)
Intake

Page 1906 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual A03112
Adjusting Shim Selection Chart (Exhaust)
Installed shim thickness
mm (in.)
mm (in.) Measured clearance
Shim No. Thickness
New shim thicknessShim No. Thickness Shim No. Thickness
mm (in.)
Exhau

Page 1907 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual NOTICE
When handling supplemental restraint system components (removal,
installation or inspection, etc.), always follow the direction given in the repair
manuals listed above to prevent accidents and

Page 1908 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual 2003
All rights reserved. This book may not be
reproduced or copied, in whole or in part, without
the written permission of Toyota Motor
Corporation.
2004 LAND CRUISER (EWD548U)
1
2004 LAND CRUISER

Page 1909 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual 2004 LAND CRUISER (EWD548U)
2A INTRODUCTION
This manual consists of the following 13 sections:
No.
SectionDescription
A
INDEXIndex of the contents of this manual.
A
INTRODUCTIONBrief explanation of e

Page 1910 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual 2004 LAND CRUISER (EWD548U)
3 HOW TO USE THIS MANUAL B
This manual provides information on the electrical circuits installed on vehicles by
dividing them into a circuit for each system.
The actual wi

Page 1911 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual
[A]
[B]
[H] [D]
[F] [E]
[ I ]
[L]
[M][J]
[K][G] [C]
1 2
IBIB
34
4 7
2111134
1 2
6 3
1 2
B18
BLRL
GR
B18 GR
3 4
Rear Combination Light RH R 7
Rear Combination Light LH R 6
High Mounted
Stop Light H1

Page 1912 of 3115

TOYOTA LAND CRUISER 1998 Factory Repair Manual 2004 LAND CRUISER (EWD548U)
5 B
[A]: System Title
[B]: Indicates a Relay Block. No shading is used and
only the Relay Block No. is shown to distinguish it
from the J/B
Example: Indicates Relay

2004 LAND CRUISER (EWD548U)
5 B
[A]: System Title
[B]: Indicates a Relay Block. No shading is used and
only the Relay Block No. is shown to distinguish it
from the J/B
Example: Indicates Relay Block No.1
[C]: ( ) is used to indicate different wiring and
connector, etc. when the vehicle model, engine
type, or specification is different.
[D]: Indicates related system.
[E]: Indicates the wiring harness and wiring harness
connector. The wiring harness with male terminal is
shown with arrows (
).
Outside numerals are pin numbers.
Female Male ( )
The first letter of the code for each wiring harness
and wiring harness connector(s) indicates the
component's location, e.g, ºEº for the Engine
Compartment, ºIº for the Instrument Panel and
Surrounding area, and ºBº for the Body and
Surrounding area.
When more than one code has the first and second
letters in common, followed by numbers (e.g, IH1,
IH2), this indicates the same type of wiring harness
and wiring harness connector.
[F]: Represents a part (all parts are shown in sky blue).
The code is the same as the code used in parts
position.
[G]: Junction Block (The number in the circle is the J/B
No. and the connector code is shown beside it).
Junction Blocks are shaded to clearly separate
them from other parts.
3C indicates that
it is inside
Junction Block
No.3
Example:
[H]: Indicates the wiring color.
Wire colors are indicated by an alphabetical code.
B = Black W = White BR = Brown
L = Blue V = Violet SB = Sky Blue
R = Red G = Green LG = Light Green
P = Pink Y = Yellow GR = Gray
O = Orange
The first letter indicates the basic wire color and the
second letter indicates the color of the stripe.
Example: L - Y
L
(Blue)Y
(Yellow)
[I]: Indicates a wiring Splice Point (Codes are ºEº for the
Engine Room, ºIº for the Instrument Panel, and ºBº
for the Body).
The Location of splice Point I 5 is indicated by the
shaded section.
[J]: Indicates a shielded cable.
[K]: Indicates the pin number of the connector.
The numbering system is different for female and
male connectors.
Example:
Numbered in order
from upper left to
lower rightNumbered in order
from upper right to
lower left
Female
Male
[L]: Indicates a ground point.
The first letter of the code for each ground point(s)
indicates the component's location, e.g, ºEº for the
Engine Compartment, ºIº for the Instrument Panel
and Surrounding area, and ºBº for the Body and
Surrounding area.
[M]: Page No.
